Горячая Распродажа SI8232BB-D-ISR доставка Оригинального
- Категория: Other Electronic Accessories >>>
- Поставщик: Shenzhen,Nuoxin,Microelectronics,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.75 $* | 0.26 $* |
| Aug-19-2025 | 0.32 $* | 0.90 $* |
| Jul-19-2025 | 0.87 $* | 0.70 $* |
| Jun-19-2025 | 0.97 $* | 0.5 $* |
| May-19-2025 | 0.85 $* | 0.82 $* |
| Apr-19-2025 | 0.29 $* | 0.1 $* |
| Mar-19-2025 | 0.10 $* | 0.2 $* |
| Feb-19-2025 | 0.36 $* | 0.92 $* |
| Jan-19-2025 | 0.89 $* | 0.58 $* |
Характеристики
Product Description
Product Paramenters
Part Number | SI8232BB-D-ISR |
Description | DGTL ISO 2.5KV GATE DRVR 16SOIC |
Minimum Quantity | 1250 |
Packaging | Tape & Reel (TR) |
Series | Automotive, AEC-Q100 |
Technology | Capacitive Coupling |
Number of Channels | 2 |
Voltage - Isolation | 2500Vrms |
Common Mode Transient Immunity (Min) | 20kV/µs |
Propagation Delay tpLH / tpHL (Max) | 60ns, 60ns |
Pulse Width Distortion (Max) | 5.6ns |
Rise / Fall Time (Typ) | 20ns, 20ns (Max) |
Current - Output High, Low | 250mA, 500mA |
Current - Peak Output | 500mA |
Voltage - Forward (Vf) (Typ) | - |
Current - DC Forward (If) (Max) | - |
Voltage - Supply | 9.4 V ~ 24 V |
Operating Temperature | -40°C ~ 125°C |
Mounting Type | Surface Mount |
Package / Case | 16-SOIC (0.295", 7.50mm Width) |
Supplier Device Package | 16-SOIC |
Approvals | CQC, CSA, UR, VDE |
