Испытательный шкаф для зарядки и разрядки аккумулятора 5 В 100 А испытательное оборудование проверки жизненного цикла
- Категория: Battery Testers >>>
- Поставщик: Guangzhou,Minder-Hightech,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.38 $* | 0.79 $* |
| Aug-17-2025 | 0.4 $* | 0.62 $* |
| Jul-17-2025 | 0.8 $* | 0.44 $* |
| Jun-17-2025 | 0.8 $* | 0.27 $* |
| May-17-2025 | 0.34 $* | 0.39 $* |
| Apr-17-2025 | 0.50 $* | 0.28 $* |
| Mar-17-2025 | 0.27 $* | 0.86 $* |
| Feb-17-2025 | 0.11 $* | 0.28 $* |
| Jan-17-2025 | 0.49 $* | 0.44 $* |
Характеристики
Product Description
High-precision battery formation and capacity division system
1. Each unit has 8 channels, and each channel can be individually set to work steps and run independently;
2. Mainly used for 18650 and soft pack polymer battery charging and discharging capacity detection and charging and discharging cycle aging test;
3. Connect to a computer, with a PC upper computer, and automatically generate data files for all test results;
4. Working mode: charging (constant current charging and constant voltage charging), pause (standstill, shelving), discharge (constant current discharge);
5. The four-wire test method is adopted, with high accuracy;
6. Using advanced constant current source and constant voltage source technology, the loop has current and voltage limiting functions and battery reverse protection functions;
7. Intelligent power failure protection measures. During the battery test process, any time there is a power failure or power failure of the power supply system (cooperate with the UPS system to ensure that the system software exits normally), the test system can guarantee that no data will be lost. After power on again, The test system has a self-recovery function, which can seamlessly connect from the place where the power was lost last time and continue the test process.
2. Mainly used for 18650 and soft pack polymer battery charging and discharging capacity detection and charging and discharging cycle aging test;
3. Connect to a computer, with a PC upper computer, and automatically generate data files for all test results;
4. Working mode: charging (constant current charging and constant voltage charging), pause (standstill, shelving), discharge (constant current discharge);
5. The four-wire test method is adopted, with high accuracy;
6. Using advanced constant current source and constant voltage source technology, the loop has current and voltage limiting functions and battery reverse protection functions;
7. Intelligent power failure protection measures. During the battery test process, any time there is a power failure or power failure of the power supply system (cooperate with the UPS system to ensure that the system software exits normally), the test system can guarantee that no data will be lost. After power on again, The test system has a self-recovery function, which can seamlessly connect from the place where the power was lost last time and continue the test process.
Stable performance, high precision, simple operation
Lithium-ion battery capacity testing equipment
Lithium-ion battery capacity testing equipment
Application
It is suitable for the detection of the capacity of 18650, soft-pack polymer and other lithium-ion batteries and the
charge-discharge cycle aging test.
charge-discharge cycle aging test.
Specification
Device model | Macex-5V3A | Single channel Output power | 15W | Communication method | TCP/IP (Network port） | ||||
Discharge voltage | 5V-0.8V | Charging voltage | DC0-5V | data record | 100mS~65535 S | ||||
Recharging current | 5Vseries：0.02A~3A | Discharge current | 5Vseries：0.02A~3A | ||||||
Current accuracy | ±(0.05%RD+0.05%FS) | Voltage accuracy | ±(0.05%RD+0.05%FS) | ||||||
Voltage resolution | The smallest unit used by lmV equipment when detecting or setting voltage | ||||||||
Electric current resolution | The smallest unit used by lmA equipment when detecting or setting voltage | ||||||||
Charging mode | Constant current charging Constant voltage charging | ||||||||
Discharge mode | Constant current discharge. Constant power discharge | ||||||||
Charging cut-off condition | Voltage,current,time, capacity,temperature | ||||||||
Discharge cut-off condition | Voltage,current,time,capacity,temperature | ||||||||
All products can be customized with different voltages and currents according to customer needs
Our Factory
Why Choose Us
We can provide you with a full line of equipment for battery pack production.
We can provide you with the most competitive price directly from the factory.
We can provide you with the most professional after-sales service 7*24 hours.
We can provide you with the most competitive price directly from the factory.
We can provide you with the most professional after-sales service 7*24 hours.
Packing & Delivery
If you want to konw more,please contact our sales engineer:
