FA1201C New Products 1/1.8" 12mm C mount lens 5MP Industrial Machine Vision Lens

1/1.8" F2.0 C-Mount					Working Distance	Optical Magnification	1/1.8'' Field of View
Focal Length		f=12mm			mm		H	V
F/NO		F=1:2.0-C			900	0.013X	538.7	404
Image Size		1/1.8"(7.2*5.32mm)	1/2.5"(5.76*4.32mm)	1/3"(4.8*3.6mm)	850	0.014X	509	381.7
Angle FOV	H	33.0	27.2	22.9	800	0.015X	479.3	359.5
	V	24.3	20.7	17.6	750	0.016X	449.6	337.2
	D	40.7	33.3	28.1	700	0.017X	419.9	314.9
Object Dimension at WD.300mm	H	182.5mm	147.3mm	122.7mm	650	0.018X	390.3	292.7
	V	136.9mm	110.5mm	92.0mm	600	0.020X	360.6	270.4
	D	228.2mm	180.1mm	153.5mm	550	0.022X	330.9	248.2
Distortion(TV)		<0.3%			500	0.024X	301.2	225.9
Focus distance (min)		0.1m			450	0.026X	271.5	203.6
Flange back		17.526mm in air			400	0.030X	241.8	181.4
Back focus		12.5mm in air			350	0.034X	212.1	159.1
Filter screw size		M25.5*P0.5			300	0.039X	182.4	136.8
Front/Rear effective dia		Front Φ 15.2mm   Rear Φ6mm			250	0.047X	152.7	114.5
Mount		C-Mount			200	0.058X	123	92.3
Temperature range		-10~+50℃			150	0.077X	93.3	70
Storage temperature range		-20~+60℃			100	0.113X	63.7	47.8



• High performace for 5 Mega piexl camera


• Fixed aperture and manual aperture can be selected



• Small volume



•


  TV Free distortion less than 1%




Selling Units:	Single item
Single package size:	10X10X8 cm
Single gross weight:	0.500 kg

Lead Time:

Quantity(Pieces)	1 - 100	>100
Est. Time(days)	15	To be negotiated

Located in Hangzhou, Mstar Technologies, Inc is a professional manufacturer of machine vision products. We have over 6 years of experience in machine vision and have a good reputation in this field.

Quality and Safety: We have implemented a strict and complete quality control system, which ensures that each product can meet quality requirements of customers. Besides, all of our products have been strictly inspected before shipment.

Your Success, Our Glory: Our aim is to help customers realize their goals. We are making great efforts to achieve this win-win situation and sincerely welcome you to join us.

1. When will you ship my order?

Generally, once we get confirmation for payment, we will ship the order within 7-10 days. The specific delivery time depends on the items and the quantity of your order.

2. Does OEM/ODM available?

Yes, just let us know your details, then we can help you to design and put it into production.

3. The sample request is ok? if so, for free?

Re: MOQ is needed for a factory but one sample for testing is acceptable. We'd like to see our customer having a try on our products. But sorry, it's not for free, you need to pay for it.

4. Driver and SDK problems?

Re: We will provide the SDK with the camera for free. And if you meet any problems when using it, just feel free to let us know.

5. How to pay?

RE: Payment Term Credit card, VISA card, e-checking, PayPal, Western Union, T/T.

6. Could I print our logo or company name on our products?

Re: Of course, we could print your logo or company name as your requirements, but you need to send us your logo certification and the certificate of authorization.

7. Shipping

We have strong cooperation with ARAMEX and UPS.

You also can choose your own shipping forwarder.

8. If you have any questions, please contact us at any time.
