Погружной трубчатый обогреватель из нержавеющей стали 110 В 230 элемент для парового шкафа
- Категория: Industrial Heater >>>
- Поставщик: Yancheng,Honleader,Electric,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.52 $* | 0.77 $* |
| Aug-17-2025 | 0.65 $* | 0.13 $* |
| Jul-17-2025 | 0.82 $* | 0.76 $* |
| Jun-17-2025 | 0.18 $* | 0.56 $* |
| May-17-2025 | 0.33 $* | 0.54 $* |
| Apr-17-2025 | 0.80 $* | 0.19 $* |
| Mar-17-2025 | 0.0 $* | 0.75 $* |
| Feb-17-2025 | 0.36 $* | 0.46 $* |
| Jan-17-2025 | 0.81 $* | 0.88 $* |
Характеристики
Product Description
The stainless steel tubular heater is made of a metal tube as the shell, and spiral electric heating alloy wires are uniformly distributed along the axial direction of the tube. The gaps are filled and compacted with magnesium oxide powder with good insulation and thermal conductivity, and both ends are sealed with silica gel or ceramics. It can heat air, metal molds and various liquids. It is widely used in all kinds of saltpeter tanks, water tanks, oil tanks, acid-base tanks, fusible metal melting furnaces, air heating furnaces, drying furnaces, drying ovens, hot press molds, commercial steamer kitchen food equipment and other devices.
Application
▪ Finned Tubular elements
▪ Animal Incubators for Prenatal Care
▪ Ducts
▪ Epoxy Curing
▪ Food Equipment
▪ Furnaces
▪ Laminating Machine
▪ Hopper and Silo Heaters - Plastic
▪ Dryers
▪ Kettles and Tanks
▪ Ovens - Process, Curing, Food
▪ Paint and Enamel Baking Equipment
▪ Plastic Sheet Bending Equipment
▪ Animal Incubators for Prenatal Care
▪ Ducts
▪ Epoxy Curing
▪ Food Equipment
▪ Furnaces
▪ Laminating Machine
▪ Hopper and Silo Heaters - Plastic
▪ Dryers
▪ Kettles and Tanks
▪ Ovens - Process, Curing, Food
▪ Paint and Enamel Baking Equipment
▪ Plastic Sheet Bending Equipment
▪ Spas and Hot Tubs
▪ Steam Tables
▪ Sterilizers and Autoclaves
▪ Stretch Wrapping Equipment
▪ Ovens
▪ Textile and Chemical Dryers
▪ Welding Preheat Equipment
▪ Air Heating-Free Air Heating
▪ Contact Heating
▪ Radiant Heating
▪ Liquid Heating (Direct Immersion)
▪ Oil Heating
▪ Air & Gas Heating
▪ Steam Tables
▪ Sterilizers and Autoclaves
▪ Stretch Wrapping Equipment
▪ Ovens
▪ Textile and Chemical Dryers
▪ Welding Preheat Equipment
▪ Air Heating-Free Air Heating
▪ Contact Heating
▪ Radiant Heating
▪ Liquid Heating (Direct Immersion)
▪ Oil Heating
▪ Air & Gas Heating
Product Paramenters
Product Name | Tubular Heaters |
Voltage | 12V/24V/48V/110V/230V/380V/Customizable |
Wattage | 1KW/1.5KW/2KW/3KW/4KW/Customizable |
Wattage Tolerance | ±3% |
Leakage Current | ＜0.5MA |
Electric Strength | Cold state withstand voltage AC working at 1500V 50Hz for 1 minute without breakdown |
Thermal insulation | AC work 1000V 50Hz for 1 minute without breakdown |
Sheath Material | SS304, 316L, 310S /T2 Copper/Incoloy800,840/Customizable |
Thread size | G / NPT / BSPP Thread 1'' 1 1/4'' 1 1/2'' 2'' etc /Customizable |
Terminal Styles | Plain Pins/ Flag Terminals/ Spade Terminal/ Screw Terminal/ Special Terminal |
Shapes | U/ Hairpin/ W/ Z/ Straight/ Spiral/ Circular(with extension)/ Double Loop/ Bent Hairpin,etc |
End Cap | Ceramic end (standard)/ Cement/ Epoxy/ RTV seal |
Pipe diameter | 6mm,6.5mm,8mm,10mm,12mm,14mm,16mm,20mm |
Details Images
● Use high-quality Copper/SS304 /SS321, /SS316L/Incoloy800，etc
● Good corrosion resistance
● High mechanical strength
● Long service life
● Good corrosion resistance
● High mechanical strength
● Long service life
● Under the same power condition
● Fast heating
● High thermal efficiency
● Heat evenly
● Stable performance
● Fast heating
● High thermal efficiency
● Heat evenly
● Stable performance
● Different specifications
● Different application
● Different shapes can be customized
● Shipping quickly
● Different application
● Different shapes can be customized
● Shipping quickly
How to order?
