6101,6201 алюминиевый провод для электромонтажа
US $2200-$2800
Cca провод медный Плакированный Алюминий изолированный Стальной Эмалированный
- Категория: Aluminum Wire >>>
- Поставщик: Hangzhou,Jayuan,Industrial,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.70 $* | 0.76 $* |
| Aug-15-2025 | 0.73 $* | 0.40 $* |
| Jul-15-2025 | 0.95 $* | 0.85 $* |
| Jun-15-2025 | 0.99 $* | 0.30 $* |
| May-15-2025 | 0.40 $* | 0.66 $* |
| Apr-15-2025 | 0.99 $* | 0.92 $* |
| Mar-15-2025 | 0.13 $* | 0.4 $* |
| Feb-15-2025 | 0.83 $* | 0.63 $* |
| Jan-15-2025 | 0.83 $* | 0.42 $* |
Характеристики
Products Description
JAYUAN CCA Wire
Copper-clad aluminum wire has high electrical conductivity, enhanced tensile strength and elongation, and good weldability.
Copper-clad aluminum wire is covered with a layer of pure copper concentrically on its surface, so it has the same weldability as
pure copper wire, which greatly improves the mechanical properties and applicability of the product.
Advantages of JAYUAN CCA Wire
1.Lighter than copper:
The outer copper covers the inner aluminum core, combining the excellent electrical conductivity of copper with the lightness of aluminum.
2.Flexible:
2.Flexible:
It can be further processed into flat and thin lines like copper wire, and can be tinned.
3.Good ductility and cost savings:
3.Good ductility and cost savings:
CCA is about 32 to 40% as dense as copper and 2.45 to 3.00 times longer than copper of the same weight and diameter, which helps cable manufacturers reduce production costs.
4.Saving resources:
4.Saving resources:
Copper resources can be better saved by using coated copper.
5.Unpolluted:
5.Unpolluted:
No pollution is emitted during the production process.
6.Easy to transport:
6.Easy to transport:
Finished cables using copper wire are lighter.
Applications of JAYUAN CCA Wire
CCA wire widely used in Cable TV signal and large volume communications net work signal transmission, control signal cable,
welding cable and so on . High Frequency Signal Transmission : 1. TV coaxial cable 2. 50Ω Radio frequency (RF) cable 3. Flexible
RF coaxial cable inner conductor material 4. Computer cable and other data cable inner conductor material 5. Superfine coaxial
cable inner conductor material
welding cable and so on . High Frequency Signal Transmission : 1. TV coaxial cable 2. 50Ω Radio frequency (RF) cable 3. Flexible
RF coaxial cable inner conductor material 4. Computer cable and other data cable inner conductor material 5. Superfine coaxial
cable inner conductor material
Data of JAYUAN CCA Wire
Specification | Copper in volume (%) | Copper in mass (%) | Length comparison | Density (g/cm3) | Max.DC resistivity Ω.mm2/m (20°C) | Conductivity (%IACS) Min |
CCA-10%Copper | 8~12 | 27 | 2.65:1 | 3.32 | 0.02743 | 63 |
CCA-15%Copper | 13~17 | 37 | 2.45:1 | 3.63 | 0.02676 | 65 |
Copper Wire | 100 | 100 | 1:01 | 8.89 | 17241 | 100 |
Company Profile
About Us
Hangzhou Jayuan Industrial Co; Ltd.is specialized in manufacturing and trading of copper wire, CCA wire, CCAM wire and various cable conductors.Our company is located in Hangzhou city, Lin’an district.With over 20 years of experience we built a strong reputation in the industry.
We provide supporting services and material to several cable manufacturers, with outstanding product quality and perfect after sale service we have won wide acclaim from the industry.Due to our cooperation with the partner companies we are able to supply various types of cables and semi-finished products to our clients abroad as well as in the domestic market.
We provide supporting services and material to several cable manufacturers, with outstanding product quality and perfect after sale service we have won wide acclaim from the industry.Due to our cooperation with the partner companies we are able to supply various types of cables and semi-finished products to our clients abroad as well as in the domestic market.
Factory & Event Showcase
These are pictures of Wires' Production Line.
Due to China is also a Raw Copper Importer role in worldwide, so price of pure copper changes every day. So don't be upset if today's quote is high, maybe tomorrow it getting lower!
All the Factory normally purchase raw material copper, and drawing the wires themselves.
Wires have two types, as soft and hard.
We attended many exhibitions, went to Africa, Europe and Middle-east. They like our stable quality and understand our quotation plan.
Think stand as our Customers.
