1.5kw 80a со слежением за максимальной точкой мощности солнечный инвертор работает без батареек Смарт гибридный Mpp Солнечный Инвертор
- Категория: Power Supplies >>>
- Поставщик: Guolong,Electric,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.27 $* | 0.13 $* |
| Aug-19-2025 | 0.48 $* | 0.14 $* |
| Jul-19-2025 | 0.93 $* | 0.24 $* |
| Jun-19-2025 | 0.74 $* | 0.28 $* |
| May-19-2025 | 0.32 $* | 0.81 $* |
| Apr-19-2025 | 0.22 $* | 0.37 $* |
| Mar-19-2025 | 0.91 $* | 0.63 $* |
| Feb-19-2025 | 0.53 $* | 0.17 $* |
| Jan-19-2025 | 0.64 $* | 0.93 $* |
Характеристики
Product Description
Specification
Model | GL-INVI 1.5KW-12V | GL-INVI 2.4KW-24V | ||
RATED POWER | 1500VN1500W | 3000VA/2400W | ||
AC Input | ||||
Voltage | 230VAC | |||
Selectable Voltage Range | 170-280VAC(For Personal Computers) 90-280VAC(For Home Appliances) | |||
Frequency Range | 50 Hz/60Hz(Auto sensing) | |||
AC OUTPUT | ||||
AC Voltage Regulation | 230VAC土5% | |||
Surge Power | 3000W | 4800W | ||
Efficiency(Peak)PV to INV | 97% | |||
Efficiency(Peak)Battery to INV | 93% | |||
Transfer Time | 10 ms (For Personal Computers);20 ms (For Home Appliances) | |||
BATTERY &AC CHARGER | ||||
Battery Voltage | 12VDC | 24VDC | ||
Floating Charge Voltage | 13.5VDC | 27VDC | ||
Overcharge Protection | 16VDC | 33VDC | ||
Maximum AC Charge Current | 60A | |||
SOLAR CHARGER | ||||
Maximum PV Array Power | 2000W | 3000W | ||
MPPT Range@ Operating Voltage | 90-430VDC | |||
Maximum PV Array Open Circuit Voltage | 450VDC | |||
Maximum Charging Current | 80A | |||
Maximum Eff1c1ency | 98% | |||
PHYSICAL | ||||
Dimension,D*W*H(mm) | 348*270*95 | |||
Net Weight(kgs) | 4 | 5 | ||
Communication interface | RS232/GPRS/WIFI | |||
OPERATING ENVIRONMENT | ||||
Mumidity | 5% to 95% Relative Humidity(Non~condensing) | |||
Operating Temperature | 0℃~55℃ | |||
Storage Temperature | ﹣15℃~60℃ | |||
Working Modes Applications
Product Panel Introduction
Production Site
Company Profile
Packing & Delivery
