C1000-16P-E-2G-L C1000 16 портов GE 2x1G SFP POE Ente rprise класса слой
- Категория: Network Switches >>>
- Поставщик: Henan,Juetai,Information,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.48 $* | 0.6 $* |
| Aug-17-2025 | 0.87 $* | 0.36 $* |
| Jul-17-2025 | 0.79 $* | 0.78 $* |
| Jun-17-2025 | 0.36 $* | 0.82 $* |
| May-17-2025 | 0.44 $* | 0.31 $* |
| Apr-17-2025 | 0.32 $* | 0.41 $* |
| Mar-17-2025 | 0.53 $* | 0.48 $* |
| Feb-17-2025 | 0.71 $* | 0.96 $* |
| Jan-17-2025 | 0.87 $* | 0.44 $* |
Характеристики
contact us
E-mail:
alex@juetaiit.com
Skype:
8613260435040
Whatsapp/WeChat:
8613260435040
Product Description
Specification
Cisco Catalyst 1000 Series Switches feature:
● 8, 16, 24, or 48 Gigabit Ethernet and 24, 48 port Fast Ethernet data or PoE+ ports with line-rate forwarding
● 2 or 4 fixed 1 Gigabit Ethernet Small Form-Factor Pluggable (SFP)/RJ 45 Combo uplinks (8 Port models only) or 4 fixed 10 Gigabit
Ethernet Enhanced SFP (SFP+) uplinks on the Gigabit Ethernet models and 4 fixed 1 Gigabit Ethernet Small Form- Factor Pluggable
(SFP) and 2 RJ 45 Combo uplinks on the Fast Ethernet models
● Perpetual PoE+ support with a power budget of up to 740W
● CLI and/or intuitive web UI manageability options
● Network monitoring through sampled flow (sFlow)
● Security with 802.1X support for connected devices, Switched Port Analyzer (SPAN), and Bridge Protocol Data Unit (BPDU) Guard
● Compact fanless models available with a depth of less than 13 inches (33 cm)
● Device management support with over-the-air access via , Simple Network Management Protocol (SNMP), RJ- 45, or USBconsole acces
● Reliability with a higher Mean Time Between Failures (MTBF) and an Enhanced Limited Lifetime Warranty support (E-LLW)
● 8, 16, 24, or 48 Gigabit Ethernet and 24, 48 port Fast Ethernet data or PoE+ ports with line-rate forwarding
● 2 or 4 fixed 1 Gigabit Ethernet Small Form-Factor Pluggable (SFP)/RJ 45 Combo uplinks (8 Port models only) or 4 fixed 10 Gigabit
Ethernet Enhanced SFP (SFP+) uplinks on the Gigabit Ethernet models and 4 fixed 1 Gigabit Ethernet Small Form- Factor Pluggable
(SFP) and 2 RJ 45 Combo uplinks on the Fast Ethernet models
● Perpetual PoE+ support with a power budget of up to 740W
● CLI and/or intuitive web UI manageability options
● Network monitoring through sampled flow (sFlow)
● Security with 802.1X support for connected devices, Switched Port Analyzer (SPAN), and Bridge Protocol Data Unit (BPDU) Guard
● Compact fanless models available with a depth of less than 13 inches (33 cm)
● Device management support with over-the-air access via , Simple Network Management Protocol (SNMP), RJ- 45, or USBconsole acces
