Ручная вибрационная пластина уплотнение сверхмощная электрическая
- Категория: Compactors >>>
- Поставщик: Zhengzhou,Hengyou,Machinery,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 333.93 $* | 350.27 $* |
| Aug-16-2025 | 330.29 $* | 347.86 $* |
| Jul-16-2025 | 277.65 $* | 291.55 $* |
| Jun-16-2025 | 325.39 $* | 341.28 $* |
| May-16-2025 | 283.65 $* | 297.15 $* |
| Apr-16-2025 | 319.9 $* | 335.77 $* |
| Mar-16-2025 | 316.7 $* | 332.18 $* |
| Feb-16-2025 | 314.85 $* | 330.57 $* |
| Jan-16-2025 | 311.30 $* | 327.67 $* |
Характеристики
vibrating plate compactor is mainly suitable for materials with relatively small adhesion and friction between compacted particles, such as river sand,gravel and asphalt. Vibratory plate compaction is composed of engine, ram plate, vibration exciter, spring suspension system, etc. The power is transmitted from the engine to the eccentric block type vibration exciter through the belt, and the eccentric moment generated by the vibration exciter drives the ram plate to a certain amplitude and excitation force. Equipment to vibrate the material being pressed.
engine | engine | motor power | tamping surface | speed of forward play | excitation frequency | vibration strength | tamping speed | total weight |
type | diesel/ gasoline | 6.5p | 380*500mm | 3600r/min | 48hz | 20kn | 4-20m/min | 75kg |
60 | electric | 3kw380v | 420*500mm | 3600r/min | 48hz | 20kn | 4-20m/min | 110kg |
160 | diesel/ gasoline | 6.5p | 420*650mm | 3600r/min | 48hz | 26kn | 4-20m/min | 140kg |
160 two-way | diesel/gasoline | 6.5p | 480*550mm | 3600r/min | 48hz | 15kn | 4-20m/min | 98kg |
mikasa | 173 diesel/ gasoline | 6.5p | 420*500mm | 3600r/min | 48hz | 20kn | 4-20m/min | 120kg |
200 | electric | 4kw380v | 420*550mm | 3600r/min | 48hz | 26hn | 4-20m/min | 130kg |
Engine
High-quality gasoline-powered engine (honda) is used for quality assurance and full power
Tamper plate
Thickened ram plate, solid materials and long service life.
Rack
Humanized U-shaped folding design, two-way pushable and pullable, suitable for more operation scenarios, and convenient to transport and save space.
Wheels
Foldable storage moving wheels, easy to move, foldable storage when the machine is running, safe to use.
Zhengzhou Hengyou Machinery Manufacturing Co., Ltd., located in Zhengzhou, Henan Province, was established on August 28, 2017.Itcovers an area of about 50 acres, has nearly 30,000 square meters of workshops, office buildings, 2000 square meters, and nearly 300 square meters of products. Showroom.Our company is now specialized in the manufacture and trade of material handling equipment, construction engineering machinery,agricultural machinery, mining machinery and livestock machinery. Our production workshop has a clear division of labor, clear division of responsibilities, and two warehouses. Our company has more than 300 fixed employees, including more than 200 skilled workers, more than 20 core professional R&D teams, and more than 200 sets of large-scale production and processing equipment. Our company insists on striving for survival by quality, creating brand by meticulous, and seeking innovation by research and development, and constantly pushes new products of different grades and different prices to meet the needs of buyers at different levels. As a direct manufacturer that can support self-production and self-sales, we have strong strength to complete the integrated operation of production, sales, delivery and after-sales, and can provide our customers with comprehensive one-stop services.
Our market has covered various regions in China, and is now exported to more than 90 countries and regions such as Europe, the United States, Australia, Japan, and the United States. With rich experience in import and export, we can provide diversified mechanical equipment for international friends in various countries.
Q1:Does the plate compactor ship by sea or land? Which port? |
A1: Our shipments are generally shipped by sea, which has strong carrying capacity and cheaper freight, and the seaborne is more tolerant of the category of goods, and the basic requirements can be met. We generally use Tianjin and Qingdao ports within China. |
Q2:How is your service in compactor plate ? |
A2:24 hours on line service,support Chinese,English and French techinical guidance. |
Q3:How you Soil Impact vibrating plate compactor Packing&delivery？ |
A3:Standard export wooden box,protect the machine from damage.If your order is big and we have no stock,we promise to delivery within 7 to 12 days. |
