5hp винтовой воздушный компрессор насос 4 кВт 5 л.с. 220 В однофазный с сушильным баком Fengshi Vialvv Yiwu Китай низкий
- Категория: Industrial Compressors >>>
- Поставщик: Yiwu,Deyang,Machinery,&,Equipment,Firm
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 1071.37 $* | 1125.92 $* |
| Aug-20-2025 | 1062.17 $* | 1115.34 $* |
| Jul-20-2025 | 891.77 $* | 936.88 $* |
| Jun-20-2025 | 1044.42 $* | 1096.93 $* |
| May-20-2025 | 909.63 $* | 954.72 $* |
| Apr-20-2025 | 1026.57 $* | 1077.24 $* |
| Mar-20-2025 | 1017.39 $* | 1068.20 $* |
| Feb-20-2025 | 1008.85 $* | 1058.41 $* |
| Jan-20-2025 | 999.63 $* | 1049.60 $* |
Характеристики
5hp air compressor 4kw 5 hp compressor 5 hp screw compressor with dryer 5hp air compressor 5hp compressor 5 hp air compressor 5 hp compressor with tankair compressor pump 5hp screw compressor 220V screw compressor 5 hp compressor with dryer
PERMANENT MAGNET
FREQUENCY
FREQUENCY
√.IE4 permanent magnet motor
√.Constant pressure and silence
√.Small footprint
√.Large size air end,low speed
sufficientair volume.
sufficientair volume.
√.Six heavy-duty bearings
Morse taper connection.
Morse taper connection.
√.Easy to install and maintain
REDUCE ENERGY CONSUMPTION
Under different conditions, the demand for gas will float.Through a large number of research and calculation of marketdemand,Cha-nun confirmed it. Only about 10% of applications require stable air supply.Therefore, frequency conversioncompressor can play a greater role in energy saving.
Energy cost often accounts for 70% of the life cycle cost of a compressor. The production of compressed air may account for40% of all electricity costs in the plant. In almost every factory, the gas consumption will vary with different time periods,with its high and low peak periods.Chanun permanent magnet variable frequency screw air compressor can supply gascompletely according to the requirements of gas consumption, which can not only save a lot of energy, but also protect theenvironment for future generations.
Products Description
Model | SD-05 | Noise dB(A) | ≤65土2 | |
Power | 4.0 KW/5 HP | Driven mode | Direct | |
Working Pressure Air flow | 7bar -0.55m3/min | Starting mode | Y/Δ or PM | |
8bar-0.51m3/min | Outlet size | G3/4" | ||
10bar-0.45m3/min | Voltage Frequency | 220V/60HZ/1PH | ||
12-25bar Customized | 220V/50HZ/1PH | |||
Speed | 2950 r.p.m | 380V/60HZ/3PH | ||
Compressed stage | Single stage | 415V/60HZ/3PH | ||
Cooling outlet air temperature after cooling | Ambient temperature+12C° | 440V/60HZ/3PH | ||
Motor protection level insulation level | IP 23/F or IP 55/F | 380V/50HZ/3PH | ||
Cooling method | Air cooled | 415V/50HZ/3PH | ||
Lubricating oil | 5 L | Size L*W*H(mm) | 800*600*815 | |
Export gas lubricant carrying capacity | ≤3ppm | Weight(KG) | 103 |
FC abbreviation：Power frequency screw air compressor. | ||||||||
PM abbreviation：Permanent magnet variable frequency screw air compressor. | ||||||||
Model Click On | Power | Air flow Pressure (8 bar / 115 psi) | Size (H*L*W) | Weight | ||||||
FC | PM | KW | HP | m3/min | CFM | cm | Kg | |||
7.5 | 10 | 1.2 | 42 | 92*65*90 | 240 | |||||
11 | 15 | 1.65 | 58 | 110*75*105 | 300 | |||||
15 | 20 | 2.35 | 83 | 110*75*105 | 340 | |||||
18.5 | 25 | 3.1 | 110 | 135*87*112 | 550 | |||||
22 | 30 | 3.62 | 128 | 135*87*112 | 550 | |||||
30 | 40 | 5 | 177 | 135*87*112 | 580 | |||||
37 | 50 | 6.5 | 230 | 150*100*130 | 700 | |||||
45 | 60 | 8.2 | 290 | 150*100*130 | 800 | |||||
55 | 75 | 9.8 | 346 | 185*130*155 | 1200 | |||||
75 | 100 | 13.5 | 477 | 185*1300*155 | 1500 | |||||
90 | 120 | 15.5 | 548 | 235*165*180 | 1850 | |||||
110 | 150 | 19.7 | 696 | 260*165*180 | 1900 | |||||
132 | 175 | 23.2 | 820 | 260*165*180 | 2600 | |||||
160 | 200 | 27.6 | 975 | 290*180*200 | 4100 | |||||
185 | 250 | 30 | 1060 | 290*180*200 | 4120 | |||||
200 | 270 | 33 | 1166 | 290*180*200 | 4180 | |||||
220 | 300 | 40 | 1413 | 352*229*203 | 6000 | |||||
250 | 340 | 45.5 | 1608 | 352*229*203 | 6000 | |||||
280 | 375 | 51.5 | 1820 | 420*230*230 | 7000 | |||||
315 | 420 | 57.5 | 2032 | 420*230*230 | 9000 | |||||
355 | 480 | 63 | 2226 | 530*230*230 | 9000 | |||||
400 | 530 | 70.5 | 2491 | 530*230*230 | 10000 | |||||
Product Introduction
7 INCH TOUCH SCREEN
Large touch screen,all-round protection monitoring,with functions of motor start/stopcontrol, operationcontrol;reversal protection
of air compressor; andmulti-point temperature detection and controlprotection.
of air compressor; andmulti-point temperature detection and controlprotection.
AUTOMOTIVE GRADE
PERMANENT MAGNET MOTOR
PERMANENT MAGNET MOTOR
IE4 high efficiency pemanent magnet motor.AUTOMOTIVE PERMANENT MAGNET MOTORForN38UH high grade pemanent magnet, IP67 protection grade,and fully enclosed structure,uniquevacuum epoxy dipping paint,effectively guaranteeing the stable operation of unit.
CHANUN
CUSTOM CONVERTER
CUSTOM CONVERTER
Permanent magnet variable-frequencyconversion technology, wide voltage,energy-saving ,with a small impact onthe power grid.
CUSTOM OILCOOLED MOTOR
First-stage energy-efficient motor,LowNoise,IlP65 protection grade.
HIGH MOBILITY (OPTIONAL)
Easy and flexible to rotate, so that the aircompressor is able to move convenientlyandquickly (optional).
