Диагностические инструменты с ЖК-дисплеем цифровой высокоточный тестер литий-ионной батареи внутреннего
- Категория: Battery Testers >>>
- Поставщик: Shenzhen,Gbeta,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 55.28 $* | 58.58 $* |
| Aug-15-2025 | 54.13 $* | 57.27 $* |
| Jul-15-2025 | 46.56 $* | 48.98 $* |
| Jun-15-2025 | 53.23 $* | 56.60 $* |
| May-15-2025 | 46.14 $* | 48.77 $* |
| Apr-15-2025 | 52.67 $* | 55.93 $* |
| Mar-15-2025 | 52.24 $* | 55.28 $* |
| Feb-15-2025 | 52.3 $* | 55.83 $* |
| Jan-15-2025 | 51.30 $* | 54.54 $* |
Характеристики
Specification
The maximum resolution of internal resistance is 0.00001Ω, and the maximum measurement range is 200.0Ω. The maximum resolution of
the voltage is 0.00001V, the maximum measurement range is ± 99.999V, and the test lithium battery voltage can display a
sufficiently high sensitivity to 0.0001V. All ranges can measure positive and negative voltage. It can measure lead acid, lithium
ion, lithium polymer, lithium iron phosphate, alkaline, dry battery, nickel metal hydride, nickel cadmium, button battery, etc.
Using the ZR function to measure internal resistance below 5 milliohms is more accurate.
*High Precision
*High Cost-effective
*Intelligent anti-reverse connection*Widely Use
the voltage is 0.00001V, the maximum measurement range is ± 99.999V, and the test lithium battery voltage can display a
sufficiently high sensitivity to 0.0001V. All ranges can measure positive and negative voltage. It can measure lead acid, lithium
ion, lithium polymer, lithium iron phosphate, alkaline, dry battery, nickel metal hydride, nickel cadmium, button battery, etc.
Using the ZR function to measure internal resistance below 5 milliohms is more accurate.
*High Precision
*High Cost-effective
*Intelligent anti-reverse connection*Widely Use
Technical Parameters Precision format:±[(Accuracy percentage]+(Least significant digit)] | ||||||
Range | Maximum Resolution | Accuracy | Display Mode | |||
20mΩ | 0.01mΩ | 0.7%+7 | 22.00mΩ (ZR Mode) | |||
200mΩ | 0.1mΩ | 0.5%+5 | 220.0mΩ | |||
2Ω | 1mΩ | 0.5%+5 | 2.200Ω | |||
20Ω | 10mΩ | 0.5%+5 | 22.00Ω | |||
200Ω | 0.1Ω | 0.6%+5 | 220.0Ω | |||
If the gear is within the range of 5% ~ 95%, when it is not within this range (less than 5% of the gear range or greater than 95% of the gear range), the error may be greater than the above accuracy. | ||||||
Range | Maximum Resolution | Accuracy | Display Mode | |||
1V | 0.00001V | 0.15+0.015 | .99999V | |||
10V | 0.0001V | 0.15+0.010 | 9.9999V | |||
100V | 0.001V | 0.15+0.015 | 99.999V | |||
Voltage measurement: (% reading +% range),Positive and negative symmetry error +5 words | ||||||
Within normal operating temperature, temperature drift 100ppm / ℃ | ||||||
Recommend Products
Company Profile
FAQ
FAQ
1,Q: What's the main product in GBETA?
A: Rechargeable battery. Li-ion and power battery pack.
2,Q: What is overcharge?
A: After charge, tested the batteries' initial state and capacity. Charge to 10.0V at 3C current, then charge to 0.01C at CV mode.Observe changes in battery appearance.
3,Q: What is over discharge?
A: After charge, test the batteries' initial state. When the batteries are normal, discharge to 0V at 0.5C. Observe changes in
battery appearance
4. Q: Can I have a sample order?
A: Yes, we accept sample order to test and check quality. Batteries can be made as require.
5. Q: Do you have MOQ limit?
A: Yes, we have MOQ limit for mass production, but it depends on battery model. Please contact us for details.
6. Q: How about the lead time?
A: Samples will takes 5-7 business days. Mass production will takes 25-30 days. It depends on quantity.
7. Q: How about shipping and delivery time?
A: Generally, battery will be shipped via Express, such as DHL, TNT, FedEx and UPS, delivery time is 3-5 business days. Or DDP
service, delivery time is 11-15 business days. Airline and sea shipping also available.
8. Q: What about after-sale service?
A: We will offer you 1 year guarantee. If there are any problems, please inform us, we will offer you positive solutions.
A: Rechargeable battery. Li-ion and power battery pack.
2,Q: What is overcharge?
A: After charge, tested the batteries' initial state and capacity. Charge to 10.0V at 3C current, then charge to 0.01C at CV mode.Observe changes in battery appearance.
3,Q: What is over discharge?
A: After charge, test the batteries' initial state. When the batteries are normal, discharge to 0V at 0.5C. Observe changes in
battery appearance
4. Q: Can I have a sample order?
A: Yes, we accept sample order to test and check quality. Batteries can be made as require.
5. Q: Do you have MOQ limit?
A: Yes, we have MOQ limit for mass production, but it depends on battery model. Please contact us for details.
6. Q: How about the lead time?
A: Samples will takes 5-7 business days. Mass production will takes 25-30 days. It depends on quantity.
7. Q: How about shipping and delivery time?
A: Generally, battery will be shipped via Express, such as DHL, TNT, FedEx and UPS, delivery time is 3-5 business days. Or DDP
service, delivery time is 11-15 business days. Airline and sea shipping also available.
8. Q: What about after-sale service?
A: We will offer you 1 year guarantee. If there are any problems, please inform us, we will offer you positive solutions.
