Пассивный сетевой коммутатор 24 в 4 8 10/100M Af/At неуправляемый Промышленный Ethernet
- Категория: Network Switches >>>
- Поставщик: Shanghai,Kuanyu,Industrial,Network,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 24.99 $* | 25.54 $* |
| Aug-18-2025 | 24.76 $* | 25.80 $* |
| Jul-18-2025 | 20.34 $* | 21.78 $* |
| Jun-18-2025 | 23.44 $* | 24.58 $* |
| May-18-2025 | 20.84 $* | 21.94 $* |
| Apr-18-2025 | 23.28 $* | 24.1 $* |
| Mar-18-2025 | 23.17 $* | 24.40 $* |
| Feb-18-2025 | 22.13 $* | 23.76 $* |
| Jan-18-2025 | 22.78 $* | 23.71 $* |
Характеристики
Product Description
Automatically detecting and supplying power for powered devices conformed to IEEE 802.3af/at PoE++/HiPoE, Kemyond unmanaged PoE switch(Ai-version) has new functions of HiPoE and PoEdog that can efficiently solve the power-supply problems of high-power devices like high-power dome cameras and wireless access point AP and achieve auto restore when the machine breaks down.Similarly, it can solve the problems that restart the machine annually on the spot and installation requirements on multiple switches.
Specification
Model | S600P-4F-2F-Ai |
Product | 4Port Fast Ethernet PoE Switch |
Fixed Port | 4*10/100Base-TX PoE port（Data/Power） 2*10/100Base-TX uplink RJ45 port(Data) |
PoE Ports | 1-4 port supports PoE(first port outputs HiPoE_60W) |
Function | N:(Standard normal) V:(Port isolation) S:(Ultral-far mode)（specific port refers to user manual） |
Ai version:PoE auto execution、detection and resets fault device, when PoE is on. | |
Network Protocol | IEEE 802.3 IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3x IEEE 802.3af/at/PoE++ hasivo HiPoE |
PoE Standard | IEEE802.3af/at/PoE++/HiPoE |
Port Specification | 10/100BaseT（X）Auto |
Transmission Mode | Store and Forward(full wirespeed) |
Bandwidth | 1.6Gbps |
Packet Forwarding | 1.15Mpps |
MAC Address | 1K |
Buffer | 768K |
Transmission Distance | 10BASE-T ： Cat3,4,5 UTP(≤250 meter) 100BASE-TX ： Cat5 or later UTP(150 meter) |
Power Pin | Default 1/2(+)，3/6(-)；Optional order 4/5(+)，7/8(-) |
Single port power | 15.4W/30W (first port MAX 60W) |
Total power/Input voltage | MAX 65W （AC100-240V） |
Watt | Standby Power Consumption：＜3W； Full-load Power Consumption：＜65W |
LED indicator | P:Power LED（Over-power LED） Uplink:（Link LED=10/100M Link） Port:（Orange=PoE LED+Green=Link LED） V:(Port Isolation LED) S:(Ultral-far Mode LED) |
Power Input | Built-in Power AC：100～240V 50-60Hz 1A |
Operating Temperature/Humidity | -10～+55°C；5%～90% RH Non coagulation |
Storage Temperature/Humidity | -40～+75°C；5%～95% RH Non coagulation |
Product size/Packing size（L*W*H） | 190mm*130mm*35mm 305mm*205mm*55mm |
N.W/G.W（kg） | 0.6kg/0.9kg |
Installation | Desktop (optional wall hanger parts) |
Lightning protection level | 3KV 8/20us； IP30 |
Certificate | CE mark, commercial；CE/LVD EN60950； FCC Part 15 Class B；RoHS； |
Warranty | Whole device for 1 year(Accessories not included) |
Company Introduction
Established in 2010, Kemyond is professional for network communication,security,5G and industrial infrastructure information solution. We concentrate on R&D in industrial internet field. Our company regards“Broad Interconnection,Domain Enjoy The Future”as our tenet. “Providing the technology with safe and good experience” is our persistent pursuit.
We have more than 40% R&D technology workers with complete technology creation and fast-iterating ability , so far already obtained almost 100 patents .Now our main products include industrial switch,BDS/GPS time server,5G router/CPE,network security monitoring device, industrial general computing platform.network management/security monitoring planet,serial port service/OFT and so on.All of Kemyond products are certified RoHS,FCC and CE standards,and widely apply to electricity,transportation, petrochemical industry,metallurgy and new energy fields.
We have more than 40% R&D technology workers with complete technology creation and fast-iterating ability , so far already obtained almost 100 patents .Now our main products include industrial switch,BDS/GPS time server,5G router/CPE,network security monitoring device, industrial general computing platform.network management/security monitoring planet,serial port service/OFT and so on.All of Kemyond products are certified RoHS,FCC and CE standards,and widely apply to electricity,transportation, petrochemical industry,metallurgy and new energy fields.
If you have any questions, you are welcome to consult.
1.Do you provide OEM/ODM?
-yes,we can produce and design based on customers’ requirements.we accept OEM/ODM.
2. Can I buy samples placing orders?
-Yes.we sell 1 pc for our customer sample test.
3.What is your lead time ?
-Usually 10-15 working days.
4.What is your payment term?
-T/T,Western Union,Money Gram,and Paypal. This is negotiable.
5.What is the shipping method?
-It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and ect). Please confirm with us before placing orders.
6.How do you make our business long-term and good relationship?
-a. We keep good quality and competitive price to ensure our customers benefit ;
-b. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
