3 тонн Колесный мини-самосвал 4 колеса с автоматической погрузчик на складе для сельское хозяйство сад

3 тонн Колесный мини-самосвал 4 колеса с автоматической погрузчик на складе для сельское хозяйство сад

Категория: Dump Trucks >>>
Поставщик: Jining,Aowei,Machine,Co.,Limited

Цена:1 500,00 $ - 3 000,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	1785.23 $*	1874.14 $*
Aug-17-2025	1770.99 $*	1859.84 $*
Jul-17-2025	1485.22 $*	1559.84 $*
Jun-17-2025	1740.31 $*	1827.82 $*
May-17-2025	1515.44 $*	1591.50 $*
Apr-17-2025	1710.9 $*	1796.70 $*
Mar-17-2025	1695.72 $*	1780.46 $*
Feb-17-2025	1680.14 $*	1764.92 $*
Jan-17-2025	1665.72 $*	1748.23 $*

Характеристики

Product Description

Specification

Model	FCY-10	FCY-20	FCY-30
Performance
Rated Loading Weight	1000KG	2000KG	3000KG
Bucket capacity	0.50m3	1. 2m3	1.50m3
Wheel base	1700mm	1280mm	1360mm
Thread	1300mm	1500mm	1960mm
Gradeability	21	21	21
Overall dimensions	260014502050mm	3017x1900x2465mm	3650x1800x2550mm
Mini turning radicus	3500mm	4000mm	4000mm
Walking speed
Forward gear 1	6.5km/h	6.5km/h	6.5km/h
Forward gear II	11km/h	11km/h	11km/h
Forward gear III	24km/h	24km/h	24km/h
Backward gear	4.5km/h	4.5km/h	4.5km/h
Engine
Engine model	ZS1100	CHANGCHAI390	Quanchai490
Engine type	3 cylinders	3 cylinders	4 cylinders
Cooler type	Water	Water	Water
Rated power	12.1KW	20KW	38KW
Tire size	Front tire 750-16 Rear tire 550-16	825-16	20.5/70-16

Model	FCY-50	FCY-70
Performance
Rated Loading Weight	5000kg	7000kg
Bucket capacity	2.5 m3	3.5 m3
Wheel base	2000mm	2200 mm
Thread	1580mm	1580 mm
Gradeability	21	21
Overall dimensions	430019202650 mm	525022502700 mm
Mini turning radicus	4000mm	4000mm
Walking speed
Forward gear 1	6.5km/h	6.5km/h
Forward gear II	11km/h	11km/h
Forward gear III	24km/h	24km/h
Backward gear	4.5km/h	4.5km/h
Engine
Engine model	Weichaihuafeng 4102	Yuchai 60kw engine
Engine type	4 cylinders	4 cylinders
Cooler type	Water cooler	Water cooler
Rated power	47kw	60kw
Tire size	14-17.5	16/70-20

Dimensions	12507001100mm	14507801100mm
Product weight	130kg	75kg
Safe load	600-700kg	600-700kg
Gradeability	35°	45°
Operating hours	8-10h	8-10h
Charging time	8h	7-8h
Battery	48V20AH*4	48V20AH*4
Motor	800W	800W

Details Images

Product Application

As a low-volume, short-distance transport of bulk materials for small site dumpers. Dumpers are widely used in many different occasions, such as the construction industry, the factory floor, battlefield ,protecting road section, the municipal engineering, underground mines and so on.

Packing & Delivery

Company Profile

Jining Aowei Machine Co., Ltd. is a modern enterprise which is specialized in producing all kinds of Mini excavators,Road
rollers,Self Dumpers ,Skid steer loaders, wheel loaders, Tractors and Forklifts etc. Our products are exported to clients in such countries and regions as United States, Southeast Asia, Australia, Europe, Russia, the Middle East, Africa. We also welcome OEM and ODM orders.Our company locates in Jining city, Shandong province, which is the "Home of Confucius and Mencius, the State of Etiquette”,and also Jining is one of four Chinese construction machinery bases famous of Shantui and Komatsu brand. Our company offers bulk export processing trade products, and other services to meet customer's needs.We hope to cooperate with you mutual success and we can be your trustworthy friend in the future!
