1. Product introduction of testo 340 portable flue gas analyzer/Germany Testo flue gas analyzer
1. The ever-increasing fuel cost makes it more and more important to use flue gas analysis to improve boiler combustion efficiency. A practical, easy-to-operate and portable flue gas analyzer is the ideal choice. Testo 340 only comes with O2 sensor as standard, and the other 3 sensors can be selected and matched according to different applications. The compact design and reliable technology make testo 340 suitable for the following applications: environmental monitoring; energy-saving monitoring; stationary engine testing; turbine testing;
2. Pre-calibrated plug-and-play spare sensor, 3 freely selectable sensor slots (standard O2, at least 2 sensors can work) CO, COlow, NO, NOlow, NO2 and SO2.
3. Testo 340 comes standard with differential pressure/flow rate measurement function: the configured range extension function, the standard single sensor range extension or the optional sensor range extension
4. Automatic flow control air pump
5. Modular flue gas probe
6. Data storage function
7. Optional: Data transmission, connect with easyEmission computer software via USB.
8. 10 kinds of built-in fuels, 10 kinds of user-defined fuels-fuel coefficient can be calculated by easyEmission software
9. Testo 340 can work with at least 2 sensors and can be equipped with 4 sensors.
2. Product parameters of testo 340 portable flue gas analyzer/Germany Testo flue gas analyzer
Order number
Optional: CO (H2 compensation) sensor, 0 ~ 10,000 ppm
0393 1100
Optional: COlow (H2 compensation) sensor, 0 ~ 500 ppm
0393 1102
Optional: NO sensor, 0 ~ 3,000 ppm
0393 1150
Optional: Nolow sensor, 0 ~ 300 ppm
0393 1152
Optional: NO2 sensor, 0 ~ 500 ppm
0393 1200
Optional: SO2 sensor, 0 ~ 5,000 ppm
0393 1250
Optional: Sensor range extension
0440 3350
Instrument case
0516 3400
Spare CO sensor chromatography filter
0554 4100
Spare NO sensor chromatography filter
0554 4150
illustrate
Order number
Spare stainless steel sintered pre-filter (2pcs/pack)
0554 3372
Extension connecting hose, 2.8 m, used to extend the hose between the probe and the analyzer
0554 1202
Spare stainless steel sintered pre-filter (2pcs/pack)
0554 3372
Probe sleeve, 335 mm long, with fixed cone, Ø 8 mm, temperature resistance 1000 °C
0554 8764
Probe sleeve, 700 mm long, with fixed cone, Ø 8 mm, temperature resistance 1000 °C
0554 8765
Probe sleeve, with pre-filter, 335 mm long, with fixed cone, Ø 8 mm, temperature resistance 1000 °C
0554 8766
Probe sleeve, with pre-filter, 700 mm long, with fixed cone, Ø 8 mm, temperature resistance 1000 °C
0554 8767
Probe sleeve, 335 mm long, with fixed cone, Ø 8 mm, temperature resistance 1000 °C
0554 8764
illustrate
Order number
Modular flue gas probe, 335 mm long, with fixed cone and thermocouple, temperature resistant to 1000°C and 2.2 m sulfur resistant tube
0600 8764
Modular flue gas probe, 700 mm long, with fixed cone and thermocouple, temperature resistant to 1000°C and 2.2 m sulfur resistant tube
0600 8765
Modular flue gas probe, with pre-filter, 335 mm long, with fixed cone and thermocouple, temperature resistance 1000°C and 2.2 m sulfur tube
0600 8766
Modular flue gas probe, with pre-filter, 700 mm long, with fixed cone and thermocouple, temperature resistant to 1000°C and 2.2 m sulfur resistant tube
0600 8767
Modular flue gas probe, 335 mm long, with fixed cone and thermocouple, 500°C temperature resistant and 2.2 m sulfur resistant tube
0600 9766
Modular flue gas probe, 700 mm long, with fixed cone and thermocouple, 500°C temperature resistant and 2.2 m sulfur resistant tube
0600 9767
illustrate
Order number
Straight Pitot tube, stainless steel, 350 mm long, used to measure flow rate and temperature, includes 3 hoses (5 m long) and adiabatic plate
0635 2041
Temperature range -40 ~ +1000 °C
Straight Pitot tube, stainless steel, 750 mm long, used to measure flow rate and temperature, includes 3 hoses (5 m long) and adiabatic plate
0635 2042
Temperature range -40 ~ +1000 °C
Stainless steel pitot tube, 350 mm long, connected to a pressure probe, can measure wind speed
0635 2145
(With pressure probe 0638 1347/0638 1447/0638 1547 or testo 521 built-in sensor)
Stainless steel pitot tube, 1000 mm long, connected to a pressure probe, can measure wind speed
0635 2345
illustrate
Order number
Mini ambient air probe, Tmax +80°C, used to measure ambient air temperature separately
0600 3692
Range 0 to +80 °C
Pipe clamp probe, used to measure the surface temperature of pipes with a maximum diameter of 2"
0600 4593
Range -60 ~ +130 °C
Combustion air temperature probe, insertion depth 60 mm
Range 0 ~ +100 °C