● Reliability with a higher Mean Time Between Failures (MTBF) and an Enhanced Limited Lifetime Warranty support (E-LLW)
Product ID* | Gigabit Ethernet / FE ports | Uplink interfaces | PoE+power budget | Fanless | Dimensions (WxDxH in inches) | Weight (kg) |
C1000-8T-2G-L | 8 10/100/1000 RJ45 Data | 2 SFP/ RJ-45 combo | – | Y | 10.56 x 7.28 x 1.73 | 1.80 |
C1000-8T-E-2G-L | 8 10/100/1000 RJ45 Data | 2 SFP/ RJ-45 combo | – | Y | 10.56 x 7.28 x 1.73 | 1.55 |
C1000-8P-2G-L | 8 10/100/1000 RJ45 PoE+ | 2 SFP/ RJ-45 combo | 67W | Y | 10.56 x 12.73 x 1.73 | 1.55 |
C1000-8P-E-2G-L | 8 10/100/1000 RJ45 PoE+ | 2 SFP/ RJ-45 combo | 67W | Y | 10.56 x 7.28 x 1.73 | 1.55 |
C1000-8FP-2G-L | 8 10/100/1000 RJ45 PoE+ | 2 SFP/ RJ-45 combo | 120W | Y | 10.56 x 12.73 x 1.73 | 2.70 |
C1000-8FP-E-2G-L | 8 10/100/1000 RJ45 PoE+ | 2 SFP/ RJ-45 combo | 120W | Y | 10.56 x 7.28 x 1.73 | 2.70 |
C1000-16T-2G-L | 16 10/100/1000 RJ45 Data | 2 SFP | – | Y | 10.56 x 10.69 x 1.73 | 1.78 |
C1000-16T-E-2G-L | 16 10/100/1000 RJ45 Data | 2 SFP | - | Y | 10.56 x 8.26x 1.73 | 1.42 |
C1000-16P-2G-L | 16 10/100/1000 RJ45 PoE+ | 2 SFP | 120W | Y | 10.56 x 11.69 x 1.73 | 2.38 |
C1000-16P-E-2G-L | 16 10/100/1000 RJ45 PoE+ | 2 SFP | 120W | Y | 10.56 x 8.26x 1.73 | 1.42 |
C1000-16FP-2G-L | 16 10/100/1000 RJ45 PoE+ | 2 SFP | 240W | Y | 10.56 x 12.14 x 1.73 | 2.49 |
C1000-24T-4G-L | 24 10/100/1000 RJ45 Data | 4 SFP | - | Y | 17.48 x 9.45 x 1.73 | 2.63 |
C1000-24P-4G-L | 24 10/100/1000 RJ45 PoE+ | 4 SFP | 195W | Y | 17.48 x 11.76 x 1.73 | 3.53 |
C1000-24FP-4G-L | 24 10/100/1000 RJ45 PoE+ | 4 SFP | 370W | N | 17.48 x 13.59 x 1.73 | 4.6 |
C1000-48T-4G-L | 48 10/100/1000 RJ45 Data | 4 SFP | - | N | 17.48 x 11.34 x 1.73 | 3.95 |
C1000-48P-4G-L | 48 10/100/1000 RJ45 PoE+ | 4 SFP | 370W | N | 17.48 x 13.78 x 1.73 | 5.43 |
C1000-48FP-4G-L | 48 10/100/1000 RJ45 PoE+ | 4 SFP | 740W | N | 17.48 x 13.78 x 1.73 | 5.82 |
C1000-24T-4X-L | 24 10/100/1000 RJ45 Data | 4 SFP+ | - | Y | 17.48 x 9.45 x 1.73 | 2.78 |
C1000-24P-4X-L | 24 10/100/1000 RJ45 PoE+ | 4 SFP+ | 195W | Y | 17.48 x 11.76 x 1.73 | 3.68 |
C1000-24FP-4X-L | 24 10/100/1000 RJ45 PoE+ | 4 SFP+ | 370W | N | 17.48 x 13.59 x 1.73 | 4.6 |
C1000-48T-4X-L | 48 10/100/1000 RJ45 Data | 4 SFP+ | - | N | 17.48 x 11.34 x 1.73 | 3.95 |
C1000-48P-4X-L | 48 10/100/1000 RJ45 PoE+ | 4 SFP+ | 370W | N | 17.48 x 13.78 x 1.73 | 5.43 |
C1000-48FP-4X-L | 48 10/100/1000 RJ45 PoE+ | 4 SFP+ | 740W | N | 17.48 x 13.78 x 1.73 | 5.82 |
C1000FE-24T-4G-L | 24 10/100 RJ45 Data | 2 SFP/ RJ-45 combo and 2 SFP | - | Y | 17.32 x 11.34 x 1.73 | 3.56 |
C1000FE-24P-4G-L | 24 10/100 RJ45 PoE+ | 2 SFP/ RJ-45 combo and 2 SFP | 195W | Y | 17.48 x 13.78 x 1.73 | 4.52 |
