Китайский колесный вилочный погрузчик JINGONG 28 тонн фронтальный JGM761FT26KN каменный
- Категория: Other Material Handling Equipment >>>
- Поставщик: Cruking,Engineering,Equipment,(Xiamen),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 97580.70 $* | 102459.91 $* |
| Aug-19-2025 | 96760.20 $* | 101598.14 $* |
| Jul-19-2025 | 81180.70 $* | 85239.25 $* |
| Jun-19-2025 | 95120.81 $* | 99876.48 $* |
| May-19-2025 | 82820.79 $* | 86961.50 $* |
| Apr-19-2025 | 93480.65 $* | 98154.58 $* |
| Mar-19-2025 | 92660.27 $* | 97293.85 $* |
| Feb-19-2025 | 91840.28 $* | 96432.96 $* |
| Jan-19-2025 | 91020.87 $* | 95571.76 $* |
Характеристики
Chinese JINGONG 28 ton wheel forklift front loader JGM761FT26KN stone forklift price
Contact
Products Description
Equipped with Weichai WP10 National III electronic-control high pressure common rail engine, it features low speed torque, energy saving and environmental protection.
Highly efficient big capacity torque converter and highly reliable self-developed low revs transmission for outstanding comprehensive energy-saving effect.
Double pump conflux, steering priority hydraulic system features high efficiency and low energy consumption.
Full hydraulic coaxial flow steering amplification system enables light and flexible steering, and reliable work.
The hydraulic fuel tank uses high-precision paper filter element in the oil suction and oil return pipeline, which ensures the cleanliness of the hydraulic system.
It improves the reliability of the hydraulic system by using hydraulic accessories of high standards and new technologies in the industry.
The cooling system for the whole machine is optimized and the heat dissipation effect is good, ensuring the stability and reliability of the machine under harsh working conditions.
Double rocker arm Z-shaped linkage mechanism for big breakout force and lifting force.
The structural parts are subject to finite element analysis, and the key hinge joints adopt dustproof design, which ensures good lubrication of the pin shaft.
The service brake adopts air-over-hydraulic caliper disc brake, and the parking brake adopts flexible shaft controlled caliper brake.
New cab with interiors made of composite materials, capacious space, and reasonably allocated operating devices, for convenient operation.
Intelligent instruments system offers real time monitoring of the overall working conditions.
Adapted to modern exploration technology, it can easily pry and load the rough stone blocks, which reduces labor cost and labor intensity.
Three power modes: “heavy load”, “medium load” and “light load” can be selected according to different working conditions to achieve fuel economy and consumption reduction.
Standard configuration
Weichai Power WP10 National III electronic control low revs engine.
Hangzhou Advance ZL60-012 hydrodynamic transmission assembly.
Self-made 60 drive axle (3 brake caliper at one side).
Sunshade curtain, silk enclosure mat, heater.
New type water tank, intercooler, torque converter oil cooler, hydraulic oil cooler.
New type waterproof connector harness, intelligent instruments, fuel sensor, GPS.
Hangzhou Advance ZL60-012 hydrodynamic transmission assembly.
Self-made 60 drive axle (3 brake caliper at one side).
Sunshade curtain, silk enclosure mat, heater.
New type water tank, intercooler, torque converter oil cooler, hydraulic oil cooler.
New type waterproof connector harness, intelligent instruments, fuel sensor, GPS.
Optional components
B-L fixed axle transmission(pilot), full hydraulic brake, Y-Y 60 axle, special bucket, tire protection chain, single cooling/cooling and heating air conditioner.
Product Paramenters
Model | JGM761FT26KN |
Machine weight kg | 28000 |
Max. Load (fork height ≤1600mm)kg | 26000 |
Load center distance mm | 600 |
Max. Lifting height mm | 3690 |
Fork size (LxWxH) mm | 1500×240×120 |
Fork spacing mm | 270～835 |
Machine size (LxWxH) mm | 8850×3050×3525 |
Min. turning radius mm | 8000 |
Min. ground clearance mm | 400 |
Wheelbase mm | 3950 |
Departure angle ° | 20 |
Max. traction kN | 221 |
Travel speed | |
Forward gear I km/h | 0～10 |
Forward gear II km/h | 0～35 |
Reverse gear I km/h | 0～13 |
Total cycle time s | 17.7 |
Engine power kW | 178 |
Fuel tank volume L | 220 |
Hydraulic oil tank volume L | 270 |
Details Images
