Оптовая продажа стоячий вилочный погрузчик грузоподъемностью 2000 кг Штабелируемый
- Категория: Forklifts >>>
- Поставщик: Jiangsu,Zhongyan,Forklift,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 4641.41 $* | 4873.24 $* |
| Aug-18-2025 | 4602.12 $* | 4832.87 $* |
| Jul-18-2025 | 3861.36 $* | 4054.75 $* |
| Jun-18-2025 | 4524.36 $* | 4750.27 $* |
| May-18-2025 | 3939.33 $* | 4136.69 $* |
| Apr-18-2025 | 4446.75 $* | 4668.54 $* |
| Mar-18-2025 | 4407.23 $* | 4627.24 $* |
| Feb-18-2025 | 4368.91 $* | 4586.41 $* |
| Jan-18-2025 | 4329.42 $* | 4545.30 $* |
Характеристики
REACH STACKING FORKLIFT
2t 3t Electric Reach Stacker for Warehouse Container Narrow Aisle
Strong structure can realize stacking at a high-level position. Pedal arm protector and electric turning can ensure the safety and convenience during work.
Main Features for 2t 3t Electric Reach Stacker for Warehouse Container Narrow Aisle
1. Alternating driving system provide strong power to assure more accurate control and more stable operation.
2. Strong gear box to assure long working life span.
3. Hydraulic pressure station with frequently tested oil cylinder and pipeline can ensure high liability for the hydraulic system.
4. Adopt high quality US AMP waterproof connector and electronic parts to protect and fix all the wires and cables reliably, which greatly reduce electric malfunction.
5. H type channel steel panel frame with its flexural behavior reinforce the strength of whole panel frame, and strong base plate improve the stability and durability.
6. Innovative driving DFA system can ensure the stability of the truck when turning at a high speed.
7. Anti-explosive design for hydraulic system makes the panel frame decline slowly and improves the safety, even when the oil pipe is exploded.
8. Emergent reversing function will help the operator avoid being hurt. Emergency power off switch will cut off circuit if the operator is out of control, and avoid emergency accident.
9. Anti-skid brake function will prevent the truck from sliding down when the truck is out of control or driving on the slope.
10. Adopt international security design (two-way electric monitor sheering) system.
Technical Parameter for Stand type Counterbalance Electric Forklift
Model Parameter | CQD1030 | CQD1530 | CQD2030 |
Load Capacity(Kg) | 1000 | 1500 | 2000 |
Lift Height(m) | 3000 | 3000 | 3000 |
Load Center (mm) | 500 | 500 | 500 |
Fork Length (mm) | 1070 | 1070 | 1070 |
Lowest height(mm) | 100 | 100 | 100 |
Manipulation Way | Handler | Handler | Handler |
Tyres | Nylon/PU | Nylon/PU | Nylon/PU |
Dimension of Driving Wheel | 250*80 | 250*80 | 250*80 |
Speed at Full Load km/h | 5 | 4.5 | 4.5 |
Lifting Speed at full Load mm/sec | 90 | 85 | 85 |
Speed Control Way | Stepless Speed Regulation | Stepless Speed Regulation | Stepless Speed Regulation |
Door Frame Tilt Angle ° | 3~6 | 3~6 | 3~6 |
Gradient at full Load ° | 10 | 8 | 8 |
Battery V/Ah | 24/180 | 24/180 | 24/180 |
Working Time(for reference) (h) | 7 | 6 | 6 |
Driving Motor (kw) | 1.2 | 1.2 | 1.2 |
Lifting Motor (kw) | 2.2 | 2.2 | 3 |
The Min. Turning Inner Radius (mm) | 1450 | 1500 | 1500 |
L X W X H Dimension (mm) | 2350*1030*2080 | 2350*1030*2080 | 2400*1030*2080 |
weight(kg) | 1580 | 1680 | 1780 |
lifting Height at each weight (mm) | 1600/2000/2500/3000/3500 | ||
Height of Door Frame (mm) | 2100/1600/1850/2100/2350 | ||
Production Process
1. Located in Taixing Jiangsu province, with a 10+ years' professional experiences in forklift field
2. covering an area of 21,800 centiare.
3. Supply standard & customized design and manufacture for electric forklift, semi-electric forklift, reach forklift, manual forklift, electric stacker, hand pallet truck etc.
4. A complete set of quality control measures before delivery
5. Great after-sale services
Presale Service: We provide professional suggestions for different type of cargos and different apllication places;
After-sale services: We supply technical support via video and free accessories damaged during delivery.
Warranty Time: 1 YEAR, SIX Months for battery.
Contact Person: Thor Zhou
Tel&Wechat&Whatsapp:+8613815971521
