Мягкая сталь S235jr /S355j2/S275jr HEA возд H
- Категория: Steel H-Beams >>>
- Поставщик: Jiangsu,Pulda,Metal,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 714.35 $* | 750.48 $* |
| Aug-18-2025 | 708.32 $* | 743.29 $* |
| Jul-18-2025 | 594.44 $* | 624.40 $* |
| Jun-18-2025 | 696.67 $* | 731.88 $* |
| May-18-2025 | 606.96 $* | 636.74 $* |
| Apr-18-2025 | 684.32 $* | 718.5 $* |
| Mar-18-2025 | 678.34 $* | 712.80 $* |
| Feb-18-2025 | 672.68 $* | 706.14 $* |
| Jan-18-2025 | 666.22 $* | 699.2 $* |
Характеристики
Product Display
Specification
Title goes here.
H-beam is named due to its shape. The parallel pieces are known as flanges, which are wider than I-beam – hence the name wide flange beam – and the line drawing included piece is called the web. Wide flange beam is also known as H-beam due to their distinctive shape, similar to a capital letter “H” when viewed at the cross section. This shape is very efficient for carrying loads of weight without bending.
H-beams are structural support materials that are primarily used for building. Able to bear excessive amounts of pressure, they ensure structural integrity and stability.
The thickness of the H-beam will determine the type of jobs it is best suited for. It is important to consider the force applied, the weight carried and the tension and compression. Smaller sizes are normally used for jobs where the amount of pressure and weight will be minimal, while larger thicker sizes of steel wide flange beams are used to support structures that bear massive amounts of weight.
H-beams are structural support materials that are primarily used for building. Able to bear excessive amounts of pressure, they ensure structural integrity and stability.
The thickness of the H-beam will determine the type of jobs it is best suited for. It is important to consider the force applied, the weight carried and the tension and compression. Smaller sizes are normally used for jobs where the amount of pressure and weight will be minimal, while larger thicker sizes of steel wide flange beams are used to support structures that bear massive amounts of weight.
Size | Wgt. Per Ft. | (A) Section Depth (In.) | (B) Web Thk. | (C) Flange Width | (D) Flange Thk. | |
W | 4 | 13 | 4.16 | 0.28 | 4.06 | 0.375 |
W | 5 | 16 | 5.01 | 0.26 | 5 | 0.36 |
19 | 5.15 | 0.27 | 5.03 | 0.43 | ||
W | 6 | 9 | 5.9 | 0.17 | 3.94 | 0.215 |
12 | 6.03 | 0.23 | 4 | 0.28 | ||
15 | 5.99 | 0.23 | 5.99 | 0.26 | ||
16 | 6.28 | 0.26 | 4.03 | 0.405 | ||
20 | 6.2 | 0.26 | 6.02 | 0.365 | ||
25 | 6.38 | 0.32 | 6.08 | 0.455 | ||
W | 8 | 10 | 7.89 | 0.17 | 3.94 | 0.205 |
13 | 7.99 | 0.23 | 4 | 0.255 | ||
15 | 8.11 | 0.245 | 4.015 | 0.315 | ||
18 | 8.14 | 0.23 | 5.25 | 0.33 | ||
21 | 8.28 | 0.25 | 5.27 | 0.4 | ||
24 | 7.93 | 0.245 | 6.495 | 0.4 | ||
28 | 8.06 | 0.285 | 6.535 | 0.465 | ||
31 | 8 | 0.285 | 7.995 | 0.435 | ||
35 | 8.12 | 0.31 | 8.02 | 0.495 | ||
40 | 8.25 | 0.36 | 8.07 | 0.56 | ||
48 | 8.5 | 0.4 | 8.11 | 0.685 | ||
58 | 8.75 | 0.51 | 8.22 | 0.81 | ||
67 | 9 | 0.57 | 8.28 | 0.935 |
Company Profile
Factory
Production Line
Shipping & Payment
Standard export package with care to prevent percussive damage or deformation
