Glass Microballoon for resin filler Description:

Hollow glass Microsphere is a kind of hollow spherical powdery ultra-light inorganic non-metallic material. Its true density is 0.15-0.65g/cm³, particle size is 2-120μm, wall thickness is 1-2μm, and its compressive strength ranges 3-125MPa, it has the characteristics of light weight, large volume, low thermal conductivity, high compressive strength, and good fluidity. It is a product filler and lightening agent in paint coatings, rubber, modified plastics, glass fiber reinforced plastic, artificial stone, putty and other industries; In oil and gas field mining industries it can be used to produce cement slurry and drilling fluid with properties of high strength, high compressive,low density.



Glass Microballoon for resin filler Properties:

Pure white color, Hollow Glass Microsphere can be widely used in products which have high requirements for looks and colors.
Low density, reducing the products’basic weight obviously after filling. (the density of HGS is one out of a dozen of traditional filler particles' density). Relatively large volume, which can substitute and save more resins, reducing cost.

High dispersion and good fluidity, dimensional stability, reduced warpage and shrinkage when used as additives.
Heat insulation, sound insulation, mostly used as heat insulation paints and coatings, automotive sealants.
In addition, corrosion resistant, fire resistant, non-conducting.



Glass Microballoon for resin filler Chemical composition(%):

SiO2	58-71
Na2CO3	12-25
B2O3	3-12
Al2O3	0-10
CaO	0.2-1.0
Fe2O3	0-0.5
MgO	0-0.05



Glass Microballoon for resin filler Physical Index:

True Density	0.18-0.60g/cm3
Bulk Density	0.10-0.34g/cm3
Crush Strength	4-125Mpa/500-18000Psi
Survival	Min 90%
Flotation	Min 92%
Moisture	Max 0.5%
Particle Size	D50:20-70um
Max. Particle Size:	200um
Melting Point	1600°C



Glass Microballoon for resin filler Application:

Lightweight cement, low-density oil well cementing slurry & low-density drilling fluids additive.
Low-density FRP(fiberglass-reinforced plastic), SMC, BMC composites.
Nylon, PA, PA6, PA66 for reducing weight.
Low-density adhesives & sealants.
Heat insulation paints and coatings.
Construction (reducing warpage/shrinkage).
Insulation and Buoyancy.
Artificial marble.

Hollow glass microspheres can be used in paint and coatings, construction sealant, rubber, plastic, FRP, artificial stone, putty and other products as filler and weight-reducing agent. The glass bubbles can also be used to produce high-strength, low-density cement slurry and low-density drilling fluid in oil and gas extraction industry. more and more industries now trying to testing the hollow glass spheres as additives to improve their products' properties.



Available Sizes:

MODEL	True Density(g/cm3)	Bulk Density(g/cm3)	Compressive strength(Mpa/Psi)	D50(um)	D90(um)	Packing(Kgs)	Loose Bag(Kgs)
HL20	0.20-0.22	0.10-0.12	4/500	65	110	10	125
HL22	0.21-0.24	0.11-0.13	5/750	65	100	10	125
HL25	0.24-0.27	0.13-0.15	5/750	65	100	12.5	160
HL28	0.27-0.30	0.14-0.17	10/1500	55	85	15	180
HL30	0.29-0.32	0.15-0.18	10/1500	55	85	15	180
HL32	0.31-0.33	0.17-0.19	14/2000	45	80	15	200
HL35	0.33-00.37	0.18-0.21	21/3000	40	70	15	250
HL38	0.37-0.39	0.19-0.22	38/5500	40	65	20	250
HL40	0.39-0.42	0.19-0.23	28/4000	40	70	20	250
HL42	0.41-0.44	0.21-0.24	55/8000	40	60	20	270
HL46	0.44-0.48	0.23-0.26	41/6000	40	70	22.5	300
HL50	0.48-0.52	0.25-0.27	55/8000	40	60	25	320
HL55	0.53-0.55	0.27-0.29	68/10000	40	60	25	350
HL60	0.58-0.62	0.29-0.34	83/12000	40	65	30	400
HL60S	0.58-0.63	0.30-0.34	125/18000	35	55	30	400
HS38	0.37-0.39	0.19-0.22	38/5500	30	50	20	250
HS42	0.40-0.44	0.21-0.24	55/8000	25	40	20	250
HS46	0.44-0.48	0.22-0.25	110/16000	20	30	22.5	300
HS60	0.58-0.62	0.27-0.30	193/28000	16	25	30	400
HS65	0.63-0.67	0.25-0.27	207/30000	13	20	32	430
HS70	0.68-0.72	0.25-0.27	207/30000	10	15	35	460