C1000FE-48T-4G-L | 48 10/100 RJ45 Data | 2 SFP/ RJ-45 combo and 2 SFP | - | N | 17.32 x 11.34 x 1.73 | 3.97 |
C1000FE-48P-4G-L | 48 10/100 RJ45 PoE+ | 2 SFP/ RJ-45 combo and 2 SFP | 370W | N | 17.48 x 13.78 x 1.73 | 5.46 |
8-port models | 16-port models | 24-port models (1/10G uplinks) | 48-port models (1/10G uplinks) | |||||||||||||||
Console ports | ||||||||||||||||||
RJ-45 Ethernet | 1 | 1 | 1 | 1 | ||||||||||||||
USB mini-B | 1 | 1 | 1 | 1 | ||||||||||||||
USB-A port for storage and console | 1 | 1 | 1 | 1 | ||||||||||||||
Memory and processor | ||||||||||||||||||
CPU | ARM v7 800 MHz | ARM v7 800 MHz | ARM v7 800 MHz | ARM v7 800 MHz | ||||||||||||||
DRAM | 512 MB | 512 MB | 512 MB | 512 MB | ||||||||||||||
Flash memory | 256 MB | 256 MB | 256 MB | 256 MB | ||||||||||||||
Performance | ||||||||||||||||||
Forwarding bandwidth | 10 Gbps | 18 Gbps | FE: 6.4 Gbps 1G: 28 Gbps 10G: 64 Gbps | FE: 8.8 Gbps 1G: 52 Gbps 10G: 88Gpbs | ||||||||||||||
Switching bandwidth | 20 Gbps | 36 Gbps | FE: 12.8 Gbps 1G: 56 Gbps 10G: 128 Gbps | FE: 17.6 Gbps 1G: 104 Gbps 10G: 176 Gbps | ||||||||||||||
Forwarding rate (64‑byte L3 packets) | 14.88 Mpps | 26.78 Mpps | FE: 9.52 Mpps 1G: 41.67 Mpps 10G: 95.23 Mpps | FE: 13.09 Mpps 1G: 77.38 Mpps 10G: 130.94 | ||||||||||||||
MAC addresses | 16000 | 16000 | 16000 | 16000 | ||||||||||||||
IPv4 unicast direct routes | 542 | 542 | 542 | 542 | ||||||||||||||
IPv4 unicast indirect routes | 256 | 256 | 256 | 256 | ||||||||||||||
IPv6 unicast direct routes | 414 | 414 | 414 | 414 | ||||||||||||||
IPv6 unicast indirect routes | 128 | 128 | 128 | 128 | ||||||||||||||
IPv4 multicast routes and IGMP groups | 1024 | 1024 | 1024 | 1024 | ||||||||||||||
IPv6 multicast groups | 1024 | 1024 | 1024 | 1024 | ||||||||||||||
IPv4/MAC security ACEs | 600 | 600 | 600 (FE: 384) | 600 (FE: 384) | ||||||||||||||
IPv6 security ACEs | 600 | 600 | 600 (FE: 256) | 600 (FE: 256) | ||||||||||||||
Maximum active VLANs | 256 | 256 | 256 | 256 | ||||||||||||||
VLAN IDs available | 4094 | 4094 | 4094 | 4094 | ||||||||||||||
Maximum STP instances | 64 | 64 | 64 | 64 | ||||||||||||||
Maximum SPAN sessions | 4 | 4 | 4 | 4 | ||||||||||||||
MTU-L3 packet | 9198 bytes | 9198 bytes | 9198 bytes | 9198 bytes | ||||||||||||||
Jumbo Ethernet frame | 10,240 bytes | 10,240 bytes | 10,240 bytes | 10,240 bytes | ||||||||||||||
Dying Gasp | Yes | Yes | Yes (FE: No) | Yes (FE: No) | ||||||||||||||
MTBF in hours (data) | 2,171,669 | 2,165,105 | 2,026,793 | 1,452,667 | ||||||||||||||
MTBF in hours (PoE) | 1,786,412, 1,706,649 (External PS) | 706,983 | 698,220 | 856,329 | ||||||||||||||
MTBF in hours (Full PoE) | 1,706,649 | - | 698,220 | 856,329 | ||||||||||||||
