Плата усилителя мощности XY C100H 100WX2 TPA3116 HIFI Stereo BT
- Категория: Receivers & Amplifiers >>>
- Поставщик: Shenzhen,Gui,Yi,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-17-2025 | 11.35 $* | 11.49 $* |
| Jul-17-2025 | 9.14 $* | 9.27 $* |
| Jun-17-2025 | 11.51 $* | 11.14 $* |
| May-17-2025 | 11.92 $* | 11.92 $* |
| Apr-17-2025 | 9.11 $* | 9.20 $* |
| Mar-17-2025 | 11.16 $* | 11.4 $* |
| Feb-17-2025 | 11.41 $* | 11.25 $* |
| Jan-17-2025 | 11.99 $* | 11.92 $* |
Характеристики
Product Description
Precautions for using APP
When using the APP, the Sinilink-APP cannot be searched, and the BT interface of the mobile phone is set to check whether the Sinilink-APP is searched. If the search is found (Do not connect here), it means that the permission of the APP is not opened or the location information of the mobile phone is not opened (very important) , Please go to the phone settings to enable all the permissions of the APP and then reopen the APP search; if the Sinilink-APP is not searched in the phone settings-BT, please confirm whether the BT power amplifier board is powered on and enters the BT mode; if it is powered on and enters the BT mode Please adjust the angle of the BT power amplifier board and search again.
Audio input mode switch
When this product is not mounted with any external audio device, the power-on default is the BT mode; if the external playback device is mounted, such as inserting an AUX or U disk, the power-on default is AUX or U disk playback mode; the playback process follows the priority of the rear plug-in device In principle, for example, if you insert AUX during BT playback, it will immediately switch to AUX playback; it is very convenient to switch the audio mode with APP.
When playing AUX, try to choose AUX cable with shielding layer to reduce noise.
The MP3 format is recommended for U disk playback. The sampling rate of the WAV format must be within 44100Hz. If the sampling rate is too high, the playback may not be possible.
When using the USB sound card function, you can connect the computer with a USB data cable without installing any drivers. Most computer systems will switch the USB sound card by default, and you can manually select the switch if it cannot be automatically switched.
When playing AUX, try to choose AUX cable with shielding layer to reduce noise.
The MP3 format is recommended for U disk playback. The sampling rate of the WAV format must be within 44100Hz. If the sampling rate is too high, the playback may not be possible.
When using the USB sound card function, you can connect the computer with a USB data cable without installing any drivers. Most computer systems will switch the USB sound card by default, and you can manually select the switch if it cannot be automatically switched.
Power selection
This product has a power supply range of 5-26VDC and is compatible with standard 5.5-2.1/2.5 power adapter plugs. It is recommended to use a 12V/24V standard power adapter with a current output of 4A or more.
1) The size of the power supply is related to the power of the speaker used. For example, if a 4 ohm 100W speaker is used, a 24V power supply is used, and the current is at least 6A. If the current is too small, a sound card may appear
This problem can be solved by reducing the volume and reducing the output power.
2) The power supply voltage cannot be higher than 26V, higher than 26V, the circuit board will be burned.
3) If the horn does not play when the power is turned on, and it keeps making a ticking sound, the power supply is insufficient, just increase the power supply.
1) The size of the power supply is related to the power of the speaker used. For example, if a 4 ohm 100W speaker is used, a 24V power supply is used, and the current is at least 6A. If the current is too small, a sound card may appear
This problem can be solved by reducing the volume and reducing the output power.
2) The power supply voltage cannot be higher than 26V, higher than 26V, the circuit board will be burned.
3) If the horn does not play when the power is turned on, and it keeps making a ticking sound, the power supply is insufficient, just increase the power supply.
Speaker selection
The power amplifier of this product can continuously output 100W*2 power when driving 40 speakers, 50W~300W speakers can be driven, it is recommended to use 4ohm or 8ohm speakers
If the power is less than 100W speakers, appropriately reduce the power supply voltage (such as 21V power supply) or reduce the playback volume; the greater the power supply voltage of speakers greater than 100W, the better (within 26V).
If there is a "hiccup" phenomenon when playing music speakers, first consider the insufficient power supply and use a larger power supply; second, consider the power amplifier overheating protection, strengthen heat dissipation or reduce the playback volume.
If the power is less than 100W speakers, appropriately reduce the power supply voltage (such as 21V power supply) or reduce the playback volume; the greater the power supply voltage of speakers greater than 100W, the better (within 26V).
If there is a "hiccup" phenomenon when playing music speakers, first consider the insufficient power supply and use a larger power supply; second, consider the power amplifier overheating protection, strengthen heat dissipation or reduce the playback volume.
Signal problem
This product uses a PCB antenna, and the visible distance of the connection can reach 15 meters without obstruction. If you can't find BT when you use it, or you can't connect to it, consider the signal problem.
1) Keep away from the router when using it.
2) Avoid using it on a metal table, which will affect the PCB antenna signal.
3) If you refit the speaker, if it is a metal shell, you must lead the antenna out of the shell. The metal shell will shield the signal.
1) Keep away from the router when using it.
2) Avoid using it on a metal table, which will affect the PCB antenna signal.
3) If you refit the speaker, if it is a metal shell, you must lead the antenna out of the shell. The metal shell will shield the signal.
Specification
Brand Name | Yourcee |
Model Number | 83866 |
Type | Professional Amplifier |
Channels | 2 (2.0) |
Place of Origin | China |
Guangdong |
