Polycarbonate solid sheet      Product Standard & Technical Parameters
Thickness(mm)	Weight(kg/m2)	Mini-bending radius(mm)	Width(m)	Length(m)	Colour
1.1	1.32	234	1.22-2.1	no limited,It can be rolled like 30 meter	Clear, Green, Blue ,Brown ,Opal ,Red ,Yellow.
2	2.4	360	1.22-2.1
3	3.6	540	1.22-2.1
4	4.8	720	1.22-2.1
5	6	900	1.22-2.1	≤5.8m for 20ft, ≤11.8m for 40ft
6	7.2	1080	1.22-2.1
8	9.6	1440	1.22-2.1
10	12	1800	1.22-2.1
12	14.4	2250	1.22-2.1
15	18	2700	1.22-2.1
Technical Parameters
Impact strength	Transparency	Specific grevity	Coefficient of thermal expansion	Service temperature	Heat conductivity
35j/m	72%-90%	1200kg/m³	0.065mm/m°C	-40°C—120°C	0.21w/m²°C
Tensile strength	Flexural strength	Modulus of elasticity	Effect of sound insulation	Tensile stress at break	Elongation at break
≥60N/mm	100N/mm²	2400Mpa	28 decibel decrease for 3mm solid sheet
packaging	Both sides with PE film, the end with paper tape, logo on the pe film. Other package are available based on customers' requirement.
delivery	7-10 days after receipt of deposit.
capacity for 20 GP	1.1mm: 12878m²			6mm: 2361m²
	2mm: 7083m²			8mm: 1770m²
	3mm: 4722m²			10mm: 1416m²
	4mm: 3541m²			12mm: 1180m²
	5mm: 2833m²			15mm: 944m²
capacity for 40GP	1.1mm: 16666m²			6mm: 3055m²
	2mm: 9166m²			8mm: 2291m²
	3mm: 6111m²			10mm: 1833m²
	4mm: 4583m²			12mm: 1527m²
	5mm: 3666m²			15mm: 1222m²
capacity for 40HQ	1.1mm: 21212m²			6mm: 3888m²
	2mm: 11666m²			8mm: 2916m²
	3mm: 7777m²			10mm: 2333m²
	4mm: 5833m²			12mm: 1944m²
	5mm: 4666m²			15mm: 1555m²
Brief introduction
A. Product Range
1).Twin-walls polycarbonate sheet thickness: 4,6,8,10,12 Width: 2100mm.
2).Triple-walls polycarbonate sheet thickness: 8,10,12,14,16. Width: 2100mm.
3).Four-walls polycarbonate sheet thickness: 8,10,12,14,16,18,20mm. Width: 2100mm.
4).Honeycomb polycarbonate sheet thickness: 6,8,10,12,14mm. Width: 2100mm.
5).X-structure polycarbonate sheet thickness: 14,16,18,20,25,30mm.
6).Solid polycarbonate sheet [Compact] thickness:0.9-8.0mm.
Width: 1220,1560,1820,2100mm.Usually 1220*2440mm, 2050*3000mm
7).Corrugated polycarbonate sheet: 0.8-2.5mm. Width is different.
B.Length: No limit(Recommend 5800, 6000, 11800,12000mm to suit 20'container &40'container).
C.Color: clear/transparent, lake blue, green, blue, opal, white, brown/bronze, silvery gray, red, yellow, etc.









4.Application

5.Main Products

6.Our Advantages

1.Good light transmission

2.Light weight and impact resistance

3.Sound insulation and Flame retardant

4.Excellent energy saving effect

5.Weather resistance(anti-fog/drop)

6.10 years of quality assurance

7.Product Line

8.Company Show

9.Packaging & Shipment

Delivery time
Generally 15 working days after the order confirmed

Packaging
1) Custom package request is appreciate.
2) Standard package:  Both Sides Covered With PE Film



10.FAQ

1. Are you manufacturer or Trade Company?
We are professional factory, founded in 1996.OEM is acceptable

2. What's the order process?
a. Inquiry---provide us all clear requirements.
b. Quotation---official quotation form with all clear specifications.
c. Customization--- We offers ultimate customization and personalized solutions.
d. Sample ---Standard sample of our factory.
e. Payment terms--- T/T 30% in advanced, balanced before shipment.
f. Production---mass production
g. Shipping--- by sea, air or courier. Detailed picture of package will be provided.

3. What terms of payment you use?
T/T, PayPal, Western Union

4. Do you have any instant chat tool?
E-mail: hzsn(at)hzsn.com.cn
