Vialvv 160KW 220hp 200hp винтовой воздушный компрессор без масла 220 hp 160 кВт компрессора безмасляный screwcompressor для
- Категория: >>>
- Поставщик: Yiwu,Deyang,Machinery,&,Equipment,Firm
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 20230.45 $* | 21242.58 $* |
| Aug-19-2025 | 20060.70 $* | 21063.83 $* |
| Jul-19-2025 | 16830.97 $* | 17672.45 $* |
| Jun-19-2025 | 19720.9 $* | 20706.52 $* |
| May-19-2025 | 17170.52 $* | 18029.41 $* |
| Apr-19-2025 | 19380.36 $* | 20349.32 $* |
| Mar-19-2025 | 19210.4 $* | 20171.44 $* |
| Feb-19-2025 | 19040.40 $* | 19992.65 $* |
| Jan-19-2025 | 18870.91 $* | 19814.0 $* |
Характеристики
160KW screw air compressor 160KW air compressor 160kw screw compressor 160KW compressor oil free 160kw oil free screw compressor 200hp screw air compressor 200hp air compressor 200hp screw compressor 200hp compressor oil free 200kw oil free screw compressor 220hp screw air compressor 220hp air compressor 220hp screw compressor 220hp compressor oil free 220hp oil free screw compressor
Products Description
Model | SD-160+ | Noise dB(A) | ≤65土2 | |
Power | 160kw/220HP | Driven mode | Direct driven or Belt driven | |
Working Pressure Air flow | 7bar - 28.5m3/min | Starting mode | Y/Δ | |
8bar - 27.0m3/min | Outlet size | G1-1/4" | ||
10bar-23.2m3/min | Voltage Frequency | 220V/50HZ/3PH | ||
12-30bar Customized | 220V/60HZ/3PH | |||
Speed | 2950 r.p.m | 380V/60HZ/3PH | ||
Compressed stage | Single stage | 415V/60HZ/3PH | ||
Cooling outlet air temperature after cooling | Ambient temperature+12C° | 440V/60HZ/3PH | ||
Motor protection level/ insulation level | IP 23/F or IP 55/F | 380V/50HZ/3PH | ||
Cooling method | Air cooled | 415V/50HZ/3PH | ||
Lubricating oil | 18 L | Dimension(mm) | 2380*1650*1900 | |
Export gas lubricant carrying capacity | ≤3ppm | Weight(KG) | 2100 |
Model Click On | Power | Air flow Pressure (8 bar / 115 psi) | Size (H*L*W) | Weight | ||||||
FC | PM | KW | HP | m3/min | CFM | cm | Kg | |||
7.5 | 10 | 1.2 | 42 | 92*65*90 | 240 | |||||
11 | 15 | 1.65 | 58 | 110*75*105 | 300 | |||||
15 | 20 | 2.35 | 83 | 110*75*105 | 340 | |||||
18.5 | 25 | 3.1 | 110 | 1350*870*112 | 550 | |||||
22 | 30 | 3.62 | 128 | 1350*870*1120 | 550 | |||||
30 | 40 | 5 | 177 | 1350*870*1120 | 580 | |||||
37 | 50 | 6.5 | 230 | 1500*1000*1300 | 700 | |||||
45 | 60 | 8.2 | 290 | 1500*1000*1300 | 800 | |||||
55 | 75 | 9.8 | 346 | 1850*1300*1550 | 1200 | |||||
75 | 100 | 13.5 | 477 | 1850*1300*1550 | 1500 | |||||
90 | 120 | 15.5 | 548 | 2350*1650*1800 | 1850 | |||||
110 | 150 | 19.7 | 696 | 2600*1650*1800 | 1900 | |||||
132 | 175 | 23.2 | 820 | 2600*1650*1800 | 2600 | |||||
160 | 220 | 27.6 | 975 | 2900*1800*2000 | 4100 | |||||
185 | 245 | 30 | 1060 | 2900*1800*2000 | 4120 | |||||
200 | 265 | 33 | 1166 | 2900*1800*2000 | 4180 | |||||
220 | 300 | 40 | 1413 | 3520*2290*2030 | 6000 | |||||
250 | 330 | 45.5 | 1608 | 3520*2290*2030 | 6000 | |||||
280 | 375 | 51.5 | 1820 | 4200*2300*2300 | 7000 | |||||
315 | 420 | 57.5 | 2032 | 4200*2300*2300 | 9000 | |||||
350 | 460 | 63 | 2226 | 5300*2300*2300 | 9000 | |||||
400 | 530 | 70.5 | 2491 | 5300*2300*2300 | 10000 | |||||
