Cpt зубчатый шкив ремень 15 зубьев резак для варочной

Cpt зубчатый шкив ремень 15 зубьев резак для варочной

Категория: Power Transmission Parts >>>
Поставщик: Hunan,Langle,Technology,Co.,Ltd.

Цена:5,00 $ - 15,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-18-2025	6.52 $*	6.39 $*
Jul-18-2025	5.0 $*	5.85 $*
Jun-18-2025	6.43 $*	6.90 $*
May-18-2025	6.54 $*	6.58 $*
Apr-18-2025	5.93 $*	5.28 $*
Mar-18-2025	6.65 $*	6.90 $*
Feb-18-2025	6.7 $*	6.61 $*
Jan-18-2025	6.59 $*	6.7 $*

Характеристики

cpt timing pulley timing belt pulley 15 teeth timing pulley hob cutter

1) Warranty: our timing pulley's quality is very good and with ensurance within 1 year, when you receive the products and find quality problems, we promise you could return it back and free maintenance.

2) Drawings: please send you timing pulleys' drawings to us to get the best quotation; If you have no drawings, then we could work out CAD drawings and the best quotation to you ASAP.

3) Sample: we accept 1 piece sample's order, we could do samples until you're satisfied.

4) Confidentiality agreetment: Strictly adherence to client confidentiality agreetment for timing pulleys.

Product Description

Product Name	Timing Belt Pulley
Teeth profile	Trapezoidal toothed	MXL, XXL, XL, L, H, XH, XXH
	T-toothed	T2.5, T5, T10, T20
	Arc toothed	HTD3M, HTD5M, HTD8M, HTD14M, HTD20M, Gt2, Gt3, Gt5
	S-toothed	S2M, S3M, S4.5M, S5M, S8M, S14M
	Parabolic-toothed	P2M, P3M, P5M, P8M, P14M
	Y-toothed	G2M, G3M, G5M, Y8M
Teeth Quantity	10-150 teeth or customized
Inner Bore	2-200mm H7 precision or customized
Belt width	4mm, 6mm, 9mm, 10mm, 12mm, 15mm, 20mm, 25mm, 30mm, 40mm, 50mm, 1/4'', 5/16'', 3/8'', 1/2'', 3/4'', 1'', 1.5'', 2''or customized
Accessories	We can provide the service of assembling setscrews, bearings, shafts or taper bush
Surface treatment	Anodize,Black Oxide,Phosphate and Galvanization
Drawing Format	Timing belt pulley cad drawing,timing belt pulley UG drawing,Timing belt Pulley Soliwork drawing,Timing Pulley PDF drawing

What is timing pulley?

Timing pulleys are specialized pulleys that have either teeth or pockets around the outside diameter of the pulley body. Timing teeth engage holes in the metal belt, while timing pockets engage drive lugs on a belt's inner circumference. These teeth or pockets are used only for timing, not for power transmission.

How timing pulleys work?

The synchronous wheel transmission is composed of an endless belt with equal-spaced teeth on the inner peripheral surface and a pulley with corresponding teeth. During operation, the toothed teeth mesh with the tooth grooves of the pulley to transmit motion and power, which is integrated with the belt. A new type of belt drive with the advantages of transmission, chain drive and gear transmission.

What is gt2 timing pulley?

2mm pitch GT2 Pulley. The GT2 or 2GT Tooth Profile timing pulley prevails in the 3d printing hobby cause the Round tooth profile brings high precision of non-backlash, were known as today's Reprap Pulley.

What is a timing pulley flange?

Timing pulley flanges are used to maintain belt contact with a timing pulley in power transmission applications.Timing pulley flanges are manufactured to fit timing pulleys of the same pitch and size. The dimensions of a pitch, including the mating flange, are specified by the number of grooves.

Note:Please confirm you need teeth profile, teeth quantity, belt width, bore diameter, quantity and type (please refer below drawings) to get our the most complete CAD drawings and the best quotation.
