Product Description
Specification
HUASHIDA plastic cylinder tube end edge curling machine characters:
Servo motor speed adjustable by needed
Smallest error range can keep within 0.05mm
Two,three,four and even more stations for you choose.
Pneumatic driven system necessitate providing stable working
Cylinder edge curling material is suitable for PVC, PP, APET and PETG
Wonderful edge curling effect, no scratch, and exact even cylinder height
One set of molds can combine different size with maximum and minimum limit
Servo motor speed adjustable by needed
Smallest error range can keep within 0.05mm
Two,three,four and even more stations for you choose.
Pneumatic driven system necessitate providing stable working
Cylinder edge curling material is suitable for PVC, PP, APET and PETG
Wonderful edge curling effect, no scratch, and exact even cylinder height
One set of molds can combine different size with maximum and minimum limit
Equipment parameters:
Machine Name | Plastic Cylinder Tube End Edge Curling Machine | ||||
Model | HSD-YTJB-2 | HSD-YTJB-3 | HSD-YTJB-4 | ||
Working station | 2 working stations | 3 working stations | 4 working stations | ||
Power supply | 110v/220v/380v | 110v/220v/380v | 110v/220v/380v | ||
Pneumatic range | 3~6kg/㎡ | 3~6kg/㎡ | 3~6kg/㎡ | ||
Diameter of Air Tube | 8mm | 8mm | 8mm | ||
Power | 1.5KW | 1.5KW | 1.5KW | ||
Cylinder diameter | 35~200mm | 35~200mm | 35~200mm | ||
Cylinder length | 10~420mm | 10~420mm | 10~420mm | ||
Material thickness | 0.18-1mm | 0.18-1mm | 0.18-1mm | ||
Production speed | 2~4 seconds / Edge | 2~4 seconds / Edge | 2~4 seconds / Edge | ||
Weight | 280kgs | 320kg | 380kg | ||
Overall size | 1100*550*1700mm | 1500*550*1700 mm | 1900*550*1700 mm | ||
Application range
Plastic Cylinder Tube End Edge Curling Machine is manual edge forming process in PVC Cylindrical box packaging, PP Cylindrical box packaging, and APET, PETG Cylinder tube packaging, plastic cylinder box can be clean/transparent or printed PVC,PP, PETG and APET Tube shaped, which is ideal cylindrical box packaging of Candy, gift, toy, stationery, umbrella, packing gear, badminton, snack food and other small, light goods with outside advertising attractive and display.
