Anlaitech modular clean room design allows it to be used as either a totally freestanding room or it can be used in combination with your existing walls and ceiling. Each room comes completely factory prefabricated for minimal on-site erection time and is totally self-contained with all components factory-finished. A major advantage to the anlaitech modular cleanroom is its ability to be enlarged or reduced. Wall panels and ceiling grids can easily be added or removed as future needs dictate. The anlaitech modular clean room is almost 100% reusable.





Features:



(1) Assembly structure designed, easy installation and easily moved

(2) Directional wheels can be installed, suitable for small building and high cleanliness area;

(3) Modular design: clean booth can be as small as several square meters and can be as large as hundreds of square meters

(4) It has large useful and effective area; while compared with traditional clean room, it has such features like low investment, high return and stable.



CLASS A/ISO5/CLASS100 CLEAN ROOM
Model	ALCSA2*3	ALCSA3*4	ALCSA4*6	ALCSA6*8
External Size (W×D×H)mm	2100×3100×2800	3100×4100×2800	4100×6100×2800	6100×8100×2800
Internal Work Zone (W×D×H)mm	2000×3000×2400	3000×4000×2400	4000×6000×2400	6000×8000×2400
QTY of FFUS	6PCS	12PCS	20PCS	40PCS
AIR VOLUME(m3/h)	7200	14400	24000	48000
Total Power	0.7KW	1.4KW	2.3KW	4.6KW



CLASSIC PROJECT FOR CLASS 100 REFER:



CLASS B/ISO6/CLASS1000 CLEAN ROOM
Model	ALCSB3*4	ALCSB4*6	ALCSB6*6	ALCSB6*8
External Size (W×D×H)mm	3100×4100×2800	4100×6100×2800	6100×6100×2800	6100×8100×2800
Internal Work Zone (W×D×H)mm	3000×4000×2400	4000×6000×2400	6000×6000×2400	6000×8000×2400
QTY of FFUS	4PCS	8PCS	12PCS	15PCS
AIR VOLUME(m3/h)	4800	9600	14400	18000
Total Power	0.5KW	1KW	1.4KW	1.8KW



CLASSIC PROJECT FOR CLASS1000 REFER:





CLASS C/ISO7/CLASS10000 CLEAN ROOM
Model	ALCSC4*6	ALCSC4*8	ALCSC6*9	ALCSC6*12
External Size (W×D×H)mm	4100×6100×2800	4100×8100×2800	6100×9100×2800	6100×12100×2800
Internal Work Zone (W×D×H)mm	4000×6000×2400	4000×8000×2400	6000×9000×2400	6000×12000×2400
QTY of FFUS	4PCS	6PCS	9PCS	12PCS
AIR VOLUME(m3/h)	4800	7200	10800	14400
Total Power	0.5KW	0.7KW	1.1KW	1.4KW



CLASSIC PROJECT FOR CLASS10000 REFER:





CLASS D/ISO8/CLASS100000 CLEAN ROOM
Model	ALCSD4*6	ALCSD4*8	ALCSD6*9	ALCSD6*12
External Size (W×D×H)mm	4100×6100×2800	4100×8100×2800	6100×9100×2800	6100×12100×2800
Internal Work Zone (W×D×H)mm	4000×6000×2400	4000×8000×2400	6000×9000×2400	6000×12000×2400
QTY of FFUS	2PCS	3PCS	4PCS	6PCS
AIR VOLUME(m3/h)	2400	3600	4800	7200
Total Power	0.5KW	0.8KW	1KW	1.2KW



 CLASSIC PROJECT FOR CLASS 100,000 REFER:



WELCOME TO VISIT US:





Factory testing:



All of equipment is individually factory tested for safety and performance in accordance with international Standards. Each unit is shipped with a documentation outlining the tests undertaken and the unit’s individual results for each unit.



Factory test include:



--appearance testing

--functional test and visual inspection

--electrical safety tests

 --air velocity testing

--noise testing

Standard export packing:



--Stretch film strapped whole cabinet,

--Foam inside protected,

--Plywood case solid fixed

--European standard bottom tray

CUSTOMER FEEDBACK

Warranty:



Our equipment is warranty for 1 year excluding consumable parts and accessories.

All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.

Additional IO/OQ/GMP document is available upon request.

Contact our sales representative for specific warranty details or document request.
