Одобренный Ce 30Kw Ccs1 Ccs2 Ev зарядное устройство для ladegerat быстрая зарядная станция с сенсорным экраном электромобиля Dc
- Категория: Auto Electronics >>>
- Поставщик: Guangzhou,Kinouwell,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 4715.91 $* | 4951.96 $* |
| Aug-20-2025 | 4675.68 $* | 4909.84 $* |
| Jul-20-2025 | 3922.20 $* | 4118.94 $* |
| Jun-20-2025 | 4596.23 $* | 4826.92 $* |
| May-20-2025 | 4002.17 $* | 4202.95 $* |
| Apr-20-2025 | 4517.38 $* | 4743.34 $* |
| Mar-20-2025 | 4477.31 $* | 4701.12 $* |
| Feb-20-2025 | 4437.78 $* | 4659.60 $* |
| Jan-20-2025 | 4398.19 $* | 4618.79 $* |
Характеристики
Products Description
Model | KW-PEVC3401E-30K1000N1 | KW-PEVC3401-40K1000N1 | |
Power Suppply | 3P+N+PE | ||
Installation | Wall-mounted/floor-standing | ||
THDi | ≤5% | ||
Efficiency | ≥95% | ||
Power Factor | ≥0.98 | ||
Rated Voltage | 400VAC±15%(50/60Hz) | ||
Protection | IP54 | ||
Connector Type | CCS Combo 2 | ||
Output voltage | 150-1000VDC | ||
Maximum Output Current | 200ADC | ||
Output Power | 30KW | 40KW | |
Output Voltage Accuracy | ≤0.5% | ||
HMI | 4.3 inch touch LCD screen | ||
Output Current Accuracy | ≤0.5% | ||
Output Current Accuracy | ≤±5% | ||
Payment Method | RFID Card,APP | ||
Cable length | 5 Meters (Custom) | ||
Network Connection | Cellular modem:GSM/3G/4G LAN:10/100 Base-T Ethernet | ||
Communication Protocol | OCPP 1.6J | ||
Operating Noise Level | ≤60dBA | ||
Protective function | Over Current,Under Voltage,Over Voltage,Short Circuit,Residual Current, Surge Protection,Over Temperature,Ground Protection | ||
Power Meter | Accuracy Class 1 energy meter | ||
Enclosure | Galvanized steel | ||
Product Dimension | 700 x 550 x 1800mm(W x D x H) | ||
Package Dimension | 950 x 720 x 1950mm(W x D x H) | ||
Maximum Installation Height | ≤2000 meters | ||
Operating Humidity | 5%–95% RH | ||
Operating temperature | -35℃ to +50℃ | ||
Storage temperature | –40°C to +75°C | ||
