Китайский поставщик оптовая продажа профессиональный ремесленный резиновый смешиватель для оборудования обработки
- Категория: >>>
- Поставщик: Qingdao,Hangsen,Industry,And,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.91 $* | 0.8 $* |
| Aug-16-2025 | 0.59 $* | 0.77 $* |
| Jul-16-2025 | 0.85 $* | 0.69 $* |
| Jun-16-2025 | 0.69 $* | 0.65 $* |
| May-16-2025 | 0.1 $* | 0.25 $* |
| Apr-16-2025 | 0.49 $* | 0.1 $* |
| Mar-16-2025 | 0.12 $* | 0.13 $* |
| Feb-16-2025 | 0.86 $* | 0.51 $* |
| Jan-16-2025 | 0.27 $* | 0.27 $* |
Характеристики
1..Four shaft head sealing, using new technology of YG8 cemented carbide Mosaic, not leak powder and glue.
2..The mixing chamber using the 20 # boiler plate which is processing by forging and fire.
3..The two Shaft is to use high-quality steel 42 Cr Mo (Grom) made by forging heat treatment.
4..The rotor shaft spindle seam D632 hard alloy welding electrode welding.
5.Two support the rotor shaft bolt and the mixing chamber after polishing hard chromium plating of 0.15-20m not only corrosion, rust, and hard wear.
6.Two rotor shaft, mixing chamber, top bolt, gearbox casing and so on , polishing after heat treatment furnace, temperature 6-700 degrees, eliminate stress, enhancing the toughness, increased by more than five times of the service life.
2..The mixing chamber using the 20 # boiler plate which is processing by forging and fire.
3..The two Shaft is to use high-quality steel 42 Cr Mo (Grom) made by forging heat treatment.
4..The rotor shaft spindle seam D632 hard alloy welding electrode welding.
5.Two support the rotor shaft bolt and the mixing chamber after polishing hard chromium plating of 0.15-20m not only corrosion, rust, and hard wear.
6.Two rotor shaft, mixing chamber, top bolt, gearbox casing and so on , polishing after heat treatment furnace, temperature 6-700 degrees, eliminate stress, enhancing the toughness, increased by more than five times of the service life.
Model | X(S)N35 | X(S)N55 | X(S)N75 | X(S)N110 |
Total volume of mixing chamber (L) | 75 | 125 | 180 | 250 |
Working volume of mixing chamber (L) | 35 | 55 | 75 | 110 |
Driving motor power (KW) | 55 | 75 | 110 | 185 |
Tilting motor power (KW) | 5.5 | 5.5 | 5.5 | 7.5 |
Tilting angle | 110 | 110 | 110 | 110 |
Rotational speed of the rotor ( front/rear) (r/min) | 36/30 | 36/30 | 36/30 | 30/24.5 |
Pressure of compressed air (Mpa) | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
Cooling water pressure (Mpa) | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 |
Size (L*W*H) (mm) | 3150*1900*2880 | 3280*2120*3090 | 3280*2220*3250 | 4070*2712*3580 |
QINGDAO HANGSEN INDUSTRY AND TRADE CO., LTD was established in 1967，have employee more than two hundred, which have two factories. we are manufacturer for package machine and rubber machine, which have more than forty years’ experience. Packaging machinery includes high speed flute laminator, middle speed flute laminator, 5 ply flute laminator, cardboard laminator, flip flop stacker machine as well as other related paper package machines.
For rubber machine, we mainly produce rubber kneader series, rubber mixing mill series, rubber extruder and strainer series, rubber powder line, rubber reclaim sheet line, rubber tube line, rubber mat line, tire making line and so on, we can make more than 200 series rubber machines, including environment protect machines, we also can make rubber machine according to customers requirement.
Till now, HANGSEN have exported to more than forty counties. including USA, Greece, Spain, Poland, France, Italy, Algeria, Egypt, India, Russia, Argentina, Vietnam, Brazil, Indonesia, Thailand and so on.
The company uses exquisite and professional technology to serve all customers and is widely praised and appreciated by customers.
For rubber machine, we mainly produce rubber kneader series, rubber mixing mill series, rubber extruder and strainer series, rubber powder line, rubber reclaim sheet line, rubber tube line, rubber mat line, tire making line and so on, we can make more than 200 series rubber machines, including environment protect machines, we also can make rubber machine according to customers requirement.
Till now, HANGSEN have exported to more than forty counties. including USA, Greece, Spain, Poland, France, Italy, Algeria, Egypt, India, Russia, Argentina, Vietnam, Brazil, Indonesia, Thailand and so on.
The company uses exquisite and professional technology to serve all customers and is widely praised and appreciated by customers.
