Shacman 4x2 6x4 Новый терминальный трактор для работы с

Shacman 4x2 6x4 Новый терминальный трактор для работы с

Категория: Truck >>>
Поставщик: Maxizm,Construction,Machinery,(Qingdao),Co.,Ltd.

Цена:63 500,00 $ - 67 850,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	75565.22 $*	79343.42 $*
Aug-15-2025	74930.93 $*	78677.68 $*
Jul-15-2025	62865.44 $*	66008.9 $*
Jun-15-2025	73660.87 $*	77343.67 $*
May-15-2025	64135.17 $*	67342.33 $*
Apr-15-2025	72390.77 $*	76010.59 $*
Mar-15-2025	71755.11 $*	75343.92 $*
Feb-15-2025	71120.52 $*	74676.78 $*
Jan-15-2025	70485.87 $*	74009.0 $*

Характеристики

Contact

Sales Manager
Eva Song

Maxizm Construction Machinery (Qingdao) Co., Ltd.

QQ/Wechat/ Mobile/ WhatsApp/ Skype: 008617865675208

Product Description

Feature：

* Rigid suspension:
Driven Axles and frame were directly connected ,not connected by springs and airbags
* Humanization Design
Air-bag seat, air-bag suspension and pneumatic unlocking saddles, etc., to minimize driver's driving intensity.

* High Quality
Considering on port’s tough environment, heavy workload, long-working time, complex operating situation, SHACMAN selected high quality hydraulic system components to make sure products reliability

* Safety
Complete vehicle protection warning system to ensure personnel and
driving safety.

* Reliability
Key assemblies and parts are selected from well-known brands
at home and abroad to ensure that vehicles are available 24 hours a
day, 7 days a week.

Specification

Model			Terminal Tractor with Cummins
Drive Type			4X2
Weight	Complete kerb mass(kg)	8500
	GCW(kg)	70000
Dimensions	Overall dimensions(LxWxH)(mm)	5280x2650x3360
	Wheel base(mm)	3200
Performance	Max speed(km/h)	46
	Minimum turning radius	7
	Max grade ability	18
Engine	Brand	Cummins
	Model	QSB6.7 C220 30
	Power(kw/HP)	163kw/220hp
	Max torque	949N-m/1500r/min
	Displacement	6.7L
	Emission Standards	Euro III
	Option	/
Transmission	Brand	USA Allison
	Model	3500 Hydraulic automatic transmission
Brakes	Type	Drum
	Service brake	Dual circuit brake
	Park brake	Spring energy storage expiation brake
Steering	Type	Hydraulic mechanical steering machine
	Option	ZF8098
Chassis	Type	Width slot frame,Outer width 850mm,the section of the longitudinal beam
	Dimensions(mm)	300mmx80mmx(10+10)mm
Suspension	Front suspension	Leaf spring,Absorber
	Rear suspension	Rigid Suspension
Axles	Brand	HANDE
	Front axle	7500kg
	Rear axle	16000kg,Port Axles,Central singe staged deceleration+wheel-side planetary reducer
	Ratio	Total speed ratio 11.98
Tires	Type	11.00R20
	Quantity	7
Fuel tank	Tank capacity(L)	200L aluminum alloy fuel tank+bumper
Electrics	Type	Single wire system 24V,Negative electrode
	Battery	Two DC 12V battery 2x180Ah
Cab	Type	RHD Terminal tractor cab
	Equipment	Large rear mirror and front under mirrorWindshield,wipe,glass cleanerManual drive type,electric tilting rotaryEngine tachometer,water temperature gauge,odometer,fuel meter,oil pressure gauge,pressure alarm,oil pressure alarm,steering indicator,reading light,reversing alarm yellow light alarm,LED work lampThe top setting air conditioner,central electrical box24 wireless terminal device for power line 24VWater bottle rack,fire extinguisher,a kick stand
Fifth wheel	Type	J0ST50 Fixed TypeOption:Lifting type

Recommend Products

Packing & Delivery

Company Profile

Our Company:
1. Professionally export construction machinery and spare parts for more than 12 years to over a hundred countries.
2. Experienced in customs clearance in different ports(countries). Clients type has big contractors, tender, private,rental
companies, construction companies etc.
3. Quick delivery time and thoughtful services.
