Считыватель rfid с диапазоном считывания 10 метров портативный считыватель 920-926 МГц 2d

SPECIFICATIONS

PHYSICAL CHARACTERISTICS

Dimension

166mm(H)x79mm(W)x27mm(D)±2 mm

Weight

Net Weight :400g (including battery&wrist strap)

Display

Gorilla Glass 3 9H 5.5 in. TFT-LCD(720x1440)touch screen with backlight

Backlight

LED backlight

Battery

Rechargeable li-ion polymer, 3.8V, 4800mAh

PERFORMANCE CHARACTERSTICS

CPU

Cortex A73 2.0GHz octa-core

Operating System

Android 10.0

Storage

2GB RAM/16GB ROM or 4GB RAM/64GB ROM, MicroSD(max 256GB expansion)

USER ENVIRONMENT

Operating Temp.

-20℃ to 50℃

Storage Temp.

-20℃ to 70℃

Humidity

5%RH to 95%RH(non-condensing)

Drop Specifications

5ft./1.5 m drop to concrete across the operating temperature range

DEVELOPMENT ENVIRONMENT

SDK

Handheld-Wireless Software Development Kit

Language

Java

Environment

Android Studio or Eclipse

DATA COMMUNICATION

WWAN

TDD-LTE Band 38, 39, 40, 41; FDD-LTE Band 1, 2, 3, 4, 7, 17, 20;

WCDMA(850/1900/2100MHz);

GSM/GPRS/Edge (850/900/1800/1900MHz);

WLAN

2.4GHz/5.0GHz Dual Frequency, IEEE 802.11 a/b/g/n/ac

WPAN

Class v2.1+EDR, v3.0+HS, v4.2

GPS

GPS(embedded A-GPS), accuracy of 5 m

DATA CAPTUER

BARCODE READER(OPTIONAL)

1D barcode

1D laser engine

N4313

Symbologies

All major 1D barcodes

2D barcode

2D CMOS Imager

Zebra SE4710/Mindeo ME5600

Symbologies

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal. etc.

RFID READER(OPTIONAL)

RFID LF

Frequency

125KHz/134.2KHz(FDX-B/HDX)

Protocol

ISO 11784&11785

R/W Range

2cm to 10 cm

RFID HF/NFC

Frequency

13.56MHz

Protocol

ISO 14443A&15693

R/W Range

2cm to 8cm

RFID UHF

Frequency

865~868MHz or 920~925MHz

Protocol

EPC C1 GEN2/ISO 18000-6C

Antenna Gain

Circular antenna(2dBi)

R/W Range

1.5 m to 2 m(tags and environment dependent)
