Промышленные Винтовые воздушные компрессоры Vialvv 7 5 кВт 15 22 цена 37 55 75 90 110
- Категория: Industrial Compressors >>>
- Поставщик: Yiwu,Deyang,Machinery,&,Equipment,Firm
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 1892.96 $* | 1987.56 $* |
| Aug-19-2025 | 1876.43 $* | 1970.90 $* |
| Jul-19-2025 | 1574.81 $* | 1653.56 $* |
| Jun-19-2025 | 1844.30 $* | 1936.87 $* |
| May-19-2025 | 1606.55 $* | 1686.58 $* |
| Apr-19-2025 | 1813.32 $* | 1904.17 $* |
| Mar-19-2025 | 1797.72 $* | 1887.43 $* |
| Feb-19-2025 | 1781.86 $* | 1870.29 $* |
| Jan-19-2025 | 1765.71 $* | 1853.94 $* |
Характеристики
7.5kw 15kw 22kw industrial compressors air-compressors air compressors brand air compressor air compressor compressors screw compressors screw air compressor price 37kw 55kw 75kw 90kw 110kw 132kw
Products Description
Model | SD-30 | Noise dB(A) | ≤65土2 | |
Power | 22kw30HP | Driven mode | Direct driven or Belt driven | |
Working Pressure Air flow | 7bar - 3.8m3/min | Starting mode | Y/Δ | |
8bar - 3.5m3/min | Outlet size | G3/4" | ||
10bar-3.2m3/min | Voltage Frequency | 220V/50HZ/3PH | ||
12-30bar Customized | 220V/60HZ/3PH | |||
Speed | 2950 r.p.m | 380V/60HZ/3PH | ||
Compressed stage | Single stage | 415V/60HZ/3PH | ||
Cooling outlet air temperature after cooling | Ambient temperature+12C° | 440V/60HZ/3PH | ||
Motor protection level/ insulation level | IP 23/F or IP 55/F | 380V/50HZ/3PH | ||
Cooling method | Air cooled | 415V/50HZ/3PH | ||
Lubricating oil | 18 L | Dimension(mm) | 970*750*1000 | |
Export gas lubricant carrying capacity | ≤3ppm | Weight(KG) | 260 |
Model Click On | Power | Air flow Pressure (8 bar / 115 psi) | Size (H*L*W) | Weight | ||||||
FC | PM | KW | HP | m3/min | CFM | cm | Kg | |||
7.5 | 10 | 1.2 | 42 | 92*65*90 | 240 | |||||
11 | 15 | 1.65 | 58 | 110*75*105 | 300 | |||||
15 | 20 | 2.35 | 83 | 110*75*105 | 340 | |||||
18.5 | 25 | 3.1 | 110 | 1350*870*112 | 550 | |||||
22 | 30 | 3.62 | 128 | 1350*870*1120 | 550 | |||||
30 | 40 | 5 | 177 | 1350*870*1120 | 580 | |||||
37 | 50 | 6.5 | 230 | 1500*1000*1300 | 700 | |||||
45 | 60 | 8.2 | 290 | 1500*1000*1300 | 800 | |||||
55 | 75 | 9.8 | 346 | 1850*1300*1550 | 1200 | |||||
75 | 100 | 13.5 | 477 | 1850*1300*1550 | 1500 | |||||
90 | 120 | 15.5 | 548 | 2350*1650*1800 | 1850 | |||||
110 | 150 | 19.7 | 696 | 2600*1650*1800 | 1900 | |||||
132 | 175 | 23.2 | 820 | 2600*1650*1800 | 2600 | |||||
160 | 220 | 27.6 | 975 | 2900*1800*2000 | 4100 | |||||
185 | 245 | 30 | 1060 | 2900*1800*2000 | 4120 | |||||
200 | 265 | 33 | 1166 | 2900*1800*2000 | 4180 | |||||
220 | 300 | 40 | 1413 | 3520*2290*2030 | 6000 | |||||
250 | 330 | 45.5 | 1608 | 3520*2290*2030 | 6000 | |||||
280 | 375 | 51.5 | 1820 | 4200*2300*2300 | 7000 | |||||
315 | 420 | 57.5 | 2032 | 4200*2300*2300 | 9000 | |||||
350 | 460 | 63 | 2226 | 5300*2300*2300 | 9000 | |||||
400 | 530 | 70.5 | 2491 | 5300*2300*2300 | 10000 | |||||
