35 градусов 0 5 м/с vvf привод наружный или внутренний эскалатор метро
- Категория: Escalators >>>
- Поставщик: G.,Loong,Elevator,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 15470.63 $* | 16244.90 $* |
| Aug-19-2025 | 15340.55 $* | 16107.36 $* |
| Jul-19-2025 | 12870.51 $* | 13514.37 $* |
| Jun-19-2025 | 15080.39 $* | 15834.81 $* |
| May-19-2025 | 13130.26 $* | 13787.72 $* |
| Apr-19-2025 | 14820.42 $* | 15561.73 $* |
| Mar-19-2025 | 14690.78 $* | 15425.26 $* |
| Feb-19-2025 | 14560.90 $* | 15288.19 $* |
| Jan-19-2025 | 14430.52 $* | 15152.51 $* |
Характеристики
Specifications
Products Performance & Parameter
Items | Products Specification GLE100 | ||||
Indoor | Semi-outdoor | Outdoor | |||
Power supply | 3phase 5 wire 380V/50Hz | 3phase 5 wire 380V/50Hz | 3phase 5 wire 380V/50Hz | ||
Truss | Angle-iron | Angle-iron | Angle-iron | ||
Inclination | 30°（2m≤H≤7.8m） 35°（2m≤H≤6.0m） | 30°（2m≤H≤7.8m）35°（2m≤H≤6.0m） | 30°（2m≤H≤7.8m）35°（2m≤H≤6.0m） | ||
Step Width | 600, 800, 1000 | 600, 800, 1000 | 600, 800, 1000 | ||
Jobsite power | Standard AC380V | Standard AC380V | Standard AC380V | ||
Jobsite power frequency | 50Hz, 60Hz | 50Hz, 60Hz | 50Hz, 60Hz | ||
Horizontal step | H≤6.0m 2steps, 3steps 2m≤H≤7.8m 3steps | H≤6.0m 2steps, 3steps2m≤H≤7.8m 3steps | H≤6.0m 2steps, 3steps2m≤H≤7.8m 3steps | ||
Balustrade height | 0.9m, 1.0m | 0.9m, 1.0m | 0.9m, 1.0m | ||
Handrail belt | G.Loong, EHC | G.Loong, EHC | G.Loong, EHC | ||
Handtail Color | Black, Red | Black, Red | Black, Red | ||
Traction machine | Worm gear | Worm gear | Worm gear | ||
Gear box | G.Loong, Flender(Siemens) | G.Loong, Flender(Siemens) | G.Loong, Flender(Siemens) | ||
Step | Stainless steel, Aluminium Alloy | Stainless steel, Aluminium Alloy | Stainless steel, Aluminium Alloy | ||
Products & scenarios
Company Profile
Project references
Service
FAQ
1. Where is your company?
Our company located in Zhejiang province Nanxun district. Around 3 hours to Shanghai port and 4 Hours to Ningbo port.
2.ARE YOU A DIRECT MANUFACTURER OR TRADING COMPANY?
Our company located in Zhejiang province Nanxun district. Around 3 hours to Shanghai port and 4 Hours to Ningbo port.
2.ARE YOU A DIRECT MANUFACTURER OR TRADING COMPANY?
We are one direct elevator manufacturer.
3.CAN YOU DO CUSTOMIZED PRODUCTS?
Yes, our target is always find out the most optimized solution, both on commercial and technique.
4.WHAT’S THE PAYMENT TERM?
3.CAN YOU DO CUSTOMIZED PRODUCTS?
Yes, our target is always find out the most optimized solution, both on commercial and technique.
4.WHAT’S THE PAYMENT TERM?
When we quote for you,we will confirm with you the way of transaction,FOB,CIF,CNF,etc. payment can be
T/T or L/C.
5.What is the guarantee period of your products?
Our regular warranty of the products is 12months, it calculate from the day that the goods are shipping out from our factory, also
you can choose optional warranty package with cost, the warranty package enhance the warranty from 12months to 36months max;
6.WHERE ARE YOUR PRODUCTS MAINLY EXPORTED TO?
T/T or L/C.
5.What is the guarantee period of your products?
Our regular warranty of the products is 12months, it calculate from the day that the goods are shipping out from our factory, also
you can choose optional warranty package with cost, the warranty package enhance the warranty from 12months to 36months max;
6.WHERE ARE YOUR PRODUCTS MAINLY EXPORTED TO?
Our products are mainly exported to territory such like Middle east, Southeast Asia, South Asia, South America, Africa, Europe,…etc.
