Машина для прокатки листового металла
US $10000
Одиночная и многоотделочная роликовая формовочная машина для формирования
- Категория: Tile Making Machinery >>>
- Поставщик: Cangzhou,Dixin,Roll,Forming,Machine,Co.,Ltd.Cangzhou,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 9520.12 $* | 9996.36 $* |
| Aug-16-2025 | 9440.96 $* | 9912.40 $* |
| Jul-16-2025 | 7920.15 $* | 8316.76 $* |
| Jun-16-2025 | 9280.33 $* | 9744.68 $* |
| May-16-2025 | 8080.13 $* | 8484.99 $* |
| Apr-16-2025 | 9120.90 $* | 9576.33 $* |
| Mar-16-2025 | 9040.56 $* | 9492.71 $* |
| Feb-16-2025 | 8960.51 $* | 9408.82 $* |
| Jan-16-2025 | 8880.40 $* | 9324.82 $* |
Характеристики
Single and Multi Trim roll forming machine,trim roll former
1.Panel Profile:
Trim Rollformers are held to the same benchmarks as our other product lines and are equipped with:
- High-quality controls
- Operator hand feed or coil feed operation
- Integrated feed table
- Ability to produce up to 600 pieces of trim per hour
- Many standard and custom profiles available
1.Technical configuration
Material | Colored steel sheet, galvanized steel sheet, aluminum sheet |
Thickness of coil sheet | 0.2-0.8mm |
Efficiency width | 25/30mm |
Machine details | |
Roller material | High grade NO. 45 forged steel with 0.05mm hard chrome plating |
Shaft material | High grade NO. 45 carbon wrought steel |
Diameter of shaft | 70mm or as your requirement |
Main frame | 300 H steel |
Forming steps | 16 stations |
Productivity | 10-15m/min |
Hydraulic station power | 5.5 KW |
Hydraulic pressure | 10-12MPa |
Hydraulic oil | 40# hydraulic oil |
Electric tension | 380V 50 Hz 3 Phase or as your requirement |
Color | Blue, green or yellow or as your requirement |
Rolling material | 45# steel,roller surfaces polishing, hard plating |
