4.0MP 2560P номерной знак LPR захвата Ip! Внешняя водозащитная камера для парковки с POE

Kvx131-4b series intelligent HD vehicle identification all-in-one machine uses low-power high-performance AI processor and 4 million

Pixel star CMOS sensor is an intelligent license plate sensor integrating license plate detection, recognition, orientation and management Identify the device. This series not only provides 4 million ultra-high definition imaging, various license plate / vehicle information recognition, surveillance video Intelligent lighting, front-end storage and other features. It also supports license plate anti-counterfeiting, cloud remote operation and maintenance, offline ad hoc network and other features,

Guarantee the 7 * 24-hour uninterrupted operation of unattended business, and greatly reduce the after-sales maintenance cost.

1.2 main features 1.2.1 4 million HD imaging effect .Kvx131-4b intelligent HD vehicle identification all-in-one machine is equipped with the industry's advanced 4 million star imaging solution

It supports video and picture output with a maximum resolution of 2560 * 1440. In an environment with the same imaging effect,

The definition of kvx131-4b intelligent HD vehicle identification all-in-one machine is more than 80% higher than that of ordinary 2 million cameras. Coordination wisdom

It can deeply learn anti-counterfeiting ISP (image signal processing) algorithm, which can not only meet the whole scene recognition of customer license plate recognition

It can provide more vehicle details and help to improve the recognition rate of the algorithm.

Kvx131-4b intelligent high-definition vehicle recognition all-in-one machine is equipped with intelligent deep learning algorithm -- it adopts cutting-edge technology in the industry

AI deep learning technology successfully creates a powerful algorithm box in the field of license plate / vehicle recognition through learning massive data

Product specification of smart series 4 million HD vehicle identification all-in-one kvx131-4b

Rack. Through in-depth optimization with kvx131-4b series hardware, it can effectively solve the needs of all intelligent transportation business scenarios

Please.

The recognition rate of typical license plate is 99.9%: it supports the recognition of ordinary blue license plate, new energy license plate and single and double-layer yellow license plate (including mud head)

Vehicle), single and double deck military / police plates, embassies and consulates, Hong Kong and Macao Entry and exit mainland license plates, emergency license plates and other license plates

Color, type, etc. the recognition rate of mainstream license plates in typical scenes is as high as 99.9%.

Deep learning anti-counterfeiting and filtering fake license plates: using self-developed deep convolution neural network algorithm

Data learning can effectively extract the global and local features in the image and accurately identify the authenticity of the license plate.

Large angle recognition: it supports the recognition of the maximum 45 degree angle between the license plate and the camera, and the camera is more adaptable to the environment.

The license plate recognition camera operation and maintenance management cloud platform VDS is designed for big data operation, remote centralized management and other needs

Cloud integrated business management platform. The license plate recognition camera operation and maintenance management cloud platform VDS provides customers with remote access vehicles

Card recognition camera solution. Customers can realize the remote operation and maintenance of control equipment on the platform, and can also integrate quickly

To their own operation and maintenance management platform. Break through the geographical restrictions of traditional networks, realize remote access and centralized operation and maintenance of cameras,

Realize the Internet of isolated scenes. Provide assistance for the customer's unattended parking lot system and improve one-on-one maintenance personnel

One to many on-site maintenance is one to many remote maintenance, which reduces the operation and maintenance labor cost for customers and improves customer service efficiency.

1.2.4 stable and reliable performance, rich and diverse interfaces

Kvx131-4b intelligent high-definition vehicle identification all-in-one machine provides 15 inch product form and adopts high IP protection

Level design to ensure long-term stable and reliable operation in typical scenarios.

Product specification of smart series 4 million HD vehicle identification all-in-one kvx131-4b

Kvx131-4b supports up to 2-way input, 2-way output and 2-way RS485. The interface surge protection level is:

6KV. (exceeding national standard level 4). It can meet the daily connection of ground induction coil, gate, LED display screen, etc

Many equipment requirements;

Support TF card data storage, no loss of network disconnection data, and real-time storage of system logs;

1.2.5 all round development and docking support

SDK development kit: provide SDK development kits for windows, Linux and Android environments, and support VB, c#

Delphi, C + + and other development languages;

API protocol interface: support API interfaces based on TCP, HTTP, mqtt and other standard protocols to meet camera and platform requirements

Docking of station system;

1.3 application scenarios

This product has richer functions and interfaces, providing users with a variety of choices to meet the different needs of various application scenarios

Please. This product is widely used in various parking lot entrances and exits, community entrances and exits, expressway entrances and exits, and new energy charging

Pile, garage floor lock, unmanned car wash shop, car 4S shop, unattended weighing and other scenes help unattended, especially

It is applicable to operating parking lots with large traffic flow and high revenue flow.
