ZOII производитель 10 мА 30 300 6A 20a 32A 40a 63a автоматический выключатель остаточного тока rcd
- Категория: >>>
- Поставщик: Zhejiang,Zhiyi,Electric,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.7 $* | 0.79 $* |
| Aug-19-2025 | 0.57 $* | 0.86 $* |
| Jul-19-2025 | 0.64 $* | 0.41 $* |
| Jun-19-2025 | 0.70 $* | 0.12 $* |
| May-19-2025 | 0.47 $* | 0.32 $* |
| Apr-19-2025 | 0.84 $* | 0.84 $* |
| Mar-19-2025 | 0.55 $* | 0.68 $* |
| Feb-19-2025 | 0.4 $* | 0.0 $* |
| Jan-19-2025 | 0.45 $* | 0.56 $* |
Характеристики
Products Description
General Introduction
DZ47-63 series earth leakage breaker is suitable for the leakage protection of the line of AC 50/60Hz, rated voltage single phase 240V, rated current up to 63A. When there is human electricity shock or if the leakage current of the line exceeds the prescribed value, it will automatically cut off the power within 0.1s to protect human safety and prevent the accident due to the current leakage. It can protect against overload and short-circuit. It can be used to protect the line from being overloaded and short circuited as well as infre-quent changeover of the line in normal situation. It complies with standard of IEC/EN61009-1 and GB16917.1.
DZ47-63 series earth leakage breaker is suitable for the leakage protection of the line of AC 50/60Hz, rated voltage single phase 240V, rated current up to 63A. When there is human electricity shock or if the leakage current of the line exceeds the prescribed value, it will automatically cut off the power within 0.1s to protect human safety and prevent the accident due to the current leakage. It can protect against overload and short-circuit. It can be used to protect the line from being overloaded and short circuited as well as infre-quent changeover of the line in normal situation. It complies with standard of IEC/EN61009-1 and GB16917.1.
Frame class | 63A |
Rated working voltage | 240V |
Rated frequency | 50/60Hz |
Rated working current | 6,10,16,20,25,32,40,50,63A |
Rated residual operating current | 0.01,0.03A |
Rated residual un-operating current | 0.005,0.015 |
Sensibility | AC Type |
Maximum operating time | In t≤0.4s , 5In t≤0.01 |
Instant release type | B,C type |
Limiting value of un-operating current | 6In |
Rated limiting short-circuit current | 10000A |
Feature
The handle being sealable or equipped with padlock bracket avoids dangerous operation changes (ON / OFF)
Clear indication of the contact position
Energy limiting class: 3
The emission of ionized gases is limited to the severest restrictions: 45 mm grid distance
Suitable for household or similar applications in accordance with:
IEC 61009-1, tripping characteristics B, C and D.
The handle being sealable or equipped with padlock bracket avoids dangerous operation changes (ON / OFF)
Clear indication of the contact position
Energy limiting class: 3
The emission of ionized gases is limited to the severest restrictions: 45 mm grid distance
Suitable for household or similar applications in accordance with:
IEC 61009-1, tripping characteristics B, C and D.
