Julong Us-400s ультразвуковой датчик края Электрический

Description:

The US-400S is made of high-grade aerospace aluminum casing, which is sturdy and beautiful, and can enhance enhance the appearance of the equipment; 200K is emitted ultrasonic sensor, 1ms reaction time, with offset display.

Fully enclosed ultrasonic probe for use in a variety of harsh environments;

Suitable for opaque, transparent, ultra-transparent film edge-trimming applications, no manual adjustment and calibration, detection range of 5mm, detection accuracy of 0.05mm.

Specification:

Name: Ultrasonic sensor US-400S

Tracking method:Side tracking

Power input: DC12V

Output signal: 0-5V

Detection range: 6mm (+-3mm)

Detection accuracy: +-0.05mm

Shell material:Aluminum alloy

Weight: 250g

Features:

1. support the output of analog quantity/switch value, can match with EPC-A10 and EPC-D12 Deviation Rectification Controller


2. applicable for the edge-following of non-transparent materials, transparent materials, ultra-transparent thin film


3. no need to perform the manual adjustment


4. 200K ultrasonic exposure


5. 1ms responding time


6. detective range: 5mm, detective accuracy :0.1mm


7. offset display attached
