КПК междугородние системы Android Читатель UHF 860-960 МГц Impinj чип R2000 2-портовый портативный пда терминал Uhf

Dimensions

164.2 x 80.0 x 24.3mm / 6.46 x 3.15 x 0.96in

Weight

654g / 23.07oz

Display

5.2'' IPS FHD 1920x1080

Touch Panel

Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported

Power

Main battery: Li-ion, rechargeable, 8000mAh

Standby: over 500 hours

Continuous use: over 12 hours (depending on user environment)

Charging time: 3-4 hours (with standard adaptor and USB cable)

Expansion Slot

1 slot for SIM card, 1 slot for SIM or TF card

Interfaces

USB 2.0 Type-C, OTG, Octa-core version supports TypeC headphones

Audio

Speaker, 2 microphones

Keypad

4 front keys, 1 power key, 2 scan keys, 1 multifunctional key

Sensors

Gravity sensor, light sensor, proximity sensor

Operating Temp.

4°F to 122°F / -20°C to 50°C

Storage Temp.

-40°F to 158°F / -40°C to 70°C

Humidity

5% RH - 95% RH non condensing

Drop Specification

Multiple 1.5m/4.9ft drops (at least 20 times) to the concrete across the operating temperature range

Tumble Specification

1000 x 0.5m/1.64ft falls at room temperature

Sealing

Host IP65 per IEC sealing specifications

ESD

±15KV air discharge, ±6KV conductive discharge

Operating System

Android 6.0(Quad-core)/Android 8.1(Octa-core)

SDK

Chainway Software Development Kit

Language

Java

Tool

Eclipse / Android Studio

CPU

Cortex-A53 Quad-core 1.45GHz/Cortex-A53 Octa-core 2.5GHz

RAM+ROM

2GB+16GB(Quad-core)/ 3GB+32GB(Octa-core)

Expansion

Supports up to 128 GB Micro SD card

WLAN

IEEE802.11 a/b/g/n, 2.4G/5G dual-band, internal antenna

WWAN (China)

2G: 900/1800MHz

3G: 900/1900/2000/2100MHz

4G: B1, B3, B5, B38, B39, B40, B41

WWAN (Europe)

2G: 850/900/1800/1900MHz

3G: 850/900/1900/2100MHZ

4G: B1, B3, B5, B7, B8, B20, B40

WWAN (America)

2G: 850/900/1800/1900MHz

3G: 850/900/1700/1900MHZ

4G: B2, B4, B7, B12, B17

WWAN (Others)

Depending on the country's ISP

Bluetooth

Bluetooth 4.0, BLE

GNSS

GPS/AGPS, GLONASS, BeiDou; internal antenna

Note

C72 models being manufactured for Turkish Market, do not include Voice Call (Phone Call) function. WAN module included on those
models only support DATA transfer.

WLAN

IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna

WWAN (China)

2G: 900/1800MHz

3G: WCDMA: B1,B8

CDMA2000 EVDO: BC0

TD-SCDMA: B34,B39

4G: B1,B3,B5,B8,B34,B38,B39,B40,B41

WWAN(Overseas)

2G: 850/900/1800/1900MHz

3G: B1,B2,B4,B5,B8

4G: B1,B2,B3,B4,B5,B7,B8,B12,B17,B20,B25,B40,B66

WWAN (Others)

Depending on the country's ISP

Bluetooth

Bluetooth v2.1+EDR,3.0+HS,v4.1+HS

GNSS

GPS/AGPS, GLONASS, BeiDou; internal antenna

Engine

CM2000-1 module based on Impinj Indy R2000

Frequency

865MHz-868MHz / 920-925MHz / 902-928MHz

Protocol

EPC C1 GEN2 / ISO18000-6C

Antenna

Linear polarization(1.8dBi); circular polarization (4dBi)

Power

1W (30dBm, +5dBm to +30dBm adjustable)

2W Optional (33dBm, for Lati America, etc.)

R/W ranges

>7m (linear polarization, outdoors); >21m (linear polarization, indoors)

>10m (circular polarization, outdoors); >25m (circular polarization, indoors)

Reading rates (circular polarization)

>200 tags/s (circular polarization)

Note

*Ranges and rates depend on tags and environment

Note2

*This function is optional

1D Linear Scanner(Quad-core)

Zebra SE965 / Honeywell N4313

1D Symbologies

UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.

2D Imager Scanner(Quad-core)

Zebra: SE4710 / SE4750 / SE4750MR; Honeywell: N6603

2D Imager Scanner(Octa-core)

Zebra: SE4750/ SE4750MR

2D Symbologies

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US
Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.

Note

*This function is optional

Camera

13MP Autofocus with flash

Frequency

13.56MHz

Note

*This function is optional

Rate

<150ms

Range

20-40cm

FAR

1/10000000

Note

Protocol:ISO/IEC 19794-6,GB/T 20979-2007

Note2

*This function is optional
