Four System Full Frequency Antenna Specification

General information:

Product name:Four System Full Frequency Antenna

Model:SHM-GNSS-R44Q6 Frequency:GPS L1/L2/L5,BDS B1/ B2/ B3,GLONASS L1/L2, Galileo E1/E2/E5a/E5b

Application: This antenna covered GPS L1/L2/L5, Beidou 2nd generation B1/ B2/ B3,GLONASS L1/L2 & Galileo E1/E2/E5a/E5b full frequency range external antenna, it can meet the request of multi-system compatibility and high precision measurement. It is widely used for Geodetic surveying and mapping, ocean surveying, geological deformation monitoring, small displacement, precision positioning, mobile mapping, larger engineering machinery control and precision agriculture and other fields.

Introduction :

Antenna part used multi-feed point design and perfectly symmetrical antenna structure, realize the coincidence of phase center and geometric center, to lower the influence to measurement error.

1.High gain, wide beam patter, has good receiving performance at low elevation, to ensure thenormal operation of satellite signal receiving in the place with serious shelter

2.Low noise amplifier section used front filtering solution, effectively suppress out-of-bandinterference and improve the reliability of the system.

3.Power supply circuit adopted with thunder protection design, which can effectively protect thelow noise amplifier, to insure the normal operation of antenna at terrible outdoorenvironment.

4.Inbuilt voltage stabilizer circuit, allow antenna to work normal at wide input voltage range.

5.IP68 waterproof design.
