Горячая Распродажа SD103CWS-HG3-08 доставка Оригинального
- Категория: Other Electronic Accessories >>>
- Поставщик: Shenzhen,Nuoxin,Microelectronics,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.87 $* | 0.6 $* |
| Aug-19-2025 | 0.37 $* | 0.52 $* |
| Jul-19-2025 | 0.23 $* | 0.6 $* |
| Jun-19-2025 | 0.33 $* | 0.94 $* |
| May-19-2025 | 0.3 $* | 0.6 $* |
| Apr-19-2025 | 0.37 $* | 0.93 $* |
| Mar-19-2025 | 0.35 $* | 0.53 $* |
| Feb-19-2025 | 0.15 $* | 0.40 $* |
| Jan-19-2025 | 0.32 $* | 0.80 $* |
Характеристики
Product Description
Product Paramenters
Part Number | SD103CWS-HG3-08 |
Description | DIODE SCHOTTKY 20V 350MA SOD323 |
Minimum Quantity | 15000 |
Packaging | Tape & Reel (TR) |
Series | Automotive, AEC-Q101 |
Diode Type | Schottky |
Voltage - DC Reverse (Vr) (Max) | 20V |
Current - Average Rectified (Io) | 350mA (DC) |
Voltage - Forward (Vf) (Max) @ If | 600mV @ 200mA |
Speed | Fast Recovery =< 500ns, > 200mA (Io) |
Reverse Recovery Time (trr) | 10ns |
Current - Reverse Leakage @ Vr | 5µA @ 10V |
Capacitance @ Vr, F | 50pF @ 0V, 1MHz |
Mounting Type | Surface Mount |
Package / Case | SC-76, SOD-323 |
Supplier Device Package | SOD-323 |
Operating Temperature - Junction | 125°C (Max) |
