1080P 4CH AHD HDD/SSD  4G GPS WIFI  H.265/H.264 Mobile DVR,Monitor Available



Main features&Benefits

1.Wide voltage(8V ~ 32V DC)

2.Wide working temperature(-25 ~ 55°C)

3.H.264 video encoding, support 4CH realtime 1080P AHD input

4.Support local hard drive(hdd/ssd) to record and playback, maxium support 2TB hard drive.

5.Support to alarm for any coincidence like video loss or no hard drive and so on.

6.support multi-platform view(smartphone, PC,IE), do live streaming with 4G/WIFI

7.Ignition sensor that provides DVR power-on recording mode when the bus is started

8.Support prerecording and post recording.









 Detailed Specification for HDVR9804 series

SYSTEM	OS	Linux 3.18.20
	Booting Time	<20 s (From Powered on to start recording)
	Language	Chinese/English/Russian
	UI	GUI
	Encoder	H.264 Main/High Profile, Each camera HD 1080p30/720p30/540p30 recording
	Power	Power In: 8V ~ 32V DC,
		Power out for analog camera: 12V/3A (8cameras)
Video	Video Input	1x 1080p/720p/540p Digital Camera Recording, maximum for 8x 1080pAnalog/AHD cameras
	Video Output	2 Video Output (1 HDMI output, 1 CVBS output)
	Preview	Support FullScreen/Dual View/Quad View/4 Cameras
	Record Mode	Auto Record, Schedule Record, Alarm Record
	Record File	Record video and audio at same time
	Compression	H.264 (High profile up to level 4.1)
	Frame Rate	100fps@1080p
Audio	Audio Input	4 audio input (audio is built in the camera)
	Audio Compression	AAC (16bit, 48KHz) and PCM(According to the type of camera)
Video Process	Record Resolution	Support 1920x1080/1280x720/960x540(According to the type of camera)
	Bitrate	100~8000 kbps for each camera
	Storage	Support up to 6TB hard disk,one up to 256G SD card. SD card can be used as backup storage for hard disk when hard disk error
Alarm	Alarm Input	3 alarm sensors input, 1 speed input, 1 ignition input, 1 panic button alarm, 1 G-Sensor alarm
	Alarm Output	1 beeper, Alarm OSD
	Event	Video Loss Event, Over Speed Event, G-Sensor Event, Storage Event, Motion Detection Event, Panic button Event
Network	Protocol	TCP / IP
	3G/4G	Optional, build in 3G/4G(HSUPA/HSDPA/WCDMA/EVDO/TD-SCDMA/FDD-LTE/TDD-LTE)
	WIFI	Optional, support WIFI connection and AP
Location	Location	Location feature is optional, Support GPS/GLONASS/BEIDOU,recording location, speed, live tracking
Firmware	Frame Rate	Recording frame rate: 1~30fps selectable for each camera
	Firmware Upgrade	Can use hard disk/USB disk/SD card/remote upgrade via 4G
	G-Sensor	Support
	Play back	Support play back, file listed by time, alarm
	Play Speed	Support from 1/32 to 32
Software	hPlayer	Player software, play multiple cameras together, can also play the encrypted file
	CMSV6	Used for 4G/3G model only, support live view/live tracking/historical track/remote upgrade
Power Input	Power Input	8VDC~32VDC
Power Output	Power Output	Power output for cameras: 10.5V/3A (8 cameras)
ACC	<4.5V	Ignition Off
	>6.2V	Ignition ON
Power Control	Ignition	Turn on the DVR when ignition is on, can set DVR to turn off after a specified time when ignition is off
	Power Consumption	Less 5.0W (No camera power consumption included)
Working Condition	Working Temperature	-25 ~ 55°C
	Working Humidity	5%~93%
