1 2 T/1 5 7 T гидравлический мини-экскаватор погрузчик с конкурентоспособными ценами соответствует CE/EPA/EURO

Описание и отзывы

Трекер стоимости

Характеристики

1.2T/1.5T/1.7T hydraulic mini excavator mini digger loader bagger with competitive prices meet CE/EPA/EURO 5 emission





model	DE1017
Standard shovel capacity	0.022-0.045m³	Swing(optinal)	75° left / 45° right
Working device form	Backhoe	Pumps	Gear pump
Rated power	8.6kw/12.3kw/15.4kw	Ground pressure	0.35MPa
Wheelbase	680mm	track width	180mm
Caterpillar chief	1200mm	Minimum radius of revolution(front)	1290mm
Platform clearance	370mm	Maximum lift height of earth shovel	260mm
width of bulldozer	860mm	Maximum digging depth of earth shovel	190mm
Emgine Model	KP-192FA	Swing speed	1.1R/MIN
Cooling	Air-cooling	Fuel Tank	5.5L



Running system

1,Designed for DEGRAS main pump, main valve, rotary motor and walking motor to ensure high reliability of hydraulic system.
2,Travel motor come with three hose, one is the unloading pipe, prevents the internal pressure of the motor from being too high, and the internal high-temperature oil will be discharged in the unloading pipe to improve the service life of the traveling motor.
Oil supply system
1,lubricating oil pressure alarm system for protect the machine, it will be alarm automatically if no lubricating oil.
2,The hydraulic tank breathing valve has a pressure compensating valve and air filtering function. The other manufacturers' machines are only one cover, no pressure.
3,The entrance of the hydraulic oil tank is equipped with magnets to prevent tiny objects such as rust from entering the hydraulic oil tank.
