GMC-18 18A 220V переменного тока 3-полюсный контактор MC GMC
- Категория: Contactors >>>
- Поставщик: Yueqing,Yileke,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 2.57 $* | 2.19 $* |
| Aug-16-2025 | 2.52 $* | 2.78 $* |
| Jul-16-2025 | 2.22 $* | 2.26 $* |
| Jun-16-2025 | 2.82 $* | 2.21 $* |
| May-16-2025 | 2.1 $* | 2.88 $* |
| Apr-16-2025 | 2.13 $* | 2.21 $* |
| Mar-16-2025 | 2.0 $* | 2.27 $* |
| Feb-16-2025 | 2.51 $* | 2.32 $* |
| Jan-16-2025 | 2.77 $* | 2.63 $* |
Характеристики
GMC-18 18A 220V 3pole ac contactor NC CONTACTOR GMC CONTACTOR
Product Description
220V Coil 65A ac contactor GMC-220V
APPLI8CATION
GMC Series AC Contactor is suitable for using in the circuits up to the rated voltage 660V AC 50HZ or 60HZ, rated current up to 800A, for making frequently starting & controlling the AC motor. Combined with the auxiliary contact block, thermal relay & machine-interlocking device etc, it becomes the delay contactor, mechanical interlocking contactor, star-delta starter. With the thermal relay, it is combined into the electromagnetic starter.
SPECIFICATION
| Type | Ac1 duty | AC3 duty | Life time(×104 | Aux.contact | ||||
| 200-240V | 380-440V | 500-550V | 690V | Electrical | Machanica | |||
| GMC-9 | 20A | 2.5KW 11A | 5KW 9A | 4KW 7A | 4KW 9A | 250 | 2500 | INO INC |
| GMC-12 | 20A | 3.5KW 13A | 5.5KW 12A | 7.5KW 9A | 7.5KW 9A | 250 | 2500 | |
| GMC-18 | 25A | 4.5KW 18A | 7.5KW 18A | 7.5KW 13A | 7.5KW 9A | 250 | 2500 | |
| GMC-22 | 32A | 5.5KW 22A | 11KW 22A | 15KW 22A | 15KW 9A | 250 | 2500 | |
| GMC-32 | 50A | 7.5KW 32A | 15KW 32A | 18.5KW28A | 18.5KW9A | 200 | 1500 | 2NO 2NC |
| GMC-40 | 60A | 11KW 40A | 18.5KW40A | 22KW 32A | 22KW 9A | 200 | 1500 | |
| GMC-50 | 80A | 15KW 55A | 22KW 50A | 30KW 43A | 30KW 9A | 200 | 1000 | |
| GMC-65 | 100A | 18KW 65A | 30KW 65A | 37KW 60A | 37KW 9A | 200 | 1000 | |
| GMC-75 | 110A | 22KW 75A | 37KW 75A | 45KW 64A | 45KW 9A | 200 | 1000 | |
| GMC-85 | 135A | 25KW 85A | 45KW 85A | 45KW 75A | 45KW 9A | 200 | 1000 | |
| GMC100 | 150A | 30KW105A | 55KW 105A | 55KW 85A | 55KW 9A | 200 | 1000 | |
| GMC125 | 150A | 37KW125A | 60KW 120A | 60KW 90A | 60KW 9A | 200 | 1000 | |
| GMC150 | 200A | 40KW150A | 75KW | 80KW100A | 90KW 9A | 200 | 1000 | |
GMC 20
