Машина для лазерной резки металла оборудование промышленного
- Категория: Industry Laser Equipment >>>
- Поставщик: Wuxi,Sunway,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 3301.97 $* | 3367.79 $* |
| Jul-16-2025 | 2677.80 $* | 2731.12 $* |
| Jun-16-2025 | 3249.52 $* | 3314.65 $* |
| May-16-2025 | 3223.64 $* | 3287.58 $* |
| Apr-16-2025 | 2573.59 $* | 2624.55 $* |
| Mar-16-2025 | 3171.92 $* | 3234.24 $* |
| Feb-16-2025 | 3145.15 $* | 3208.97 $* |
| Jan-16-2025 | 3119.52 $* | 3181.26 $* |
Характеристики
Products Description
Configuration of 57 double motor X / Y-axis linear guide.Rapid cutting function for curved lines: any curved line can be cut successively and rapidly.
High-quality laser tube,laser power supply, reduce the failure rate.State light path to make sure the same output laser power from every site of working platform.Data outputis morefully due to high performance of RuiDa mainboard with anti-interference, and it has the function of the power cuts continued carving and slope carving.
Rotany carving fittings can be optional according to customer requirements, to solve the difficulties in carving for cylinder and irregular products.
Off-Line Functionality: RuiDa control panel can store 128MB of files, in the case of completely out of the computer,the user can selectfiles on the engraving machine , easy production of different products.Design software of CAD、AI、Coreldraw are all supported for friendly human-computer interface and demand of the industries on-the-spot.
Laser Head
Laser head can stop focus lens from polluting. Laser head will make effect of engraving and cutting better.
CO2 Laser Tube
Longer service life, more steady.
Higher effciency, high precision, small facula.
RUIDA Offline/M2 Main Board
RUIDA offline, superior control performance. engraving speed. Support engraving and cutting simultaneously. M2 using coreldraw software output.
The lens
Lens use frequently wipe can prolong life.
Generally about 1 year.
Linear quide rail with high precision , durable and stable. Not easy to deform.
Parameter Details
CO2 Laser Engraving Machine Features:
1. Automatic focus lens.
2. CO2 sealed laser tube including laser powers of 60 Watts, 80 Watts, 100 Watts, 130 Watts, 150 Watts, 180 Watts etc.
3. Honey comb table or knife table for option.
4. Profesional exhauster device and cooling device.
5. Transmit files directly in CorelDraw, AutoCAD, and more softwares.
6. The CO2 laser cutting machine adopts international linear rail with high precision.
7. The CO2 laser cutting machine owns functions of restoring from power off, continuation on break point.
Machine Size: | 3200*2010*1140(mm) |
Working Area: | 1300*2500(mm) |
Engraving Speed: | 1-1000mm/s |
Cutting Speed: | 1-300mm/s |
Engraving Thickness: | 0-2mm(depends on materials) |
Cutting Thickness: | 0-20mm(depends on materials) |
Water Protechion: | Yes |
Positioning Way: | Red Light Positioning |
Locating Precision: | ≤0.01mm |
Work Platform: | Honeycomb/Fixed/Lift platform |
Laser power: | 60W/80W/100W/130W/150W/180W/200W/300W |
Laser Type: | Sealed CO2 Laser Tube |
Cooling Mode: | Water Cooling Protection System |
Net Weight: | 840 KG |
Power Supply: | AC110-220V/50-60HZ(Custom Made) |
Packaging: | Standard Plywood Case |
Auxiliary Device: | Exhaust Fan, Exhaust Pipe,Water Pump,Air Pump,User Manual |
Optional Configuration
Simple Rotary Axis
Standard Rotary Axis
S & A Water Chiller（CW-3000/5000）
Accessories
(Warranty card、Water pump、Base(Four wheels)、USB cable etc.)
Application Industry
Applicable Materials
Wood, acrylic, stone, bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass, and other nonmetal materials.
Applicable Industries
Advertisements, gifts, crafts, arts, toys, shoes, computers, model making, garments, building, paper, packaging and printing.
