60 кв. м 40FL дома с ванной комнаты и кухонными окнами Таиланд большая Греция США складной контейнер дом для
- Категория: Prefabricated Buildings >>>
- Поставщик: Xiamen,Sunfine,Architect,&,Construction,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-19-2025 | 32.92 $* | 33.84 $* |
| Jul-19-2025 | 26.27 $* | 27.36 $* |
| Jun-19-2025 | 31.30 $* | 32.42 $* |
| May-19-2025 | 31.54 $* | 32.48 $* |
| Apr-19-2025 | 25.40 $* | 26.29 $* |
| Mar-19-2025 | 31.79 $* | 32.8 $* |
| Feb-19-2025 | 30.16 $* | 31.82 $* |
| Jan-19-2025 | 30.27 $* | 31.6 $* |
Характеристики
Product Description
Sunfine container modular house and prefabhouses that can be used as a granny flat, spare room, rental investment, first home,downsizing,deluxe mining camp accommodation, coffee shop,crib room, training room, office and accommodation for caravan & holiday parks, bed and breakfasts and more!
Technical parameters of folding room | ||||||
type | Specifications | Material name | model | thickness | Company | number |
basic features | External dimension (mm) | 5800*2480*2560 | ||||
Internal dimension (mm) | 5640*2320*2420 | |||||
Folding state (mm) | 5800*2480*380 | |||||
Total mass (kg) | 1200 | |||||
Design parameters | Structural design service life | 10 years | ||||
Ground live load | 200kg/sqm | |||||
Roof live load | 100kg/sqm | |||||
Wind load | Grade 8 | |||||
seismic fortification intensity | Grade 10 | |||||
frame structure | Top frame | Q235B rectangular square tube | 40*80*2.44m | 1.8 | root | 5 |
Q235B rectangular square tube | 20*40*5.9m | 1.8 | root | 1 | ||
Q235B rectangular square tube | 80*80*5.64m | 1.8 | root | 2 | ||
P-tube | 40*80 | 1.8 | root | 2 | ||
Galvanized sheet | 5.75m*1.5m | 0.8 | block | 2 | ||
Glass wool | 12m*1.5m | 0.75 | rice | 12 | ||
Ceiling board | 0.37 | block | 3 | |||
5.8m noodles | Q235B rectangular square tube | 40*80 | 1.8 | root | 8 | |
L-shaped steel plate (galvanized sheet) | 1.165m | 2 | block | 4 | ||
L-shaped steel plate (galvanized sheet) | 1.180m | 2 | block | 4 | ||
P-tube | 40*80*5.84m | 1.8 | root | 8 | ||
P-tube | 1.05m | 1.8 | root | 4 | ||
Hinge | High strength | 1.8 | individual | 34 | ||
wallboard | 1080*2.88m | 0.3 | block | 8 | ||
Galvanized angle | 1.08m | 0.8 | root | 16 | ||
D-type E-type adhesive tape | 5.9m | root | 24 | |||
2.35m noodles | P-tube | 2640 | 1.8 | root | 4 | |
2485 | 1.8 | root | 4 | |||
2400 | 1.8 | root | 1 | |||
860 | 1.8 | root | 1 | |||
wallboard | 950 | 0.3 | rice | 8.66 | ||
Galvanized angle | 50# | 0.8 | rice | 20.41 | ||
window | individual | 2 | ||||
Hanging head baffle | block | 8 | ||||
door | individual | 1 | ||||
Black tape | rice | 21.32 | ||||
Bottom frame | Custom sill (galvanized sheet) | 160*80*5.9m | 2 | root | 2 | |
80*80 | 1.8 | root | 2 | |||
Hinge | High strength | individual | 4 | |||
C-section steel | 1.8 | root | 14 | |||
floor | 1165*2690 | 15mm | block | 5 | ||
Angle steel | 30# | root | 3.5 | |||
Top of box | Integral frame coating | Electrostatic spraying / direct white plastic powder | ||||
External roof | Galvanized sheet 0.8mm | |||||
Interior ceiling | Color steel veneer V / 830 / 0.37mm | |||||
wallboard | 5.8m noodles | 75mm composite board 0.3mm + glass wool (unit weight: 28KG) + 0.3mm | ||||
2.48M noodles | 75mm composite board 0.3mm + glass wool (unit weight: 28KG) + 0.3mm | |||||
floor | Fireproof glass magnesium floor 15mm | |||||
electrical system | Electrical wiring, in strict accordance with the moisture-proof standard installation, all electrical products meet CE certification. Connect the circuit according to the code of circuit engineering, indoor: incoming wire 4? GB soft copper wire, 1 20A circuit breaker, 2.5? 2 socket, 1 5-hole single opening socket, 1 5-hole socket, 1 LED lamp | |||||
anti-theft door | High quality security door (warm white) size: 960mm * 1970mm | |||||
window | 920 * 920 single glass sliding window, plastic steel window, with protective fence, screen window, glass thickness of 4mm (warmwhite) | |||||
Related Products
Company Information
Established in 2011, Xiamen Sunfine Architect & Construction Co., Ltd islocated in Xiamen City, Fujian Province. With only 1 hour away from Xiamen seaport and airport, We can provide an efficient logistic solution to global customers
Sunfine is specialized in manufacturing below products:
1. Various prefabricated house
2. Modular housing
3. Garden studio
4. Luxury Villa
5. Social housing
6. Complete resort project
7. Apartment
8. Container house
9. Cheap housing solutions
10. Emergency shelter and emergency housing for government and situated
We can provide our customers with one-stop service from design to construction according to customers' different needs. With a professional vision, we provide customers such as business plans in the project area, the layout of mobile villas, the number of rooms allocated, and the investment recovery period. Sunfine is willing to work with you to create a better future.
FAQ
Q1:What products do you offer?
A1:We focus on prefab houses, dome houses, steel structure, container house, modular villa and so on.
Q2:How is your after-sales service?
A2:Any question, welcome to contact us.24 hours available for you.
Q3:What information should we offer before you quote?
A3:you have the drawing, pls give us and tell us the material you use. If no drawing, pls tell
us the usage and the size of the house, then we design for you with the good price.
us the usage and the size of the house, then we design for you with the good price.
Q4:Can you help to purchase the appliances and install inside?
A4:One-stop Service. Please tell me what you need.
Q5:If I want to custom different color and size?
A5:Of course. we can provide OEM service. But the MOQ is 10 sets for color and 30sets for size.
