Huawei V5 Rack 1288H Fusionserver Pro Rh1288 2U V3 1U Network 2488H Intel Xeon 2-Socket Rerver высококачественный 2288H
- Категория: Servers >>>
- Поставщик: Beijing,Huaying,Communication,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 1295.27 $* | 1360.44 $* |
| Aug-19-2025 | 1284.57 $* | 1348.30 $* |
| Jul-19-2025 | 1077.47 $* | 1131.96 $* |
| Jun-19-2025 | 1262.0 $* | 1325.53 $* |
| May-19-2025 | 1099.80 $* | 1154.78 $* |
| Apr-19-2025 | 1240.21 $* | 1302.35 $* |
| Mar-19-2025 | 1229.66 $* | 1290.74 $* |
| Feb-19-2025 | 1219.90 $* | 1280.0 $* |
| Jan-19-2025 | 1208.11 $* | 1268.9 $* |
Характеристики
Product Description
HUAWEI FusionServer Pro 5288 V5 Rack Server
Huawei FusionServer Pro 5288 V5 is a 4U2 rack server, which is suitable for hot, warm and cold data hierarchical deployment,historical data archiving and other business needs. With efficient design, while ensuring excellent computing performance, it provides flexible and ultra-large capacity local storage expansion. Ability to reduce data storage costs. 5288 V5 can configure 2-way processors, 24 DDR4 memory and 44*3.5" +4*2.5 (up to 8*NVMe SSD) local storage resources in 4U space. It integrates patented technologies such as DEMT intelligent power consumption management and FDM intelligent fault management, and can be configured with Huawei FusionDirector full life cycle management software, which can effectively reduce operating costs and improve
investment returns.
investment returns.
Specification
model number | FusionServer Pro 5288 V5 |
form | 4U rack server |
processor | 1/2 first-generation Intel® Xeon® scalable processing 3100/4100/5100/6100/8100 series, up to 205W 1/2 second-generation Intel® Xeon® scalable processing 3200/4200/5200/6200/8200 series, up to 205W |
memory | 24 DDR4 memory slots, up to 2933MT/s, up to 12 Intel® AotengTM persistent memory 100 series, up to 2666MT/s |
Local storage | Front end: • 24 3.5-inch SAS/SATA hard disks can be configured Built-in: • 4 3.5-inch SAS/SATA hard disks can be configured Backend: • 16 3.5-inch SAS/SATA hard disks can be configured • 16 3.5-inch SAS/SATA hard disks + 4 2.5-inch SAS/SATA/NVMe SSD hard disks can be configured • 14 3.5-inch SAS/SATA hard disks (4 NVMe SSD disks are supported by NVMe models) + 4 2.5-inch SAS/SATA/NVMe SSD hard disks can be configured (the built-in hard disks and IO module 1 cannot be configured when selecting this configuration) Support Flash storage: • Dual M.2 SSDs |
RAID support | Optional support for RAID0, 1, 5, 50, 6, 60, etc., support Cache super capacitor protection, provide RAID-level migration, disk roaming, self-diagnosis, Web remote settings and other functions. |
network | • On-board network card: 2 10GE interfaces and 2 GE interfaces • Flexible card: optional 2*GE or 4*GE or 2*10GE or 1/2 56G FDR IB interfaces |
PCIe extension | Up to 10 PCIe 3.0 expansion slots, including 1 PCIe expansion card dedicated to RAID card and 1 flexible LOM plug-in card |
fan | 4 hot-plug fans, support N+1 redundancy |
power supply | It can be configured with 2 redundant hot-swappable power supplies and supports 1+1 redundancy. The optional specifications are as follows: • 900W AC PLATINUM POWER SUPPLY • 1500W AC Platinum Power Supply |
management | • Huawei iBMC chip integrates 1 dedicated management GE network port to provide comprehensive fault diagnosis, automated operation and maintenance, hardware security reinforcement and other management features • iBMC supports standard interfaces such as Redfish, SNMP, IPMI2.0, etc.; provides a remote management interface based on HTML5/VNC KVM; supports CD-free deployment and Agentless features to simplify management complexity • It can be configured with Huawei FusionDirector management software to provide stateless computing, OS batch deployment, firmware automatic upgrade and other advanced management features to realize intelligent and automated management throughout the life cycle. |
Product certification | CE, UL, FCC, CCC, RoHS, etc. |
installation kit | L-shaped slide, retractable slide, rail holding |
Dimensions (height x width x depth) | Chassis size: 175 mm×447 mm×748 mm |
operating temperature | 5oC - 40oC (ASHRAE A3 standard) |
operating temperature | 5oC - 40oC |
Details Images
Chassis appearance display
Front of model
Rear of model
Model side
Packing&Shipping
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Packing & Delivery
All the products are shipped in one piece at Beijing and hongkong.
phone：00852-56466680
Wechat: 15901547465
E-mail:huayingxintong@163.com
Company Introduction
Huaying Communication Technology Co., Ltd. is an excellent IT hardware supplier. It is headquartered in Beijing and has branches in many places. Its products are exported to home and abroad. It can provide notebook computers, routers, switches, servers, firewalls, video surveillance, optical access / transmission networks, wireless products, 5g / consumer it equipment and other products. We have an excellent sales team and technical team to provide you with free consultation, high-quality technical support and thoughtful after-sales service at any time. We look forward to working with you.
Our Services & Strength
Huaying communication always adheres to the development concept of "customer first, efficient cooperation, gratitude, innovation and conservation", constantly strengthens innovation, opens branches and offices in provinces and cities across the country, and provides users with complete marketing localization, implementation localization and service localization. Users are all over education, military, government, medical treatment, transportation, finance, scientific research, coal, energy, insurance, manufacturing and other industries. Provide more users with "private customization" intelligent solutions。
Certifications
