Сканер штрих-кода Chainway C66 и NFC КПК Android 11 0 встроенный UHF RFID-считыватель портативный мобильный

Physical Characteristics

Dimensions

160.0 x 76.0 x 15.5 mm / 6.3 x 2.99 x 0.61 in.

Weight

287 g / 10.12 oz. (device with battery)

Battery

Removable main battery (normal version:4420 mAh ; Android 11.0 with fingerprint / built-in UHF / volume measurement version: 5200mAh )
5200 mAh optional pistol battery, support QC3.0 and RTC
Standby: up to 490 hours (only main battery ; WiFi: up to 470h; 4G: up to 440h)
Continuous use: over 12 hours (depending on user environment)
Charging time: 2.5 hours (charge device by standard adaptor and USB cable)

Touch Panel

Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported

Speaker

Support

Vibrator

Support

Microphone

2 Microphones, 1 for noise reduction

Interfaces

USB Type-C, USB 3.1, OTG, extended thimble;

Card slot

1 slot for Nano SIM card, 1 slot for Nano SIM or TF card

Keypad

1 power key, 2 scan keys, 2 volume keys, 1 PTT key

Sensors

Gravity sensor, proximity sensor, light sensor, accelerometer sensor, vibration motor

Indicator LED

Power, charging, status indicator

Display Interface

5.5-inch high definition full display (18:9), IPS LTPS 1440 x 720

Developing Environment

Operating System

Android 11.0; GMS, built-in support for a future upgrade through Android 12 which complies with GMS and Android Enterprise Recommended

SDK

Chainway Software Development Kit

Language

Java

Tool

Eclipse / Android Studio

Performance

CPU

2.0 GHz Octa-core

RAM+ROM

3 GB + 32 GB / 4 GB + 64 GB

Expansion

Supports up to 128 GB Micro SD card

UHF RFID

Frequency

865-868 MHz / 920-925 MHz / 902-928 MHz

Protocol

EPC C1 GEN2 / ISO18000-6C

Antenna

Circular polarization (1 dBi)

Power

1 W (+19 dBm to +30 dBm adjustable)

R/W ranges

3 m

User Environment

Operating Temp.

-4oF to 122oF / -20 ℃ to +50 ℃

Storage Temp.

-40oF to 158oF / -40 ℃ to +70 ℃

Humidity

5% RH - 95% RH non condensing

Drop Specification

Multiple 1.8 m / 5.91 ft. drops (at least 20 times) to the concrete across the operating temperature range
Multiple 2.4 m / 7.87 ft. drops (at least 20 times) to the concrete after installed rubber bumper

Tumble Specification

1000 x 0.5 m / 1.64 ft. falls at room temperature

Sealing

IP65 per IEC sealing specifications

ESD

±15 KV air discharge, ±8 KV conductive discharge

Barcode Scanning

2D Scanner

Zebra: SE4710/SE2100; Honeywell: N6603; E3200; IA166S

1D Symbologies

UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.

2D Symbologies

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc.

Note

*This function is optional

Camera

Camera

Rear 13MP Autofocus with flash

NFC

Frequency

13.56 MHz

Protocol

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.

Chips

M1 card (S50, S70), CPU card, NFC tags, etc.

Range

2-4 cm

Optional accessories

Accessories

Wrist Strap; Rubber Bumper; Charging Cradle
