UL1569 28 AWG stranded copper pvc flexible cable

All our wires and cables are made of 99.99% pure oxygen free copper and high quality PVC which comply with the European UnionRoHS environmental protection instruction.

Specification:UL 1569

Rated temperature: 105°C

Rated voltage: 300V

Reference Standard: UL758

Conductor:  stranded  tinned  copper conductor

Insulation: PVC insulation, comply with ROHS environmental standard

Flame Retardant Test: UL VW-1, CSA FT1 flame Test

Uniform thickness to ensure stripping and cutting easily

Applied into electrical equipments as internal wire

MARKING:

E330446   AWM STYLE 1569 AWG NO. 105°C 300V VW-1 ---  AWM I A 105°C 300V FT1 RoHS COMPLIANT DANYANG WINPOWER



CONDUCTOR			INSULATION		MAX.COND. RESISTANCE  (Ω/km,20°C,DC)	DIELECTRIC STRENGTH (VAC,1min)
AWG	CONSTRUCTION (No./mm)	DIA. (mm)	THICKNESS (mm)	O.D. (mm)
30	1/0.254	0.25	0.40	1.05	361	2000
	7/0.10	0.30	0.40	1.10	381
28	1/0.32	0.32	0.39	1.10	227	2000
	7/0.127	0.38	0.41	1.20	239
26	1/0.404	0.40	0.43	1.25	143	2000
	7/0.16	0.48	0.41	1.30	150
24	1/0.511	0.51	0.42	1.35	89.3	2000
	11/0.16	0.61	0.40	1.40	94.2
22	1/0.643	0.64	0.43	1.50	56.4	2000
	17/0.16	0.76	0.42	1.60	59.4
20	1/0.813	0.81	0.42	1.65	35.2	2000
	26/0.16	0.94	0.43	1.80	36.7
18	1/1.024	1.02	0.41	1.85	22.2	2,000
	41/0.16	1.18	0.46	2.10	23.2
16	1/1.29	1.29	0.46	2.20	14.0	2,000
	26/0.254	1.49	0.46	2.40	14.6
14	1/1.60	1.60	0.45	2.50	8.78	2,000
	41/0.254	1.88	0.41	2.70	8.96
12	65/0.254	2.36	0.42	3.20	5.64	2,000
10	105/0.254	3.42	0.44	4.30	3.54	2,000







     Q: Are you manufacturer or trading company?

     A: We are the factory who specialize in the production of ul electrical wire,automotive wire

          building wire , motor lead wire and solar cable since 2009.



     Q: How can I go to your factory?

     A: We are located in Lingkou Industrial Park , Danyang City , Jiangsu Province , China.

          There’re tow kind transportation methods.

          1) Flight to Shanghai , and aboard one-hour Harmony train from Shanghai Station to

          Danyang  Station.

          2)Flight to Changzhou , and aboard 20-minute Harmony train from Changzhou Station to

          Danyang Station.



     Q: Can you show us your products test report?

     A: Of course . I can e-mail the copy one to you.

         Our products have passed RoHS & REACH test.



     Q: Can I have the sample?

     A:  Yes . The free samples are available . You just need to afford the freight cost.



     Q: How long can I expect to get the samples?

     A:  If there’ stock , it can be delivered within 1 day . If not , it will be 3-5 days.



     Q: OEM can be accepted?

     A:  Yes , it can be accepted.



     Q: Some special wire can be producted?

     A:  Yes , we can do the customer wire according to your drawings or specifications.



     Q: What’s your delivery time?

     A:  It depends on your quantity.
