Product Description


Automatic and Fast defrost optimization
Complete defrosting with intelligent flexible, advanced technology. Maximize heating requirements with each compressor refrigerant cycles alternately -operating.

Modular design
Integral structure, easy installation,Increasing unit capacity freely, simple and easy， flexible configuration to meet different needs fully. Max 16 units can be connected in parallel and controlled by the master

High-efficient heat exchanger to improve efficiency
Effectively increasing the heat exchange area with the fin type threaded tube, also with high compacting convection design heat transfer
Low resistance of the hot water circuit and more stable operation

Multiple protection functions to ensure the safe operation of the system
Advanced intelligent control, with multiple protection devices such as operating control and safety protection, real-time alarm when failure occurs.

Cloud service
Automatic control and remote control are available. You can monitor the product any moment by APP, diagnose machine faults in time and keep the excellent working performance all time.

Environmental- friendly refrigerant
R410A free of ODP, also with better evaporation performances at low temperatures, higher evaporation pressure , and less energy attenuation.


HP
12HP
15HP
24HP
30HP
48HP
50HP
100HP
Model Name
LSQW(R)F35
LSQW(R)F42
LSQW(R)F68
LSQW(R)F85
LSQW(R)F130
LSQW(R)F130
LSQW(R)F300
Power Supply
380-400V~, 3Ph, 50Hz
Cooling
Capacity
kW
32
42
65
85
130
130
260
kBtu/h
109.2
143.3
221.8
290.1
443.7
443.7
887.4
RT
9.1
11.9
18.5
24.2
37.0
37.0
73.9
Power Input
kW
10.5
13.5
21.5
27
43
45
90
Current
A
19
24.5
38.5
48.3
76.8
80.5
161
EER
3.05
3.11
3.02
3.15
3.02
2.89
2.89
Heating
Capacity
kW
35
45
68
90
140
150
300
kBtu/h
119.5
153.6
232.1
307.2
477.8
511.9
1023.9
RT
10.0
12.8
19.3
25.6
39.8
42.6
85.3
Power Input
kW
9.5
12
19
24
38
41
82
Current
A
17
21.5
33.9
42.9
67.9
73.3
146.6
COP
3.7
3.8
3.6
3.8
3.7
3.7
3.7
Compressor
Type
Scroll
Quantity
1
1
2
2
4
2
4
Fan
Type
Aixal Fan
Quantity
2
2
2
2
2
2
4
Power Input
W
250
370
750
1100
1500
2000
4000
Evaporater
Axial coaxial heat exchanger
Shell in Tube heat exchanger
Condenser
Copper tube and aluminum fin
Refrigerant
Type
R410A
Charged
kg
8.5
9
8.0*2
9.0*2
8.0*4
13.5*2
13.5*4
Pipe
Water Flow
M3/H
5.5
7.2
11.2
14.6
22.4
22.4
44.8
Drop
kPa
35
35
42
45
45
45
45
Size
\\
DN32
DN40
DN50
DN50
DN65
DN65
DN100
Dimension
Length
mm
1500
1720
2056
2160
2450
2270
2600
Width
mm
760
760
1106
1110
1136
2130
2250
Height
mm
1140
1140
2045
2000
2118
1300
2470
Noise
dB(A)
65
65
68
70
72
72
72
Weight
kg
350
420
650
900
920
970
1940


Notes:
1, Nominal cooling capacities are based on the following conditions: Outdoor temperature: 35°CDB, 24°CWB,Water in / out:12/7°C ;
2. Nominal Heating capacities are based on the following conditions: Outdoor temperature: 7°CDB, 6°CWB,Water in / out: -
/ 45°C ;
3. Sound pressure level is measured at a position 1m in front of the unit and 1.3m above the flfloor in a semi-anechoic
chamber;




Details Images
