Высококачественная ручная бензиновая вибрационная машина для уплотнения
- Категория: Compactors >>>
- Поставщик: Jining,Jinheng,Garden,Machinery,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 369.23 $* | 387.35 $* |
| Aug-18-2025 | 366.11 $* | 384.64 $* |
| Jul-18-2025 | 307.61 $* | 322.73 $* |
| Jun-18-2025 | 360.63 $* | 378.45 $* |
| May-18-2025 | 313.23 $* | 329.80 $* |
| Apr-18-2025 | 353.44 $* | 371.71 $* |
| Mar-18-2025 | 350.70 $* | 368.62 $* |
| Feb-18-2025 | 347.23 $* | 364.24 $* |
| Jan-18-2025 | 344.7 $* | 361.17 $* |
Характеристики
Product Display
Model NO | GCF90 | GCF160 | GCF200 |
Engine Type | Honda Gasoline Engine | Honda Gasoline Engine | Honda Gasoline Engine |
Motor Power | 5.5HP | 5.5HP/6.5hp | 5.5HP/6.5hp/8hp |
Weight | 65KG | 100KG | 120KG |
Plate Size | 480*530MM | 420*600MM | 480*600MM |
Working Speed | 6-30M/H | 6-30M/H | 6-30M/H |
Compaction Depth | 160mm | 300mm | 300mm |
Plate compactor
1.Compaction of granular soil in a narrow site.
2. Backfill soil compaction for roadside stones, concrete structures, sidewalk drainage ditches, gas and sewage treatment projects.
3. Leveling and compaction of sand, gravel, soil and asphalt surface.
4. The surface of concrete is grouted and leveled.Vibration tamping machine compacts the pipe backfill Pipe top backfill.The compactness of the pipe top backfill is less than that of the pipe side backfill, so under the load, the soil at the top of the pipe settles more than the soil on the pipe side, causing relative displacement between the two, which can produce a kind of prevention The upward shear force caused by the sinking of the soil on the top of the pipe reduces the top load, reduces the pressure of the soil on the pipe, and thereby reduces the deformation value of the closed body. Of course, the soil near the road surface should still be constructed in accordance with the requirements of the roadbed to achieve road construction quality.Here we first use graded gravel to fill the top of the pipe, and then backfill 50cm on the top of the pipe with clay, hand-push the plate compactor, use a vibratory rammer, the plate compactor company, and then use an excavator to dig the trench to the road roller Wide, use an excavator to backfill the clay road roller and compact it in place. Pay attention to the geotechnical test.
2. Backfill soil compaction for roadside stones, concrete structures, sidewalk drainage ditches, gas and sewage treatment projects.
3. Leveling and compaction of sand, gravel, soil and asphalt surface.
4. The surface of concrete is grouted and leveled.Vibration tamping machine compacts the pipe backfill Pipe top backfill.The compactness of the pipe top backfill is less than that of the pipe side backfill, so under the load, the soil at the top of the pipe settles more than the soil on the pipe side, causing relative displacement between the two, which can produce a kind of prevention The upward shear force caused by the sinking of the soil on the top of the pipe reduces the top load, reduces the pressure of the soil on the pipe, and thereby reduces the deformation value of the closed body. Of course, the soil near the road surface should still be constructed in accordance with the requirements of the roadbed to achieve road construction quality.Here we first use graded gravel to fill the top of the pipe, and then backfill 50cm on the top of the pipe with clay, hand-push the plate compactor, use a vibratory rammer, the plate compactor company, and then use an excavator to dig the trench to the road roller Wide, use an excavator to backfill the clay road roller and compact it in place. Pay attention to the geotechnical test.
Related Products
Company Profile
Packing And Shiping
FAQ
Q: What is your Minimum Order Quantity?
A: Different products have different MOQ,but we can sell you even one piece if we have stock of the model you need.
A: Different products have different MOQ,but we can sell you even one piece if we have stock of the model you need.
Q: How is quality ensured?
A: All our processes strictly adhere to ISO-9001 procedures.And we have one year's quality warranty against B/L issue date.
A: All our processes strictly adhere to ISO-9001 procedures.And we have one year's quality warranty against B/L issue date.
Q: How can I place the order?
A: First sign the PI,pay deposit,then we will arrange the production.After finished production need you pay balance. Finally we will ship the Goods.
A: First sign the PI,pay deposit,then we will arrange the production.After finished production need you pay balance. Finally we will ship the Goods.
Q: How do you guarantee your quality ?
A: Firstly, we do quality test during every process. We produce most components by ourselves, it is started from cutting raw material ,machining roughly in the first step. casting ,forging ,punching ,heat treatment ,finish machining ,painting ,assembling and finally packing ,we will spot check for each steps.Secondly, we will collect all comments on our products from customers in time. And try our best to improving quality all the time.
A: Firstly, we do quality test during every process. We produce most components by ourselves, it is started from cutting raw material ,machining roughly in the first step. casting ,forging ,punching ,heat treatment ,finish machining ,painting ,assembling and finally packing ,we will spot check for each steps.Secondly, we will collect all comments on our products from customers in time. And try our best to improving quality all the time.
