Диодимовые очки для легких работников, поставщик из Китая
US $35.00-$45.00
400 нм-700 нм поляризационный лучевой разветвитель пластина телефлуоресцентное полуотражающее
- Категория: Optical Filters >>>
- Поставщик: Hangzhou,Jingyu,Optoelec,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.36 $* | 0.44 $* |
| Aug-19-2025 | 0.32 $* | 0.55 $* |
| Jul-19-2025 | 0.38 $* | 0.21 $* |
| Jun-19-2025 | 0.59 $* | 0.87 $* |
| May-19-2025 | 0.2 $* | 0.41 $* |
| Apr-19-2025 | 0.28 $* | 0.73 $* |
| Mar-19-2025 | 0.12 $* | 0.95 $* |
| Feb-19-2025 | 0.55 $* | 0.38 $* |
| Jan-19-2025 | 0.58 $* | 0.77 $* |
Характеристики
Product information
Available materials | Crystal, White glass,Blue glass, Corning glass, Sapphire and other material |
Product name | Beam Splitter glass |
Size | 2 - 1000mm （Square / round / customized） |
Thickness | 0.21 - 5.0mm, customized |
Transmission wavelength | 400-700nm/400-1100nm, customized |
T/R | 10/90 20/80 30/70 40/60 50/50 60/40 70/30 80/20, customized |
Incident angle | 0°/45°, customized |
The beam splitter is used in DVD/VCD laser reading, DLP/LCoS projection display, optical instruments, optical communications, and industrial cameras.
The beam splitter reflects part of the incident light energy, absorbs a relatively small part, and transmits the rest of the energy.
The beam splitter has obvious neutral color characteristics.
The beam splitter is also the corners of the beam. It is coated with a special film on the surface, so that the incident light can be reflected half and half transmitted, so that a beam of light can be divided into a reflected beam and a transmitted beam, forming two beams of light!
The beam splitter is made by vacuum evaporation of a multilayer dielectric film.
There is no problem that the metal film will absorb. The total penetration and reflection ratio is close to 100.
Function: It is made by vacuum evaporation method, and the light can be changed after passing through the filter. Penetration ratio, for example: half penetration and half reflection, with low absorption characteristics.
Products recommended
Company information
Why choose us
● 20 years of factory direct sales.
●Professional customization, Some are in stock.
●Imported top coating equipment.
●High-heat laser dot experiment, no explosion when heated.
●Using vacuum deposition coating process.
●Standard cleaning room.
FAQ
1.Q: Are you trading company or manufacturer ?
A: We are factory.
2.Q:What is the MOQ?
A:Our MOQ is 1 piece except customized order.
3.Q:Do you provide free samples?
A:Yes!Free samples are available. For more details, please contact the customer service.
4.Q:What is the lead time?
A:Usually it will take 3 days if we have them in stock.Customized order will take 7-30days.
5.Q: What's the material of your products ?
A: Crystal, for Schott glass,for AGC glass, Corning glass,Sapphire and other material
6.Q:How to choose suitable model?
A:Please provide a photo of the product you used before or advise us your needs, we will give suggestion.
2.Q:What is the MOQ?
A:Our MOQ is 1 piece except customized order.
3.Q:Do you provide free samples?
A:Yes!Free samples are available. For more details, please contact the customer service.
4.Q:What is the lead time?
A:Usually it will take 3 days if we have them in stock.Customized order will take 7-30days.
5.Q: What's the material of your products ?
A: Crystal, for Schott glass,for AGC glass, Corning glass,Sapphire and other material
6.Q:How to choose suitable model?
A:Please provide a photo of the product you used before or advise us your needs, we will give suggestion.
