Огнеупорный тепловой барьер uetersen MBI паровой r13 изоляционный рулон Стекловолоконная вата изоляционное покрывало
- Категория: Heat Insulation Materials >>>
- Поставщик: Uetersen,New,Materials,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.71 $* | 0.45 $* |
| Aug-16-2025 | 0.66 $* | 0.74 $* |
| Jul-16-2025 | 0.42 $* | 0.34 $* |
| Jun-16-2025 | 0.6 $* | 0.11 $* |
| May-16-2025 | 0.80 $* | 0.4 $* |
| Apr-16-2025 | 0.35 $* | 0.99 $* |
| Mar-16-2025 | 0.67 $* | 0.86 $* |
| Feb-16-2025 | 0.17 $* | 0.88 $* |
| Jan-16-2025 | 0.13 $* | 0.42 $* |
Характеристики
Product Description
Youke glass wool uses a new formaldehyde-free thermo setting binder to produce different types formaldehyde-free environmentally friendly glass wool and other kinds of glass wools.
No. | Item | Unit | National Standard | Company Product | Remark |
1 | Density of glass wool board | kg/m3 | 24-96 | 24-96 | GB/T13350-2017 |
Density of glass wool Blanket | kg/m3 | 10-48 | 10-48 | GB/T13350-2017 | |
Density of glass wool Batt | kg/m3 | 10-48 | 10-48 | GB/T13350-2017 | |
2 | Avearage Fiber diameter | ≤8.0 | 5.5 | GB5480.4-85 | |
3 | Hygroscopicity | % | ≥98 | 98.2 | GB10299-88 |
4 | Thermal Conductivity | w/m.k | ≤0.042 | 0.032 | GB10294-88 |
5 | Noncombustibility | 0 | Noncombustible | Noncombustible (A) | GB5464-85 |
6 | Sound Absorption Coefficient | 0 | 0 | 1.03 product reverberation method 24kg/m3 2000HZ | GBJ47-83 |
7 | Highest usage Temperature | °C | ≤350 | 350 | GB11835-89 |
Products &Project
Our laboratory
Material inspection
Testing difference instruction of material
Water-proof inspection
Up than 98% of water proof level,Pass difference lots of certification of fire-resistance standard.
Fire-resistance inspection
Tested at 400 degrees. Pass difference lots of certification of fire-resistance standard.
Our Company
Production lines
Production sites
Work Site
Cutting site
Warehouse 1
Our Warehouse
Warehouse 2
Our warehouse
Factory Base 1 :Locate in South of China Market
Factory base 2
Locate in South-west of China Market
Factory base 3
Locate in East of China Market
Our production sites
Glass fiber material
Glass slag, soda and other materials are evenly stirred into the kiln.
Melting glass fiber
Material at about1400 degrees according to the formula, then turned into liquid.
Glass fiber silk after Centrifugal
Liquid cooled to convey to the centrifuge. Resin glue and a certain amount of water are added at the same time of being thrown into silk.
Glass fiber silk in transit
Glass fiber silk convey to the hot air pressing room.
Automatic air pressing site
Then formed by hot air pressing,heat curing.
Glass wool plate in automatic cutting site
Width cutting,cutting edges and corners are reused through the automatic recovery system.
Length size of Glass wool plate be cutted when throughing cutting gate at a certain distance.
Glass wool strip in automatic cutting
Glass wool plates be cutted to be strips
Glass wool in automatic packing
Glass wool strip be packing automatic ,packing by PP or PE bag.
Packing Details : Vacuum Packing with PE or PP bag , 10-50pcs/carton,or customized.
Shipping Details : 6 days after order be confirmed.
Loading
Glass wool roll in loading
Glass wool strip and plate in loading
Loading site
Glasswool Blanket Specification(Loadage advised) | ||||||||
Length | Width | Thickness | Density | Loadage | ||||
mm | mm | mm | Kg/m3 | Roll/HQ | ||||
10000 | 1200 | 180 | 16 | 273 | ||||
10000 | 1200 | 25 | 20 | 1260 | ||||
10000 | 1200 | 25 | 24 | 1050 | ||||
10000 | 1200 | 25 | 32 | 787 | ||||
10000 | 1200 | 25 | 40 | 630 | ||||
10000 | 1200 | 25 | 48 | 525 | ||||
10000 | 1200 | 30 | 16 | 1312 | ||||
10000 | 1200 | 50 | 12 | 1050 | ||||
10000 | 1200 | 50 | 16 | 787 | ||||
10000 | 1200 | 50 | 20 | 630 | ||||
10000 | 1200 | 50 | 24 | 525 | ||||
10000 | 1200 | 50 | 32 | 410 | ||||
10000 | 1200 | 50 | 40 | 298 | ||||
10000 | 1200 | 50 | 48 | 253 | ||||
Product | Length | Width | Thickness | Temperature | ||||
Glass wool board | 1200-3000 | 300-1200 | 15-100 | -120℃ to 350℃ | ||||
Glass wool Blanket | >6000 | 600-1200 | 25-150 | -120℃ to 350℃ | ||||
Glass wool Batt | 1000-1200 | ID (Customized) | 30-100 | -120℃ to 350℃ | ||||
Trade Assurance
Q:How to dealing with you for payment safety.
A: We are provide Alibaba Online Trade Assurance to make sure your ordering smoothly , payment safety
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.and with export dpt.
Q: How long is your delivery time?
A: Usually with 6 days to ship the goods out. and delivery time will according the address and time to choice the best delivery time for you.If by huge quantity,it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