Wood, acrylic, stone, bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass, and other nonmetal materials.
Applicable Industries
Advertisements, gifts, crafts, arts, toys, shoes, computers, model making, garments, building, paper, packaging and printing.
Applicable Materials | Cutting | Engraving |
Acrylic | Plexiglass | PMMA | Perspex | √ | √ |
Organic Board | Double Color Sheet | √ | √ |
Wood | Plywood | Veneer | MDF | Balsa | √ | √ |
Leather | PU | Shoe Material | Synthetic Leather | Genuine Leather | √ | √ |
Fabric | Cloth | Textile | √ | √ |
Carpet | Mat | Rug | Wool Felt | √ | √ |
Paper | Cardboard | Chipboard | Press Board | √ | √ |
Ceramic | Tile | Marble | Glass | × | √ |
Plastic | √ | √ |
Fiber Glass | Filter Cloth | √ | × |
Coated Metal/Anodized Metal | × | √ |
Cutting thickness of different laser power for reference | ||||||
Laser power(W) | Acrylic(mm) | Plywood(mm) | MDF(mm) | |||
40W | 3 | 2 | 1.5 | |||
60W | 8 | 5 | 3 | |||
80W | 12 | 8 | 6 | |||
100W | 15 | 12 | 9 | |||
150W | 25 | 20 | 15 | |||
*The above data is for reference only.
Customer Reviews
Company Profile
C O M P A N Y S T R E N G T H
------
Wuxi Sunway Technology Co.,Ltd.
Wuxi Sunway Technology Co.,Ltd is a professional manufacturer of laser engraving machine,laser cutting machine,fiber laser marking machine in China.
Sunway Laser focused on the development and production of various types of laser engraving/cutting/marking machine with the advanced management,strong research strength and steady globalization strategy, Sunway Laser establish more perfect product sales and service system in China and around the world, make the world's brand in laser industry.
Our target is "scientific management, high quality, high reputation and takes continuous development as our policy, regards customers as our center, double win with our customers", and we adhere to our tenet of "take the market demand as the guide, continue to take innovation and make improvement". We will try our best to provide the high quality products and perfect service for clients.
Furthermore,we pay much attention to after-sales service. Good service and good quality is same important for Sunway Laser will follow the spirit "Credibility and Integrity", try best to provide customer more super product and better service.
Sunway Laser--reliable professional Laser equipment supplier!
Welcome to cooperate with us and achieve win-win!
P R O D U C T I O N
------
Wuxi Sunway Technology Co.,Ltd.
O U R H O N O R
------
Wuxi Sunway Technology Co.,Ltd.
C U S T O M E R P H O T O S
------
Customer photo、Exhibition Photos.
S E R V I C E F L O W
------
Wholehearted service.
Fast delivery，Products will arrive to you in 3 days at the earliest .
FAQ
Q: Are you a manufacturer or trading company?
A:We are factory with professional production team and service consciousness just for
exporting various types of laser machine.
Q: Do you have after sales support?
A: Yes, we are available online to give guidance and also have skilled technicians to dispatch to customers’ factories.
Q: What's your payment terms ？
30% deposit is paid before production, the balance paid after inspection confirmation before shipment.
Q: What can you do if the machine broken?
A: The quality of our machines is very reliable. The warranty is one year after delivery, if some parts are broken,
we will send you new ones for free and customer affords the express cost. If some parts are broken out of warranty period, we will sell them at cost.
we will send you new ones for free and customer affords the express cost. If some parts are broken out of warranty period, we will sell them at cost.
Q: Will you deliver the right goods as ordered? How can I trust you?
A:Yes, we will. The core of our company culture is honesty and credit. Sunway is ALIBAB’s
Gold supplier with BV assessment and CE certificate.
Q: Do you sell only standard machines?
A:No, most of our machines are designed according to customers’ specifications, using
famous brand components.
Q: How to visit our company ？
Fly to Shanghai airport: By high speed train From Shanghai to Wuxi (30 min),then we can pick up you.