Please provied these information:
Please provied these information:
1. Wattage/Voltage/Length/Pipe diameter
2. Heating medium
3. Thread size,if have
4. Quantity
5. Drawings,if have
Please contact us with your special requirements. We are pleased to contact you if you would like more information or want to discuss custom heater elements availability and pricing.
Welcome to order samples for initial evaluation.
2. Heating medium
3. Thread size,if have
4. Quantity
5. Drawings,if have
Please contact us with your special requirements. We are pleased to contact you if you would like more information or want to discuss custom heater elements availability and pricing.
Welcome to order samples for initial evaluation.
Recommend Products
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
YANCHENG HONLEADER ELECTRIC CO.,LTD. has been focusing on the solutions to heater application and development for many years. We not only provide you with high-quality products and services,Well-trained engineers will also provide you with technical supports.It takes 3-4 days for general samples, and 1 week for customzied sample or requests, with ISO, CE, ROHS certification. Our products are exported to the Europe, America, Oceania, Asia, Africa and Latin America.
We are famous for innovative products.With years of production experience as well as the strong support of our partners, Honleader continues to introduce new and customer-satisfied heaters,and have at the same time been working with many branded companies, online store companies, medical institutions, university laboratories and other institutions,whic from the USA and Europe customers to customize their products.We have our own factories and freight forwarders, we can provide more competitive prices and more professional services at low cost.
With rich expertise, our professional team members can respond to customer inquiries more effectively than most competitors, enabling our customers to enjoy from us the following benefits: A)professional service; B)high quality products; C)short sample and production lead time; D) placing OEM or ODM orders We believe in partnership, and are fully committed to control the supply chain in order to provide our customers high quality products, at competitive price, and in a timely manner. We look forward to building up long-term business relationship with you to our mutual benefit.
We are famous for innovative products.With years of production experience as well as the strong support of our partners, Honleader continues to introduce new and customer-satisfied heaters,and have at the same time been working with many branded companies, online store companies, medical institutions, university laboratories and other institutions,whic from the USA and Europe customers to customize their products.We have our own factories and freight forwarders, we can provide more competitive prices and more professional services at low cost.
With rich expertise, our professional team members can respond to customer inquiries more effectively than most competitors, enabling our customers to enjoy from us the following benefits: A)professional service; B)high quality products; C)short sample and production lead time; D) placing OEM or ODM orders We believe in partnership, and are fully committed to control the supply chain in order to provide our customers high quality products, at competitive price, and in a timely manner. We look forward to building up long-term business relationship with you to our mutual benefit.
FAQ
Q: Are your products original?
A: Yes! All products are original and produced by the original manufacturer. Our parts can accept any type of testing, and we will be responsible if there is a quality problem.
Q: What is your warranty?
A: within 365 days after receiving the package.
Q: What is your delivery time?
A: Normally samples need 3-5 days.
Mass production need 7-10 days.
Q: What is the minimum order quantity for your products?
A: MOQ 5Pc. Please feel free to contact us.
Q: Can I provide samples for testing?
A: Yes! You only need to pay the freight and you can send free samples for testing.
Q: How do I pay for the order?
A: We support such as TT, Paypal,Western Union and Alibaba online payment methods.Or you can consult us.
Q: How will my package be shipped?
A: Usually we use DHL, FedEx, TNT, EMS, etc. Otherwise, please contact us.
A: Yes! All products are original and produced by the original manufacturer. Our parts can accept any type of testing, and we will be responsible if there is a quality problem.
Q: What is your warranty?
A: within 365 days after receiving the package.
Q: What is your delivery time?
A: Normally samples need 3-5 days.
Mass production need 7-10 days.
Q: What is the minimum order quantity for your products?
A: MOQ 5Pc. Please feel free to contact us.
Q: Can I provide samples for testing?
A: Yes! You only need to pay the freight and you can send free samples for testing.
Q: How do I pay for the order?
A: We support such as TT, Paypal,Western Union and Alibaba online payment methods.Or you can consult us.
Q: How will my package be shipped?
A: Usually we use DHL, FedEx, TNT, EMS, etc. Otherwise, please contact us.
