Полностью Гидравлический двойной барабанный дорожный Вибрационный ролик для асфальта бетонной почвы по заводской цене 1000 кг
- Категория: Road Rollers >>>
- Поставщик: Shandong,Benma,Engineering,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 6307.26 $* | 6622.6 $* |
| Aug-20-2025 | 6254.35 $* | 6567.48 $* |
| Jul-20-2025 | 5247.10 $* | 5509.14 $* |
| Jun-20-2025 | 6148.58 $* | 6455.43 $* |
| May-20-2025 | 5353.72 $* | 5621.18 $* |
| Apr-20-2025 | 6042.46 $* | 6344.42 $* |
| Mar-20-2025 | 5989.42 $* | 6288.95 $* |
| Feb-20-2025 | 5936.67 $* | 6233.81 $* |
| Jan-20-2025 | 5883.41 $* | 6177.45 $* |
Характеристики
factory price 1000kg 1200kg fully hydraulic double drum road vibratory roller asphalt concrete soil compactor
factory price 1000kg 1200kg fully hydraulic double drum road vibratory roller asphalt concrete soil compactor
factory price 1000kg 1200kg fully hydraulic double drum road vibratory roller asphalt concrete soil compactor
factory price 1000kg 1200kg fully hydraulic double drum road vibratory roller asphalt concrete soil compactor
Product Description
Features:
1. Equipped with famous brand engine, which can guarantee quality stability and excellent performance.
2. Hawkeye-shaped body design, wide field of vision, and beautiful appearance
3. Used international famous brand hydraulic pump and motor, which can be steplessly shifted and walk forward and backward.
4. LED display instrument panel.
5. Assembled with working light and warning light, could work at night.
6. Ergonomic chair.
7. Passed CE, SGS and ISO certification and won Red Star Award design.
Parameters:
| Item No./Details | BM1200 new design | |
| ENGINE | ||
| Engine | BRIGGS&STRATTON 25T2 | CHANGCHAI 192F |
| Engine type | Single cylinder, OHV, air-cooled, four-stroke, gasoline | Single cylinder, vertical, air-cooled, four-stroke, diesel |
| Number of cylinders | 1 | |
| Output power (KW) | 9.7 | 8.1 |
| Rating speed(RPM) | 3600 | |
| Fuel consupmtion(G/KWH) | 313 | 320 |
| Lubricating oil volume(L) | 1.1 | 1.65 |
| DRIVING | ||
| Electrical equipment(V) | 12 | |
| Drive mode | Variable plunge pump, stepless speed change, double-wheel series, parallel motor | |
| Walking speed (KM/H) | 0--5 | |
| Theoretical climbing ability(%) | 30/35(vibration on/off) | |
| STEERING | ||
| Swing angle(°) | 28 | |
| Steering mode | Hydraulic cylinder, articulated steering | |
| Steering system | Swing articulated | |
| EXCITING SYSTEM | ||
| Vibration wheel | Front | |
| Drive form | Hydraulic Motors | |
| Vibration frequency (HZ) | 65 | |
| Vibration amplitude (MM) | 0.5 | |
| Exciting force(KN) | 22 | |
| SPRINKLING SYSTEM | ||
| Water spray form | Intermittent pressure water spray | |
| CAPACITY | ||
| Hydraulic oil capacity(L) | 22 | |
| Fuel capacity(L) | 6.5 | 5.5 |
| Water tank capacity (L) | 65 | |
| SIZE | ||
| Working width(MM) | 930 | |
| Overall length(MM) | 1980 | |
| Machine height(MM) | 1540 | |
| Turning radius(outer)(MM) | 3165 | |
| Ground clearance(MM) | 245 | |
| Wheel track(MM) | 1356 | |
| Drum size | 560*800mm*2 | |
| Drum thickness(MM) | 12 | |
| WEIGHT | ||
| Weight(KG) | 1200 | |
| Static load(N/CM) | 69.5/68 | |
factory price 1000kg 1200kg fully hydraulic double drum road vibratory roller asphalt concrete soil compactor
Packaging & Shipping
Packaging& shipping of our walking-behind road roller compactors:
Package type:
1. Steel frame
2. Plywood case
3. As customers' request
Shipping way:
1. By air
2. By sea
3. By train
4. By courier
Company Information
FAQ
1. Are you a manufacturer?
Yes, we are manufacturer and our factory have more than 20 years manufacturing experience.
2. Where is your factory?
Our factory is located in Incalcu Industrial Park, Jining city, China. Welcome to visit us. We can also show you our factory and production through video chat.
3. What’s your warranty?
The warranty of our products is 1 year, and we will always provide after sale service.
4. What’s your advantage?
As a factory with R & D capabilities, we can provide OED, OEM service, and also can guarantee delivery time and competitive prices.
5. What kind of payment terms do you accept?
T/T, L/C at sight, Western Union, Cash etc. We also accept trade on Alibaba directly.
