Характеристики
Products Description
Product Paramenters
YH Rubber Welding Cable
Standard
IEC 60245-6: Rubber insulated cables - Rated voltages up to and including 450/750V - Part 6: Arc welding electrode cables
Application
This rubber insulated copper core welding cable is used for connecting the electrode to the welding machine. It has super flexibility and oil-resistant performance. It can also be used in other movable applications where high flexibility is required.
Product details
1) Conductor: class 5 or 6 copper
2) Sectional area: 10~185 mm2
3) Insulation: rubber
4) No. of cores: 1
5) Outer sheath: rubber
6) Max. working temperature: 90 degrees
Sectional Area (mm2) | Insulation Thick. (mm) | Overall Dia. (mm) | Approx. Weight (kg/km) | Max. DC Resist. @ 20 degrees (ohm/km) |
10 | 1.8 | 9.2 | 170 | 1.95 |
16 | 2.0 | 10.5 | 240 | 1.24 |
25 | 2.0 | 11.9 | 340 | 0.795 |
35 | 2.2 | 13.4 | 450 | 0.565 |
50 | 2.4 | 15.5 | 615 | 0.393 |
70 | 2.6 | 18.3 | 850 | 0.277 |
95 | 2.8 | 20.2 | 1140 | 0.210 |
120 | 3.0 | 22.5 | 1400 | 0.164 |
150 | 3.2 | 25.0 | 1720 | 0.132 |
185 | 3.5 | 27.0 | 2010 | 0.108 |
